Sharp AH-N45DP2 - Disassembling Procedure

22
AH-N45DP2
AU-N45DP2
AH-N56DP2
AU-N56DP2
DISASSEMBLING PROCEDURE
FOR INDOOR UNIT MODEL [AH-N45DP2 / AH-N56DP2]
CAUTION:DISCONNECT THE UNIT FROM THE POWER SUPPLY BEFORE ANY SERVICING
1. Open the Opne panel, remove 2 Air Filters.
2. Open the Louver frame.unlook the hooks,and pull
the unit.
3. Remove 6 screws fixing the Front panel.
4. Remove the screw fixing the Cord holder.
