Sharp AH-N45DP2 - Electrical Parts

6
AH-N45DP2
AU-N45DP2
AH-N56DP2
AU-N56DP2
Part Part Name Items Specifications
No. AH-N45DP2 AH-N56DP2
1 Terminal Board Rating 300V 25A
2 Fan motor Rating 400V or 430V 2µF
Capacitor
3 Relay Rating RY1 AC250V 20A RY4 AC250V 5A
Coil Volt.; 12V Coil Volt.; 12V
4Printed Wiring Material Paper Base Phenolic Resin (UL 94V-0)
Board
5 Transformer Rating Pri 220 - 240VAC Sec. 16.8V DC 0.29A
6 Fan motor Rating 220 - 230VAC 60Hz 41W 4-Pole
Type MLB038
Thermal Protector Cut off 135±10˚C
(Internal)
7 Power Supply Rating 20A 250V 12AWG
Cord Type SJT12AWGSJT12 (12AWGX3)
8 Louver Motor Rating DC12V 250
Type MP35EA
Part Part Name Items Specifications
No. AU-N45DP2 AU-N56DP2
1 Terminal Board Rating 300V 25A
2 Fan motor Rating 450V 3µF 450V 3µF
Capacitor
3 Running Rating 370V or 400V 35µF 370V or 400V 35µF
Capacitor
4 Compessor Rating AC208 - 230V 60Hz 1250W AC208 - 230V 60Hz 1600W
Type PH28NNBT PH33NPBT
5 Fan motor Rating 220VAC 60Hz 63W 6-Pole 220VAC 60Hz 86W 6-Pole
Type MLB027 MLB028
Thermal protector Cut off 135˚C±5˚C
(Internal)
6 Relay Rating – AC250V 30A
Coil volt: 200 -240V
ELECTRICAL PARTS
