Quick Reference Guide: AR-M237/M277
Pre-Setup: Tools, Documentation, & Admonitions
Toolbox Basics
Mechanical
• Screwdriver, Phillips #2
• Screwdriver, Flat #1
• Wrench, 1.5mm Hex head
• Feeler gauges
Electrical
• Voltmeter
• ESD wrist or ankle strap
• Approved surge suppressor
• 30x lighted viewing device
Miscellaneous
• Clean, soft, lint-free cloths
• Alcohol
Special Tools & Service Documentation
* Optional equipment available for system
Electrical/Electronic Component
Admonitions
!
WARNING: Electrical hazard.
Employ proper precautions when
working with high-voltage electrical
equipment.
CAUTION: Improper handling of
electronic components can damage
the equipment.
Properly ground and wear an
electro-static device (ESD) on your
wrist or ankle when working with
electronic modules. Similarly, use
anti-static bags to protect electronic
components during storage or
shipping.
E
S
D
Material Safety Data Sheets (MSDSs)*
* Download MSDSs at http://www.sharp-service.com
Laser Admonition
For your protection, do
not remove protective
covers or bypass safety
interlocks.
2
SM-AR-FX7
Code: 00ZARFX//A1E
*AR-FX7, Super G3 Fax Kit
SM-0AR-FN5N
Code: 00ZARFN5//A1E
*AR-FN5N, Finisher/Stapler
SM-AR-NS2
Code: 00ZARNS2//A1E
*AR-NS2, Network Scanning
Kit
SM-AR-P17
Code: 00ZARP17//A1E
*AR-P17, Print Controller
PG-ARM-237/M277
Code: 00ZARM277/P1E
AR-M237/M277, Parts Guide
CD-ARM-237/M277
Code: 00ZARM277/C1E
AR-M237/M277, Circuit
Diagram
SM-ARM-237/M277
Code: 00ZARM277/A1E
AR-M237/M277, Service
Manual
Part NumberDescription
F-31201Drum CartridgeAR-271DR
F-30981DeveloperAR-271MD
F-00981Toner CartridgeAR-270MT
MSDS No.DescriptionProduct Code
