82
APPENDIX
*1 First copy time is measured with original on the document glass in full ready condition with fuser at operating temperature and
mirror motor at operating speed, actual time may vary based on environment conditions.
*2 The warm-up time may vary depending on the power-supply voltage, ambient temperature, and other operating conditions.
Weight Approx. 55 kg (121.3 lbs.) (Not includes toner cartridge)
Dimensions
623 mm (W) x 615 mm (D) x 786 mm (H)
(24-17/32" (W) x 23-13/64" (D) x 30-15/16" (H))
Operating conditions Temperature: 15°C to 30°C (59°F to 86°F), Humidity: 20% to 85%
Noise level
Sound Power Level L
wA(1B=10dB)
Copying: 6.3[B] (AR-M256)
Copying: 6.5[B] (AR-M316)
Standby: 3.2[B] (AR-M256, AR-M316)
Sound Pressure Level L
pA (bystander positions)
Copying: 47[dB(A)] (AR-M256)
Copying: 51[dB(A)] (AR-M316)
Standby: 16[dB(A)] (AR-M256, AR-M316)
Sound Pressure Level LpA (operator position)
Copying: 50[dB(A)] (AR-M256)
Copying: 52[dB(A)] (AR-M316)
Standby: 16[dB(A)] (AR-M256)
Standby: 17[dB(A)] (AR-M316)
Noise emission measurement in accordance with ISO 7779.
Emission concentration
(measured according to
RAL-UZ62: Editon Jan.
2002)
Ozone: 0.02 mg/m
3
or less
Dust: 0.075 mg/m
3
or less
Styrene: 0.07 mg/m
3
or less
As a part of our policy of continuous improvement, SHARP reserves the right to make design and specification
changes for product improvement without prior notice. The performance specification figures indicated are
nominal values of production units. There may be some deviations from these values in individual units.
Note
