– 31 –
O
1ST ﾄﾚｲ給紙ﾕﾆｯﾄ (1ST Tray paper feeding unit)..AR-200M,AR-M205
NO. PARTS CODE
PRICE RANK
NEW
MARK
PART
RANK
DESCRIPTION
Ex. Ja.
1 NGERH1207FCZZ AF DS C
Joint gear(40T) 連結ｷﾞﾔｰ
2 MARMP0229FCZZ AE DS C
Joint arm 連結ｱｰﾑ
3 MSPRT0128QSZZ AB DJ C
Joint arm spring 連結ｱｰﾑﾊﾞﾈ
4 XRESP50-06000 AA DD C
E type ring E ﾘﾝｸﾞ
5 LBOSZ1031FCZZ AC DJ C
Clutch boss ｸﾗｯﾁﾎﾞｽ
6 MSPRC0161QSZZ AF DS C
Clutch spring ｸﾗｯﾁｽﾌﾟﾘﾝｸﾞ
7 PPIPP0007QSZZ AD DJ C
Clutch pipe ｸﾗｯﾁｽﾘｰﾌﾞ
8 NGERH1132FCZZ AH DX C
Clutch gear(29T) ｸﾗｯﾁｷﾞﾔｰ
9 NBRGM0501FCZZ AB DJ C
Metal D(B-F6-7) ﾒﾀﾙ D
10 DHAI-0075QSZ1 AR EQ N C
1ST harness 1ST ﾊ - ﾈｽ
13 NROLP0044QSZ2 AQ EQ C
1ST transport roller 1 段搬送ﾛｰﾗｰ
15 VHPGP1A71A1-1 AG DX B
Photo sensor(GP1A71A1) ﾌｫﾄｾﾝｻｰ
16 RPLU-0012QSZ1 AM EG N B
Paper feeding solenoid 給紙ｿﾚﾉｲﾄﾞ
17 NBRGC0188FCZZ AB DD C
PF bearing PF 軸受
18 XRESP40-06000 AA DD C
E type ring E ﾘﾝｸﾞ
19 LBOSZ1510FCZZ AF DX C
Cam boss A1 ｶﾑﾎﾞｽ A1
20 PPIPP0109FCZZ AB DD C
Pipe A 手差しｸﾗｯﾁｽﾘｰﾌﾞ A ﾊﾟｲﾌﾟ
21 MSPRC1315FCZ1 AD DJ C
Clutch spring A 手差しｸﾗｯﾁｽﾌﾟﾘﾝｸﾞ A
22 LPINS0181FCZZ AA DD C
Spring pin ｽﾌﾟﾘﾝｸﾞﾋﾟﾝ
23 LBOSZ1508FCZZ AG DX C
Cam boss A2 ｶﾑﾎﾞｽ A2
26 QSW-B0017QSZZ AF DS B
Tray detect switch ﾄﾚｲ検知ｽｲｯﾁ
27 MSPRD0134QSZ2 AC DJ C
Paper feeding earth spring 給紙ｱ - ｽﾊﾞﾈ
28 NGERH0041QSZZ AF DS C
2ND gear ID(18T/26T) 2 段ｷﾞﾔｰ
29 NGERH0990FCZZ AB DJ C
Gear(16T) ｷﾞﾔｰ
30 PTME-0017QSZZ AD DJ C
Paper feeding clutch pawl 給紙ｸﾗｯﾁ爪
31 MSPRT0130QSZ1 AB DJ C
Clutch pawl spring ｸﾗｯﾁ爪ﾊﾞﾈ
32 PTME-0016QSZZ AD DJ C
Transport clutch pawl 搬送ｸﾗｯﾁ爪
33 RPLU-0013QSZ1 AM EG N B
Transport solenoid 搬送ｿﾚﾉｲﾄﾞ
34 XBBSD30P06000 AA DD C
Screw(3×6) ﾋﾞｽ
35 MLEVP0039QSZ1 AE DS C
PPDI actuator PPDI ｱｸﾁｭｰﾀｰ
36 MLEVP0046QSZZ AD DJ C
CICS actuator CICS ｱｸﾁｭｴｰﾀｰ
38 LFRM-0031QSE3 AU EZ C
Paper feeding frame 給紙ﾌﾚｰﾑ
41 LPLTM0137QSZZ AD DJ C
Boss reinforce plate ﾎﾞｽ補強板
42 LX-WZ0314FCZZ AA DD C
Poly slider ﾎﾟﾘｽﾗｲﾀﾞｰ
43 MSPRC0157QSZZ AC DJ C
Break spring ﾌﾞﾚｰｷｽﾌﾟﾘﾝｸﾞ
44 NBRGC0529FCZZ AD DJ C
Bearing 軸受
45 PPIPP0011QSZZ AC DJ C
Break sleeve ﾌﾞﾚｰｷｽﾘｰﾌﾞ
46 XBBSE30P06000 AA DD C
Screw(3×6) ﾋﾞｽ
47 RCORF0006QSZZ AL EB C
Core ｺｱ
48 XWHSD60-10000 AA DD C
Washer ﾜｯｼｬｰ
50 RHET-0011QSZZ AQ EQ N E
Heater unit (1ST tray) (Japan) 除湿ﾋ - ﾀ -
51 XEBSE30P08000 AA DD C
Screw(3×8) (Japan) ﾋﾞｽ
52 MSPRD0156QSZZ AB DJ C
PPDIACT spring PPDIACT 復帰ｽﾌﾟﾘﾝｸﾞ
53 PSPO-0005QSZZ AA DJ C
Cluch pawl spong (Europe) ｸﾗｯﾁ爪ｽﾎﾟﾝｼﾞ
54 PSPO-0007QSZZ AB DJ C
Toransport cluch pawl spong (Europe) 搬送ｸﾗｯﾁ爪ｽﾎﾟﾝｼﾞ
55 LPLTM0120QSZZ AF DS C
Heater raditate plate (Japan) ﾋｰﾀｰ放熱板
56 XHBSE30P08000 AA DD C
Screw(3×8) (Japan) ﾋﾞｽ
57 NSFTZ0067QSZZ AK DX N C
Paper feed roller shaft 給紙ﾛｰﾗｰｼｬﾌﾄ
58 LHLDR0095QSZZ AD DJ N C
Paper feed roller holder 給紙ﾛｰﾗｰﾎﾙﾀﾞｰ
59 XEBSE30P12000 AA DD C
Screw(3×12) ﾋﾞｽ
60 PCLR-0011QSZZ AC DJ N C
Roller color ﾛｰﾗｰｶﾗｰ
61 LBRCR0011QSZZ AD DJ N C
Paper feed roller bracket 給紙ﾛｰﾗｰﾌﾞﾗｹｯﾄ
62 PGUMM0013QSZZ AG DX N C
Paper feed roller rubber 給紙ﾛｰﾗｰｺﾞﾑ
64 DHAI-0344QSZZ AH DX N C
2nd heater harness [AR-200M] 2nd ﾋｰﾀｰﾊｰﾈｽ
501 CFRM-0031RS5C BL HL N E
Paper feeding unit (1ST tray) (Except Europe) 給紙ﾕﾆｯﾄ
502 CSFTZ0067RS52 AW FG N E
Paper feeding shaft 給紙ｼｬﾌﾄ
503 CGUMM0013RS51 AN EG N E
Paper feed roller rubber unit 給紙ﾛｰﾗｰｺﾞﾑﾕﾆｯﾄ
