AY-XPC15PU
4 â 3
1 .Unscrew the 2 screws fixing drain pan and remove it.
1 .Unscrew the 2 screws and remove the motor bracket.
19. lide the vertical louvre and remove it
20.Unscrew the 3 screws fixing side cover and side cover R.
otor bracket
ertical louvre
21.Release the hook of the motor cover from cabinet.
1 .Remove the control box b releasing the upper hook and pulling
out.
ook
22. ake out the motor and cross flow fan.
23.Unscrew the screw of the cross flow fan and remove it.
otor and cross flow fan
24.Remove the pipe holder.
î Push the hook of the pipe holder and remove it b pulling lower
part.
ook of the pipe holder
pull
ediskcaedistnorF
otor cover
To Next Page
