INDOOR UNIT
PART NAMES
1
Inlet (Air)
2
Open Panel
3
Air Filter
4
AUX Button
5
Receiver Window
6
Vertical Airfl ow Louvre
7
Horizontal Airfl ow Louvre
8
Outlet (Air)
9
OPERATION Lamp (Green
)
10
TIMER Lamp (orange
)
11
PLASMACLUSTER Lamp*
(blue
)
*High end models only
OUTDOOR UNIT
12
Inlet (Air)
13
Refrigerant Pipe and Cable
14
Drainage Hose
15
Outlet (Air)
12
13
14
15
1
2
3
4
5
6
7
8
9
10
11
9
10
High end modelsStandard models
12
13
14
15
AU-X18UED
AU-X18UHD
AU-X24UED
AU-X24UHD
