– 23 –
J
排紙ﾌﾚｰﾑﾕﾆｯﾄ (Delivery frame unit)
NO. PARTS CODE
PRICE RANK
NEW
MARK
PART
RANK
DESCRIPTION
Ex. Ja.
1 XEBSD30P08000 AA DD C
Screw(3×8) ﾋﾞｽ
2 GCOV-0049QSZ1 AK EB N C
Delivery front side cover 排紙前ｶﾊﾞｰ
3 CPWBF0129QSE1 AQ EQ N E
Delivery interface PWB 排紙中継基板
6 NROLM0103QSZZ AQ EQ N C
Delivery roller C 排紙ﾛｰﾗｰ C
7 MSPRT0229GCAZ AC DJ C
FU spring R FU ﾊﾞﾈ R
8 NROLP0034QSZZ AD DJ N C
Delivery roller 排紙従動ﾛｰﾗｰ
9 NKOM-0002QSZZ AC DJ N C
Delivery collar 排紙ｺﾛ
11
PBRSR0009QSZ1 AH DX N B
Discharge brush [AR-200M/AR-160M/AR-M160/AR-5220] 除電ﾌﾞﾗｼ
PBRSR0005QSZZ AK EB B
Discharge brush [AR-M205] 除電ﾌﾞﾗｼ
12 XRESP50-06000 AA DD C
E type ring E ﾘﾝｸﾞ
13 NBRGC0529FCZZ AD DJ C
Bearing 軸受
14 LPLTM0100QSZ1 AD DJ N C
Delivery earth plate B 排紙ｱｰｽ板 B
15 NBRGY2122SCZZ AB DD B
Transport roller bearing 1 搬送ﾛｰﾗｰﾍﾞｱﾘﾝｸﾞ 1
16 LHLDZ0040QSZ2 AS EQ N C
Delivery roller holder 排紙従動ﾛｰﾗｰﾎﾙﾀﾞｰ
28 MLEVP0106QSZZ AD DJ N C
Delivery actuator 排紙ｱｸﾁﾕｴｰﾀ
29 CPWBF0147QSE2 AP EQ N E
Duplex/P-out sensor PWB DUP/P-OUT ｾﾝｻｰ基板
30 MSPRD0143QSZ1 AF DS C
Delivery earth spring A 排紙ｱｰｽﾊﾞﾈ A
31
NPLYZ0030QSZZ AE DJ N C
Delivery pulley [AR-200M/AR-160M/AR-M160/AR-5220] 排紙ﾌﾟｰﾘｰ
NGERH0063QSZZ AD DJ C
Delivery drive gear(30T) [AR-M205] 排紙駆動ｷﾞﾔｰ
32 LPINS0258FCZZ AA DD C
Spring pin(φ3-8) ｽﾌﾟﾘﾝｸﾞﾋﾟﾝ
33 NBRGC0019QSZZ AD DJ C
Bearing(φ6) 軸受
34 XRESP40-06000 AA DD C
E type ring [AR-M205] E ﾘﾝｸﾞ
35 NGERH0070QSZZ AC DJ C
DUP delivery R gear(20T) [AR-M205] DUP 排紙 R ｷﾞﾔｰ
36 XPSSJ20-10000 AA DD C
Spring pin(φ2-10) [AR-M205] ｽﾌﾟﾘﾝｸﾞﾋﾟﾝ
37 NBRGY2122SCZZ AB DD B
Transport roller bearing 1 [AR-M205] 搬送ﾛｰﾗｰﾍﾞｱﾘﾝｸﾞ 1
38 NROLP0038QSZZ AP EQ C
DUP delivery roller [AR-M205] DUP 排紙ﾛｰﾗｰ
39 LFRM-0027QSZ2 AS EQ N C
Delivery frame 排紙ﾌﾚ - ﾑ
40
PFILZ0004QSZZ AM EG B
Ozone filter [AR-160M/AR-M160/AR-M205/AR-5220] ｵｿﾞﾝﾌｨﾙﾀｰ
PFILZ0008QSZZ AL EB B
Ozone filter 20 [AR-200M] ｵｿﾞﾝﾌｨﾙﾀｰ 20
