AR-6020V MAINTENANCE 9 – 5
Fusing sec-
tion
Upper heat roller - O O O
Upper heat roller bearing - X X X
Pressure roller - O O O O O
Pressure roller bearing - X
O
X
O
Replace if necessary.
Upper separation pawl - O O O
Lower separation pawl - O O O O O
Upper cleaning pad - X X X
Thermistor - - O O O O O
Gear -
Paper guide - O O O O O O
Drive section Gears -
XX XXX X
Belts - X X X O X X
Filters
Ozone filter - X X Or, replace it every 6 month use.
Paper exit
section
Transport rollers X O O O O O O
Gears X X X X X X X
Discharge brush X X X X X X X
Transport paper guides O O O O O O O
Sensors X X X X X X X
Document
transport
section
(RSPF)
Paper feed roller O O O O O O O
Replacement reference:
Replace according to the RSPF
paper feed counter value.
RSPF section roller: 100K or 1
years of use
When replacing the paper feed
roller, apply grease to the paper
feed shaft. (GP-501MR)
Pickup roller O O O O O O O
Separation roller O O O O O O O
Torque limiter X X X X X X X
Replacement reference:
Replace according to the RSPF
paper feed counter value.
RSPF torque limiter: 400K or 2
years of use
Discharge brush X X X X X X X
Transportation rollers O O O O O O O
Sensors X X X X X X X
Reading plate O O O O O O O
Gears X X X X X X X
Belts X X X X X X X
OC mat O O O O O O O
Cassette
paper feed
section
Pickup roller X O O O O O O
Replace it every 100K or 1 year of
use
Paper feed roller X O O O O O O
Separation roller X O O O O O O
Torque limiter X X X X X X X
Transportation rollers X O O O O O O
Paper guides O O O O O O O
Gears X X X X X X X
Apply the grease to the necessary
part.
Unit name Part name When
calling
100K 150K 200K 300K 400K 450K Remark
