AX1500J(S)
6
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
[2] CABINET PARTS
ELECTRIC PARTS
!
1-7 DPWBFC593WRUZ BS Inverter unit assembly
1-8 QACC-A178WRZZ AQ Power supply cord
1-9 DPWB-A786DRKZ BN Control unit
1-11 FPWBFA448WRKZ AT Noise filter unit
1-14 RTRNPA170DRZZ AY Transformer
1-10 QFS-CA026WRZZ AH Fuse F10A
1-20 RMOTEA462WRZZ AW Fan motor
1-6 QSW-MA086WRE0 AF Dew tray switch
1-26 RMOT-A034WRZZ AU Fan motor (Cooling)
CABINET PARTS
7-1 FCABDA055WRWZ AX Back plate assembly
7-2 FDAI-A330WRYZ AZ Bottom plate assembly
7-3 GCABUB169WRPZ BK Outer case cabinet
MECHANICAL PARTS
8-4 GCOVPA021WRFZ AF Drip tray cover
8-5 GCUPPA024WRTZ Drip tray
8-6 GLEGPA108WRFZ AF Back shade guide
8-7 LHLDPA006WRFZ AL PWB holder
8-8 PCUS-A221WREZ AC Cushion
8-9 PGID-A090WRFZ AL Dew tray guide L
8-10 PGID-A091WRFZ AL Dew tray guide R
8-11 PPAC-A069WREZ AF Stopper
8-12 PSKR-A496WRFZ AH Dew shield
* 8-19 FHNG-A389WRYZ BE Left hinge assembly
* 8-20 FHNG-A390WRYZ BE Right hinge assembly
8-29 NFANJA065WRFZ AK Fan blade
8-30 PCUS-A199WREZ AE Cushion
8-31 PDUC-B075WRFZ AP Fan duct
8-54 LANGKB358WRPZ AF Motor angle
8-56 LBNDKA166WREZ AD Wire holder
* 8-58 MCAMPA171WRMZ AN L door cam
* 8-59 MCAMPA173WRMZ AN R door cam
* 8-60 MSPRTA258WREZ AK Door spring-R
*
8-61 MSPRTA259WREZ AK Door spring-L
8-62 PCOV-A109WRPZ AH Filter cover
8-63 PCOV-A155WRFZ AT Exhaust cover
8-65 PCUS-A204WREZ AC Cushion
8-66 PCUS-A205WREZ AC Cushion
8-67 PCUS-A206WREZ AC Cushion
8-68 MLEVPA285WRFZ AB Lever
8-69 MSPRCA177WREZ AC Dew tray spring
8-72 PCUS-A212WREZ AC Cushion
8-75 TCAUHA344WRRZ AF Micro caution
8-77 PCUS-A217WREZ AC Cushion
8-79 PCUS-A223WREZ AB Dew tray guide cushion
8-89 PCUS-A265WREZ AD Cushion
8-94 PCUS-A234WREZ AC Cushion
8-95 PCUS-A235WREZ AE Cushion
8-98 GCAP-A014WRFZ AN Steam cap
8-112 PPAC-A143WREZ AP Steam duct packing
8-115 PCUS-A240WREZ AC Cushion
8-120 LANGQA731WRFZ AD Dew tray SW angle
8-127 PSPAJA011WRFZ AF Side spacer
8-135 TCAUAA332WRRZ AF Caution label
8-136 PCUS-A236WREZ AC Cushion
8-151 PSHEPB458WREZ AE Water proof sheet
8-152 PCUS-A282WREZ Cushion
SCREW, WASHER AND NUT
9-1 XOTS740P10000 AB Screw; 4mm x 10mm
9-2 XOTS740P08000 AA Screw; 4mm x 8mm
9-3 LX-BZA138WREZ AB Special screw
9-4 XEBS730P10000 AA Screw; 3mm x 10mm
9-5 XHTS740P08000 AC Screw; 4mm x 8mm
9-7 XETS740P08000 AA Screw; 4mm x 8mm
9-8 XEPS740P25K00 AC Screw; 4mm x 25mm
9-24 XEPS740P10000 AA Screw ;4mm x 10mm
9-27 LX-NZA057WREZ AG Special nut
9-32
LX-CZA088WREZ AB Special screw (Knock type)
9-34 LX-BZA148WREZ AC Special screw
9-36 XEPS740P06000 AA Screw; 4mm x 6mm
9-37 XOBS740P30000 AC Screw; 4mm x 30mm
9-44 XHPS740P10XS0 AC Screw; 4mm x 10mm
9-46 LX-CZ0052WRE0 AA Special screw
