Sharp AE-XM30GR - 3. Other Outdoor Unit Parts

AE-XM30GR
5
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
[2] OUTDOOR UNIT PARTS 2
1-54 QW-IZA100JBZZ AZ Compressor cord
1-69 RH-HXA032JBZZ AX Thermistor
1-73 RTHM-A022JBEO AN Thermistor
1-78 RH-HXA054JBZZ AX Thermistor
1-79 MSPR-A027JBEO AB Thermistor spring
2-16 PDAI-A114JBTB BB Flare coupling base
2-29 LSUB-A021JBWZ AE Flare cou. Sub-s
2-30 LSUB-A020JBWZ AE Flare cou. Sub-s
2-33 MSPR-A026JBEO AB Spring
2-35 MSPR-A046JBEO AC Protector spring
2-63 TLAB-C770JBRA AR Unit label
2-64 TLAB-B709JBRA AH Label
2-66 PSEL-C006JBEZ AC Insulator
2-67 PGUM-A119JBEZ AG Valve rubber
2-68 PGUM-A120JBEZ AG Valve rubber
2-69 MSPR-A129JBEO AD Cycle spring
3-1-1 PVLVRA040JBEZ BM Expansion valve
3-1-2 PVLVRA045JBEZ BD Expansion valve
3-2 DVLV-A668JBKZ AZ 3Way valve unit
3-5 DVLV-A669JBKZ AN 3Way valve unit
3-5-2 LX-NZA228JBEZ AD Service nut
3-5-1 LX-NZA227JBEZ AF Bonnet
3-7 DVLV-A702JBKZ BF Reverse valve ass'Y
3-8 CCIL-A112JBEZ AX Coil
3-9 LX-BZA268JBEZ AB Special screw
3-10 PACU-A043JBEZ BW Accumulator
3-11 GLEG-A116JBEZ AK Compressor cushion
3-12 LBSHCA004JBEO AD Terminal seal
3-13 PCMPRA407JBEZ CT Compressor
3-14 PCOV-A014JBEO AG Terminal cover
3-17 RMOTSA024JBZZ BC Coil
3-18 RMOTSA030JBZZ BC Coil
3-21 PVLVXA061JBEZ BD Reverse valve
3-22 PGUMSA319JBEZ AF
Damper rubber
3-23 PMUF-A081JBEZ AY Muffer
3-24 PGUM-0035JBEO AG Dumper rubber (3/8)inch
3-25 PGUM-0036JBEO AG Dumper rubber (1/2)inch
3-28 DVLV-A703JBKZ AZ Flare union unit 3s
3-29 DVLV-A704JBKZ AZ Flare union unit 3s
3-30 DVLV-A705JBKZ AZ Flare union unit 2s
3-31 LX-NZA250JBEZ AE Fiare nut
3-32 LX-NZA251JBEZ AG Fiare nut
3-33 PCAP-A083JBEZ AC Nut bonnet
3-34 PCAP-A084JBEZ AC Nut bonnet
3-35 PTUB-A196JBEZ AK Pipe insulator
3-36 DVLV-A794JBKZ BM Flare union unit 4s
3-37 DVLV-A796JBKZ BM Flare union unit 2s
3-38 PCAP-A103JBEZ AF Nut bonnet
3-39 LX-NZA280JBEZ AG Flare nut(4)
4-5 LX-BZA355JBEZ AE Special screw
4-6 LX-NZA313JBEZ AE Special nut
6-1 TINS-B048JBRZ AH Insulator manual
6-2 TINS-B049JBRZ AH Insulator manual
6-3 TINS-B050JBRZ AH Insulator manual
6-5 LX-BZA354JBEZ AC Hex screw 10
6-6 GFTASA002JBFA AM Cable cover
6-7 LBND-A046JBEO AE Wire fixing band
6-8 LPFT-A134JBFZ AF Drain joint
6-9 LPFT-A135JBFZ AH Drain tray
6-10 PTUB-A218JBEZ AB Tube insulator
[3] OTHER OUTDOOR UNIT
1-6 QW-VZE592JBZZ AP Lead wire (TBN-T2)
1-7 QW-VZE593JBZZ AP Lead wire (TBL-T1)
1-8 QW-VZF079JBZZ AU Lead wire (TB-CN6)
1-9 QW-VZF212JBZZ AK Lead wire (TBE-BOX)
1-10-1 RFIL-A064JBE0 AF Ferrite core (FC1-9)
1-10-2 RNF--A001VBE0 AF Ferrite core (FC10-12)
1-13 RH-VXA002JBZZ AF Varistor
1-14 QFS-GA065JBZZ BA Fuse 20A AC250V(FUSE1/2)
1-15 QFS-GA062JBZZ AF Fuse 3.15A C250V(FUSE3-4)
1-16 QFS-GA063JBZZ AE Fuse 2A C250V(FUSE5)
1-17 QFS-GA064JBZZ AF Fuse 1A C250V(FUSE6)
1-18 QSPGCA003JBZZ AH Surge absorb(SA1)
1-19 QTAN-0129JBEO AB Fuse CLIP(Fuse1-2)
1-20 QW-VZF080JBZZ AU Lead wire (IPM 10A LEAD)
1-21 QW-VZE581JBZZ AP Lead wire (IPM 2P LEAD)
1-22 QW-VZF081JBZZ AU Lead wire (DISPLAY LEAD)
1-23 QW-VZE585JBZZ AP Lead wire (AF LEAD)
1-25 QW-VZE624JBZZ AP Lead wire (BLUE)
1-26 QW-VZE625JBZZ AP Lead wire (BROWN)
1-27 RH-IXA882JBZZ BK Micro computer(IC1)
1-28 RH-QXA005JBZZ AW Ptc thermistor (PTC1)
1-29 RRLYDA008JBZZ AH Relay(RY3)
