AY-XPC15PU
3
NO. PARTS CODE PRICE RANK NEW MARK PART RANK DESCRIPTION
[1] INDOOR UNIT PARTS
3 CCYC-E038JBKZ
CA N CYCLE ASS'Y(AY-XPC15PU)
3 CCYC-E039JBKZ
CG N CYCLE ASS'Y(AY-XPC18PU,AY-XP24PU)
3-1 DCOV-A389JBKZ
AL N COVER-L ASS'Y
3-2 PCOV-B987JBFZ
AH N SIDE COVER R
3-3 PGID-A200JBFA AG N EVA COVE L
3-4 PGID-A201JBFA
AG N EVA COVE R
3-5 PFPFPE436JBEZ
AK INSULATOR
3-6 PSEN-A086JBKZ
AP FLARE NUT ASS'Y
3-7 LHLD-B207JBFZ
AE N THERMISTOR HOLDER
3-8 PSEN-A080JBKZ
AH FLARE NUT ASS'Y
4-1 DBOX-A136JBKZ
BR N CONTROL BOX ASS'Y(AY-XPC15PU)
4-1 DBOX-A137JBKZ
BL N CONTROL BOX ASS'Y(AY-XPC18PU)
4-1 DBOX-A149JBKZ
BQ N CONTROL BOX ASS'Y(AY-XP24PU)
4-1-1 DSGY-F028JBKZ
BL N CONTROL BOARD UNIT(AY-XPC15PU)
4-1-1 DSGY-F032JBKZ
BL N CONTROL BOARD UNIT(AY-XPC18PU)
4-1-1 DSGY-F121JBKZ
BL N CONTROL BOARD UNIT(AY-XP24PU)
4-1-2 GBTN-A015JBFA AC N BUTTON
4-1-3 LHLD-A539JBFA
AE CORD HOLDER
4-1-4 LHLD-B210JBFA
AE N DISPLAY HOLDER
4-1-5 PCOV-B854JBWZ
AV CONT.BOX COVER A
4-1-6 PCOV-C099JBWZ
AH N CONT.BOX COVER B
4-1-7 PCOV-B858JBWZ
AY TERMINAL COVER
4-1-8 QTANZA090JBZZ
AR N TERMINAL BOARD
4-1-9 RH-HXA165JBZZ
AS THERMISTOR
4-1-10 PBOX-A587JBFA
AX N CONTROL BOX
4-3 PCOV-B988JBFA
AE N DISPLAY COVER
4-4 PCOV-B989JBFZ AC N LED COVER
4-5 LHLD-B233JBFA
AC N CORD HOLDER
5-1 LPLT-A058JBPZ AC HOSE HOLDER
5-2 PHOS-A052JBEZ
AM DRAIN HOSE
5-3 CKITTA087JBKZ
BN N CLUSTER ASS'Y
5-3-1 CKITTA133AKKZ
BM PLASMACLUSTER UNIT
5-3-2 PCOV-B990JBFA
AC N SCREW COVER
5-3-3 QW-VZG595JBZZ
AK LEAD WIRE
5-3-4 LHLD-B211JBFA
AG N HOLDER
5-3-5 LHLD-B212JBFA
AG N COVER
5-4 DCOV-A390JBKZ
AV N FRONT PANEL ASS'Y
5-5 DSRA-A403JBKZ
BC N DRAIN PAN SUB ASS'Y
5-6 GGAD-A076JBTA AT N WIRE GUARD
5-7 MARMPA078JBFA
AD N ARM
5-8 MJNTPA191JBFA
AE N LOUVER LINK
5-9 MLOV-A574JBFA
AQ N HORAIZONTAL LOUVER
5-10 MLOV-A562JBFA
AE VERTICAL LOUVER
5-11 NBRG-A026JBFA
AB LOUVER BUSHING
5-12 NBRG-A038JBFA
AC BEARING C
5-13 PDAI-A291JBFA
AD N MOTOR BRACKET
5-14 PGUMMA381JBEZ
AF DRAIN PLUG
5-15 RMOT-A223JBZZ
AS LOUVER MOTOR
6-1 CWAK-E203JBKZ
AX N FRONT PANEL L ASS'Y
6-1-1 HDEC-B226JBFA
AL N DECORATION PANEL L
6-2 CWAK-E202JBKZ BA N FRONT PANEL R ASS'Y
6-2-1 HDEC-B227JBFA
AL N DECORATION PANEL R
6-2-2 TCAUSA002JBRZ
AD UL WARNING LABEL -2
6-2-3 TLABCE002JBRZ
AD N WIRING DIAGRAM
7-1 CMOT-A561JBKZ
BM N FAN MOTOR SUB ASS'Y
7-2 CHLD-A122JBKZ
AG BEARING ASS'Y
7-3 DCHS-A833JBKZ
BD N CABINET SUB ASS'Y
7-4 PCOV-B996JBFZ
AE N MOTOR COVER
7-5 DPNL-A123JBKZ
BD N OPEN PANEL ASS'Y
7-6 LHLD-B213JBFA
AD N STOPPER
7-8 NFANCA149JBEZ
BD N CROSS FLOW FAN
7-9 PCOV-B994JBFA
AF N PIPE HOLDER
7-10 PCOV-B851JBWZ AV BOX COVER
7-11 PCOV-B995JBFA
AP N GRILL
7-12 PCOV-B983JBWZ
AE N CABLE HOLDER
7-13 PFILMA282JBEA
AL N AIR FILTER
7-14 PGID-A202JBFA
AH N FILTER GUIDE
7-15 PPLTNA134JBWZ
AX MOUNTING ANGLE
7-16 TSPC-H648JBRA
AF N NAME LABEL(AY-XPC15PU)
7-16 TSPC-H655JBRA
AF N NAME LABEL(AY-XPC18PU)
7-16
7-17
7-18
TSPC-H815JBRA
TCAUSA003JBRZ
PGID-A127JBFZ
UL WARNING LABEL-3
GUIDE
AF N NAME LABEL(AY-XP24PU)
N
CABINET & UNIT PARTS
CYCLE PARTS
CONTROL BOX
DRAIN PAN PARTS
FRONT PANEL PARTS
N
AF
AG
