Sharp AY-XPC18PU Service Manual

AY-XPC15PU
4 – 4
[2] PLASMACLUSTER UNIT
1. pen the open panel.
2. Remove the vertical louvre.
3. Pull wire guard from drain pan hook.
4. lide the wire guard to right and remove it.
ertical louvre
5. Remove the 2 screw covers.
nsert a flat t pe screw driver to hole of screw cover.
. Unscrew 2 screws.
. lide Plasmacluster cover to the back.
. Replace the Plasmacluster unit.
isconnect the connector and replace Plasmacluster unit.
Plasmacluster cover
Plasmacluster unit
Connector
pen panel
