6
AY-XPC12PU
6-1 GWAK-A409JBFA N FRONT PANEL L
6-2 HDEC-B228JBFA N DECORATION PANEL L
6-3 DWAK-B050JBKZ N FRONT PANEL R ASS'Y
6-3-1 HDEC-B229JBFA N DECORATION PANEL R
6-3-2 HDECQA494JBEA N DISPLAY PANEL
6-3-3 TLABCE007JBRZ N WIRING DIAGRAM
6-3-4 TCAUSA001JBRZ UL WARNING LABEL-1
6-3-5 TCAUSA002JBRZ UL WARNING LABEL-2
6-4 DPNL-A126JBKZ N OPEN PANEL ASS'Y
7-1 CHLD-A122JBKZ BEARING ASS'Y
7-2 CMOT-A562JBKZ N FAN MOTOR SUB ASS'Y
7-3 DCHS-A835JBKZ N CA
BINET ASS'Y
7-4 PCOV-B996JBFZ MOTOR COVER
7-5 PCOV-C007JBWZ N CABLE HOLDER
7-6 NFANCA150JBEZ N CROSS FLOW FAN
7-7 PCOV-C011JBFZ N PIPE HOLDER
7-8 PFILMA283JBEA N AIR FILTER
7-9 PGID-A203JBFA N FILTER GUIDE
7-10 PPLTNA143JBWZ MOUNTING ANGLE
7-11 TSPC-H659JBRA N NAME LABEL(AY-XPC12PU)
7-11 TSPC-H693JBRA N NAME LABEL(AY-XPC9PU)
7-11 TSPC-H777JBRA N NAME LABEL(AY-XPC7PU)
[2] ACCESSORY PARTS
1-1 CRMC-A868JBEZ REMOTE CONTROL
1-2 LHLD-A484JBFA HOLD
ER
1-3 DHLD-A073JBKZ N CORD HOLDER ASSY
1-4 FFZK-A256JBKZ SCREWS KIT
1-5 UBATUA027JBE0 BATTERY PACK
1-7 TINS-B453JBRZ INSTALLATION MANUAL
1-8 TINSEA760JBRZ OPERATION MANUAL
[3]PACKING PARTS
2-1 SPADBA637JBEZ PACKING PAD L
2-2 SPADBA638JBEZ PACKING PAD R
2-3 SPAKCE303JBEZ PACKING CASE
2-4 TLABMB229JBRZ N PRODUCT LABEL(AY-XPC12PU)
2-4 TLABMB249JBRZ N PRODUCT LABEL(AY-XPC9PU)
2-4 TLABMB268JBRZ N PRODUCT LABEL(AY-XPC7PU)
2-5 TLAB-F722JBR
Z NO CLAMP LABEL
FRONT PANEL & OPEN PANEL PARTS
CABINET & UNIT PARTS
N