41 PMLT-0027QSZZ AC DJ C
Cleaning fan cushion ｸ - ﾘﾝｸﾞﾌｧﾝﾓﾙﾄ
42 XEBSD20P06000 AA DD C
Screw(2×6) ﾋﾞｽ
43 NFANP0009QSZZ AT EZ N B
Cooling fan ｸ - ﾘﾝｸﾞﾌｧﾝ
44 PDUC-0003QSZ1 AG DX C
Cleaning fan duct ｸｰﾘﾝｸﾞﾌｧﾝﾀﾞｸﾄ
45 PGIDM0062QSZ1 AP EQ N C
Delivery upper paper guide 20 排紙上ﾍﾟｰﾊﾟｰｶﾞｲﾄﾞ 20
46 NROLP1122FCZZ AF DS C
PS upper roller [AR-M205] PS 上ﾛｰﾗｰ
47
PGIDM0040QSZ2 AK DX N C
Delivery lower paper guide
[AR-160M/AR-M160/AR-M205/AR-5220] 排紙下ﾍﾟｰﾊﾟｰｶﾞｲﾄﾞ
PGIDM0063QSZ1 AP EQ C
Delivery lower paper guide 20 [AR-200M] 排紙下ﾍﾟｰﾊﾟｰｶﾞｲﾄﾞ 20
48 MSPRT0229GCAZ AC DJ C
FU spring R [AR-M205] FU ﾊﾞﾈ R
50 XEBSD30P08000 AA DD C
Screw(3×8) ﾋﾞｽ
51 CSFTZ0023QS02 AH DX C
Shiftier shaft ｼﾌﾀｰｽﾗｽﾄｼｬﾌﾄ
52 MSPRD0144QSZZ AC DJ C
Delivery earth spring B 排紙ｱｰｽﾊﾞﾈ B
53 XRESP40-06000 AA DD C
E type ring E ﾘﾝｸﾞ
54 LSTPP0003QSZ1 AC DJ C
Shiftier stopper ｼﾌﾀｰｽﾄｯﾊﾟｰ
55 MSPRT0107QSZZ AC DJ C
Shiftier return spring ｼﾌﾀｰ復帰ﾊﾞﾈ
56 NGERH0067QSZZ AD DJ C
Shiftier gear(24T) ｼﾌﾀｰｷﾞﾔｰ
57 NGERH0068QSZ1 AD DJ C
Shiftier gear(50T) ｼﾌﾀｰｷﾞﾔｰ
58 CPLTM0075QS01 AL EB C
Shiftier drive plate ｼﾌﾀｰ駆動板
59 RMOTS0040QSZZ AR EQ N B
Shiftier motor ｼﾌﾀｰﾓｰﾀｰ
60 XHBSF30P05000 AA DD C
Screw(3×5) ﾋﾞｽ
61 CPWBF0147QSE3 AL EB N E
Shifter HP sensor PWB ｼﾌﾀｰ HP ｾﾝｻｰ基板
62 XRESP30-06000 AA DD C
E type ring E ﾘﾝｸﾞ
64 DHAI-0325QSZZ AD DJ N C
Delivery tray unit harness 排紙ﾄﾚｲﾕﾆｯﾄﾊｰﾈｽ
71 NROLP0104QSZZ AC DJ N C
Delivery roller 排紙従動ﾛｰﾗｰ
72 LHLDW0086QSZZ AB DJ C
Holder ﾎﾙﾀﾞｰ
73 XHBSD30P08000 AA DD C
Screw(3×8) ﾋﾞｽ
74 LBNDJ0013FCZ1 AE DJ C
Cable band ｹｰﾌﾞﾙﾊﾞﾝﾄﾞ
75 PSHEZ0446QSZZ AB DJ N C
Delivery sheet 排紙ﾏｲﾗｰ
(Unit)
901
CFRM-0027RS74 BQ LP N E
Delivery frame unit SIMP [AR-200M] 排紙ﾌﾚｰﾑﾕﾆｯﾄ SIMP
CFRM-0027RS72 BP LP N E
Delivery frame unit SIMP [AR-160M/AR-M160/AR-5220] 排紙ﾌﾚｰﾑﾕﾆｯﾄ SIMP
CFRM-0027RS73 BQ LP N E
Delivery frame unit DUP [AR-M205] 排紙ﾌﾚｰﾑﾕﾆｯﾄ DUP
