REF. NO. PART NO. DESCRIPTION Q'TY CODE
REPLACEMENT PARTS LIST [AH/AY-X079E/X099E]
CABINET AND UNIT PARTS
1- 1 CMOT-A263JBE0 Fan motor sub assembly 1 BH
1- 2 PGUMMA071JBE0 Motor cushion 1 AN
1- 3 CHLD-A050JBK0 Bearing assembly 1 AG
1- 4 DCHS-A352JBK0 Cabinet assembly 1 BA
1- 5 NFANCA058JBE0 Cross flow fan 1 AS
1- 6 CSRA-A443JBK0 Drain pan assembly 1 BK
1- 7 CMOTLA486JBE0 Fan motor 1 BM
1- 8 MJNTPA058JBFA Louver link 2 AC
1- 9 MLOV-A184JBFA Horizontal adjustment louver 10 AB
1-10 MLOV-A172JBFC Vertical adjustment louver 1 AN
1-11 MLOV-A173JBFC Vertical adjustment louver 1 AK
1-12 QW-VZC406JBE0 Fan motor wire 1 AK
1-13 LHLD-A197JBFP Louver holder 2 AX
1-14 NBRG-A026JBFA Louver bushing 2 AB
1-15 PBOX-A186JBK0 Louver gear assembly 1 BA
1-16 CHOS-A004JBK0 Drain hose assembly 1 AM
1-17 PPACGA010JBE0 O ring 1 AB
1-18 DCOV-A138JBFB Blow cover 1 AL
1-19 RMOT-A061JBE0 Louver motor 1 AS
1-20 PGUMMA110JBE0 Drain cap 1 AD
1-21 CWAK-B850JBK0 Front panel assembly 1 BD
1-22 CPNL-A300JBK0 Open panel assembly 1 AV
1-23 HBDG-A059JBEA Badge 1 AF
1-24 DDEC-A193JBK0 Display cover assembly 1 AF
1-25 PFILMA088JBEA Air filter 2 AK
1-26 LHLD-A187JBFB Tube holder 1 AC
1-27 HPNL-A195JBEB Open panel 1 AS
1-28 TSPC-C948JBRA Name label [AH-X079E] 1 AD
1-28 TSPC-C946JBRA Name label [AH-X099E] 1 AD
1-28 TSPC-C947JBRA Name label [AY-X079E] 1 AD
1-28 TSPC-C918JBRA Name label [AY-X099E] 1 AE
1-29 LHLD-A297JBFB Motor holder 1 AE
1-30 PGUMMA082JBE0 Motor cushion 1 AD
1-31 GWAK-A203JBFC Front panel 1 AT
1-32 PCOV-A306JBF0 Drain cover 1 AE
1-33 TLABCB148JBR0 Wiring diagram 1 AE
1-34 QW-VZC500JBE0 Louver motor wire 1 AF
1-35 LHLD-A303JBFA Tube cover 1 AD
1-36 PSEL-B554JBE0 Aluminum tape 1 AB
1-37 PSEL-B555JBE0 Aluminum tape 1 AB
1-38 PSEL-B556JBE0 Aluminum tape 1 AB
1-39 PSEL-B557JBE0 Aluminum tape 1 AB
1-40 PSEL-B559JBE0 Aluminum tape 1 AB
1-41 PSEL-B558JBE0 Aluminum tape 1 AB
CONTROL BOX
2- 1 RTHM-A300JBE0 Thermistor 1 AP
2- 2 PBOX-A191JBF0 Control box 1 AP
2- 3 LHLD-A313JBF0 Cord holder 1 AC
2- 4 LHLD-A282JBF0 Thermistor holder 1 AG
2- 5 PCOV-A300JBF0 Thermistor holder cover 1 AB
2- 6 HPNLCA578JBFA Control box cover 1 AF
2- 7 HPNLCA595JBEA Control panel 1 AC
2- 8 PCOV-A278JBF0 LED holder 1 AH
2- 9 LPLTMA147JBW0 Control box angle 1 AF
2-10 DPWBFA145JBK0 Electric control board [AH-X079E] 1 BR
2-10 DPWBFA144JBK0 Electric control board [AH-X099E] 1 BR
2-10 DPWBFA143JBK0 Electric control board [AY-X079E] 1 BN
2-10 DPWBFA142JBK0 Electric control board [AY-X099E] 1 BN
2-11 QACC-A176JBE0 Power supply cord 1 AY
2-12 QTAN-A152JBE0 Terminal board 1 AN
2-13 QTAN-A186JBE0 4 poles terminal board 1 AP
2-14 QW-VZD389JBE0 Terminal wire L 1 AG
2-15 QW-VZC487JBE0 Terminal wire N 1 AE
2-16 QW-VZD390JBE0 Main relay wire 1 AF
2-17 QW-VZC489JBE0 Earth lead 1 AF
2-20 PSGY-A415JBE0 Photo detector unit (IC101) 1 AK
2-21 QFS-AA050JBE0 Fuse 2.5A 250V 1 AD
2-22 RH-IZA140JBE0 IC (IC5) 1 AE
2-23 RH-IZA149JBE0 IC (IC3) 1 AE
2-24 RH-IZA337DRE0 ICEEPROM (IC80) 1 AK
2-25 RH-TZA098JBE0 Transistor (Q1) 1 AB
2-26 RH-VZA020JBE0 Varistor (CNR1) 1 AE
