32
AH-N45DP2
AU-N45DP2
AH-N56DP2
AU-N56DP2
REF. NO. PART NO. DESCRIPTION Q'TY CODE
2-25 RIC--A025BDE0 Integrated circuit (IC4, IC5) 2 AE
2-26 RH-IZA140JBE0 Integrated circuit (IC6) 1 AE
2-27 VHIBR24C01A-6 Integrated circuit (IC8) 1 AF
2-28 RRMCUA001JBZZ Photo detector unit (IC101) 1 AK
2-29 RH-VXA002JBZZ Varistor (NR1) 1 AF
2-30 RTRN-A181JBE0 Current transformer (CT1) 1 AN
2-31 VHRS201D01/-6 Solid state relay (SSR1) 1 AK
2-32 VHRPR33MF11-6 Solid state relay (SSR2) 1 AX
2-33 RTRN-A287JBZZ Transformer (TR1) 1 AT
2-34 RRLYDA004JBZZ Relay (RY1) [AH-N45DP2] 1 AG
2-35 RRLYDA008JBZZ Relay (RY4) [AH-N56DP2] 1 AH
2-36 QFS-GA053JBZZ Fuse (WPE1) 1 AE
CYCLE PARTS
3- 1 CPIPCA723JBKZ Tube assembly [AH-N45DP2] 1 BA
3- 1 CPIPCA729JBKZ Tube assembly [AH-N56DP2] 1 BA
3- 2 PSEN-A042JBKZ Flare nut assembly (1/4") 1 AL
3- 3 PSEN-A043JBKZ Flare nut assembly (3/8") [AH-N45DP2] 1 AD
3- 3 PSEN-A048JBKZ Flare nut assembly (1/2") [AH-N56DP2] 1 AP
3- 4 PVLV-A222JBEZ Flare union (1/4") 1 AG
3- 5 PVLV-A223JBEZ Flare union (3/8") [AH-N45DP2] 1 AL
3- 5 PVLV-A238JBEZ Flare union (1/2") [AH-N56DP2] 1 AM
3- 6 DEVA-A188JBKZ Evaporator sub assembly [AH-N45DP2] 1 CA
3- 6 DEVA-A203JBKZ Evaporator sub assembly [AH-N56DP2] 1 BW
ACCESSORY PARTS
4- 1 CRMC-A607JBEZ Remote control 1 BA
4- 2 UBATUA027JBE0 Battery pack 1 AE
4- 3 LHLD-A535JBFA Cord holder (for covering the terminal board of indoor unit) 1AE
4- 4 XTTSD40P20000 Tapping screw (for fixing the cord holder) 1 AA
4- 5 LX-NZA207JBEZ Special nut (for fixing long screw steadily) 10 AE
4- 6 TINS-A767JBRZ Installation manual 1 AF
4- 7 PPLTNA061JBWZ Mounting angle 1 AT
4- 8 XTTSD45P30000 Long screw 8 AA
4- 9 TINS-A768JBRZ Operation manual 1 AE
4-10 XTTSF40P20000 Tapping screw (for fixing the remote controller holder) 1 AB
4-11 LHLD-A484JBFA Holder 1 AE
4-12 TGANJB557JBRZ Warranty card 1 AF
SCREWS
5- 1 LX-BZA075JBE0 Special screw (for earth) 1 AA
PACKING PARTS
6- 1 CPADBA047JBKZ Packing pad assembly 2 AN
6- 2 SPADBA162JBEZ Packing pad (sheet) 1 AL
6- 3 SPAKCB320JBEZ Packing case [AH-N45DP2] 1 AV
6- 3 SPAKCB321JBEZ Packing case [AH-N56DP2] 1 AV
HOW TO ORDER REPLACEMENT PARTS
To have your order filled prompty and correctly, please furnish the following information.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
