Command table
How to read the command table
Command: Command field (See page 26.)
Direction: W When the “Parameter” is set in the parameter field (see page 26), the command functions as described
under “Control/Response Contents”.
R The returned value indicated under “Reply” can be obtained by setting “????” or , “
?” in the
parameter field. (see page 26.)
Parameter: Parameter field (See page 26.)
Reply: Response (Returned value)
Power control/Input mode selection
Function Command Direction Parameter Reply Control/Response contents
Power control POWR W 0 Switches to standby state.
1 Returns from standby state.
R 0 Standby state
1 Normal mode
2 Input signal waiting state
Input mode selection INPS W 0 Toggle change for input mode.
10 HDMI1
13 HDMI2
14 DisplayPort
18 HDMI3
R 10 HDMI1
13 HDMI2
14 DisplayPort
18 HDMI3
PICTURE menu
Function Command Direction Parameter Reply Control/Response contents
AUTO HDR DETECTION ADHD WR 0-1 0-1 0: OFF, 1: ON
COLOR MODE BMOD WR 10 10 THRU (no adjustment)
11 11 BT.2100 (HLG)
12 12 BT.2100 (PQ)
13 13 sRGB
14 14 BT.2020
15 15 BT.709
16 16 DCI-P3
17 17 Adobe RGB
18 18 EBU
50 HDR AUTO(HLG)
51 HDR AUTO(PQ)
101 101 USER1
102 102 USER2
LUMINANCE VLMP WR 0-22, 9999 0-22, 9998,
9999
0: 48cd/m
2
, 1: 80cd/m
2
, 2: 100cd/m
2
, 3: 120cd/m
2
,
4: 150cd/m
2
, 5: 175cd/m
2
, 6: 200cd/m
2
, 7: 225cd/m
2
,
8: 250cd/m
2
, 9: 275cd/m
2
, 10: 300cd/m
2
, 11: 325cd/m
2
,
12: 350cd/m
2
, 13: 375cd/m
2
, 14: 400cd/m
2
, 15: 425cd/m
2
,
16: 450cd/m
2
, 17: 475cd/m
2
, 18: 500cd/m
2
, 19: 525cd/m
2
,
20: 550cd/m
2
, 21: 575cd/m
2
, 22: 600cd/m
2
, 9998: CUSTOM,
9999: THRU
LUMINANCE PRIORITY LUMP WR 0-1 0-1 0: OFF, 1: ON
CONTRAST CONT WR 0-60 0-60
BLACK LEVEL BLVL WR 0-60 0-60
HUE TINT WR 0-60 0-60
CHROMA COLR WR 0-60 0-60
SHARPNESS SHRP WR 0-24 0-24
COLOR
ADJUSTMENT
WHITE BALANCE WHBL WR 0-2 0-2, 99 0: THRU, 1: PRESET, 2: USER, 99: Custom
PRESET CTMP WR 1-18,
29-33
1-18,
29-33, 101
1: Approx. 3000K-15: Approx. 10000K (in steps of 500K), 16: Approx. 5600K,
17: Approx. 9300K, 18: Approx. 3200K, 29: Approx. 2500K, 30: D50, 31: D60,
32: D65, 33: DCI, 101: CUSTOM
“ERR” when WHBL is not set to 1.
