Sharp AQUOS 4T-C60CH1X User Manual

3 4
Remote control unit
DISPLAY
ATV/DTV
AD/MPX
EPG
HDMI
AV MODE
SUPER
ECO
WIDE
GUIDE INFO RADIO
1
2
5
7
8
9
11
6
3
4
12
13
14
15
16
17
18
10
19
20
21
8
e
(Mute)
Press
e s
Mutes sound.
Press
e
again
s
Restores sound.
Mute will be cancelled after 30 minutes. However, the TV will
not suddenly output loud sound as the volume level will be
set to 0 automatically. Increase the volume level by pressing
VOL
k
.
9
a
/
b
/
c
/
d
(Cursor)
Select a desired item on the setting screen.
ENTER
Execute a command.
10 ATV/DTV
Press to switch between ATV and DTV mode. After switching
from ATV or DTV, radio or external input mode to ATV and
DTV mode, the TV jumps to the most recently viewed ATV and
DTV channel.
11 Colour (Red/Green/Yellow/Blue)
The coloured buttons are correspondingly used to select the
coloured items on the screen.
TELETEXT mode: Select a page. (See page 12.)
12 SUPER ECO
Reduce overall power consumption based on user
preferences.
13 WIDE
Change a wide image mode. (See page 9.)
14 AV MODE
Select an audio and video setting. (See page 8.)
15 INPUT (INPUT SOURCE)
Select an input source.
16 CH
r
/CH
s
TV input mode: Select the channel.
(CH
r
) Increase the channel number.
(CH
s
) Decrease the channel number.
TELETEXT mode: Select a page. (See page 12.)
17 MENU
Display the menu screen.
18 AD/MPX
Select the sound multiplex mode and audio description.
19 RETURN
MENU mode: Return to the previous menu screen.
20
m
(TELETEXT),
k
(Reveal hidden for TELETEXT),
3
(Hold),
[
(SUBTITLE for TELETEXT)
Use for TELETEXT mode. (See page 12.)
21 EPG
DTV mode: An “EPG (Electronic Programme Guide)” is a
programme schedule, which is displayed on the TV screen.
The EPG is broadcasted together with DTV.
GUIDE
DTV mode: Display the programme channel list.
INFO
DTV mode: Display the programme information.
RADIO
Press to switch from DTV to radio mode. The TV will jumps to
the most recently tuned radio channel.
1 POWER (STANDBY/ON)
To switch the power on and off.
2 SLEEP
Set the Sleep timer.
0 hr. 30 min. 1 hr. 00 min.
2 hr. 30 min.
1 hr. 30 min.
2 hr. 00 min.
Off
3 HDMI
Select the HDMI input mode.
4 0 – 9
Set the channel.
TELETEXT mode: Set the page. (See page 12.)
5
A
(Flashback)
Press
A
to return to the previous selected channel
or external input mode.
6 DISPLAY
Display the channel or input information.
7 VOL
k
/VOL
l
Set the volume.
(VOL
k
) Increase the volume.
(VOL
l
) Decrease the volume.
Inserting the batteries
1
Open the battery cover.
2
Insert the two supplied “AAA” size batteries.
3
Close the battery cover.
• Place batteries with their terminals corresponding to
the (
e
) and (
f
) indications in the battery compartment.
CAUTION
• Batteries (battery pack or batteries installed) shall not be exposed to excessive heat such as sunshine, fi re or the like.
Part names
TV (Front)
Remote control sensor /
POWER indicator
Light off Power off.
Lighted (Red) The TV is in standby mode.
Lighted (Green) The TV is on.
TV (Rear)
POWER
SUPPLY
DC5V
TOTAL 2A
/ AUDIO
OUT(L/R)
USB
2
4
3
5
1
6
7
POWER
SUPPLY
DC5V
TOTAL 2A
/ AUDIO
OUT(L/R)
USB
89
11
10
1 Antenna input terminal
2 POWER SUPPLY terminal*
3 USB terminal**
4 HDMI 1 (HDMI/ARC) terminal
5 HDMI 2 (HDMI) terminal
6 HDMI 3 (HDMI) terminal
7 /AUDIO OUT (L/R) terminal
8 SERVICE ONLY terminal***
9 AV IN terminals
10 DIGITAL AUDIO OUTPUT terminal
11 JOG-KEY
JOG-KEY BASIC FUNCTION
r
CH UP
s
INPUT
+ VOL UP
– VOL DOWN
a
POWER
* POWER SUPPLY terminal use for USB charger.
** USB terminal use for USB media player. (See page 12.)
*** Usually do not connect anything to this terminal as it reserved only for service personnel.
• The illustrations and on-screen displays in this operation manual are for explanation purposes and may vary slightly from
the actual operations.
• Some features differ depending on the selected country.
4T-C60CH1X_H375_EN.indd 24T-C60CH1X_H375_EN.indd 2 2/25/2020 2:36:13 PM2/25/2020 2:36:13 PM
