Sharp AY-XPC12PU - Page 37

5
AY-XPC12PU
No. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
[1] INDOOR UNIT PARTS
3 CCYC-E043JBKZ N CYCLE ASS'Y
3-1 PFPFPE084JBEZ TUBE INSULATOR
3-2 PSEN-A081JBKZ FLARE NUT ASS'Y
3-3 PPLT-A933JBFZ N SIDE COVER L
3-4 PCOV-C002JBFZ N SIDE COVER R
3-5 PSEN-A080JBKZ FLARE NUT ASS'Y
3-6 LHLD-B217JBFA THERMISTOR HOLDER
3-7 PFPFPD317JBEZ CABINET INSULATOR J
4-1 PBOX-A588JBFZ N CONTROL BOX
4-2 DSGY-F168JBKZ N CONTROL BOARD UNIT(AY-XPC2PU)
4-2 DSGY-F1
69JBKZ N CONTROL BOARD UNIT(AY-XPC9PU)
4-2 DSGY-F170JBKZ
N
CONTROL BOARD UNIT(AY-XPC7PU)
4-3 LHLD-B219JBFA N LED HOLDER
4-4 LHLD-B230JBFA N CONTROL BOX SUPPORT
4-5 DBOX-A157JBYZ N CONTROL BOX ASS'Y
4-6 PCOV-B946JBWZ TERMINAL COVER
4-7 PCOV-B967JBWZ TERMINAL COVER 2
4-8 PFPFPE683JBEZ INSULATOR
4-10 QTANZA090JBZZ TERMINAL BOARD
4-11 RH-HXA178JBZZ N THERMISTOR
4-12 PCOV-C009JBWZ N TERMINAL COVER
4-13 PCOV-C008JBFA N SW COVER
4-14 LHLD-B234JBFA N HOLDER
4-15 LHLD-B235JBFA N CORD HOLDER
4-16 FSGY-B717JBKZ N DISPLAY BOARD UNIT
5-1 LPLT-A0
58JBPZ HOSE HOLDER
5-2 PHOS-A052JBEZ DRAIN HOSE
5-3-1 CKITTA159AKKZ PLASMACLUSTER UNIT
5-3-2 LHLD-B214JBFA N CLUSTER HOLDER
5-3-3 PCOV-C005JBFA N CLUSTER COVER
5-3-4 QW-VZG741JBZZ LEAD WIRE
5-4 DSRA-A406JBKZ N DRAIN PAN SUB ASS'Y
5-5 MARMPA078JBFA ARM
5-6 MJNTPA192JBFA N LOUVER LINK
5-7 MLOV-A577JBFA N HORAIZONTAL LOUVER
5-8 MLOV-A569JBFA VERTICAL LOUVER
5-9 NBRG-A026JBFA LOUVER BUSHING
5-10 NBRG-A038JBFA BEARING C
5-11 PDAI-A293JBFA N MOTOR
BRACKET
5-12 PGUMMA381JBEZ DRAIN PLUG
5-13 PSTB-A007JBFA N STABILIZER R
5-14 PSTB-A008JBFA N STABILIZER L
5-15 RMOT-A236JBZZ LOUVER MOTOR
5-16 TLAB-F805JBRZ N LABEL
5-17 GGAD-A077JBTA N WIRE GUARD L
5-18 GGAD-A078JBTA N WIRE GUARD R
5-19 LHLD-B215JBFA N GUARD HOLDER L
5-20 LHLD-B216JBFA N GUARD HOLDER R
CYCLE PARTS
CONTROL BOX UNIT PARTS
DRAIN PAN PARTS
