3
4
Attaching the stand cover.
1
Insert the stand cover.
2
Insert and tighten four short screws into the holes
of the stand cover.
NOTE
•
To detach the stand unit, perform the steps in reverse order.
• A screwdriver is not supplied with this product.
Attaching the stand unit
• Before performing work, spread cushioning over the
surface on which you will be laying the TV. This will prevent
it from being damaged.
CAUTION
• Attach the stand in the correct direction.
•
Be sure to follow the instructions. Incorrect installation
of the stand may result in the TV falling over.
1
Confi rm that there are screws with the stand unit.
(Eight long screws and four short screws)
2
Attach the supporting post for the stand unit
onto the base using the long screws with a
screwdriver as shown.
Supporting
post
Front
3
Insert the stand into the openings on the bottom
of the TV (hold the stand so it will not drop from
the edge of the base area).
Soft cushion
LC-60LE631M_EN 662.indd 3LC-60LE631M_EN 662.indd 3 10/2/2012 11:31:28 AM10/2/2012 11:31:28 AM
