Introduction
Main Unit (Rear)
Main Unit (Front)
Major Components
58
6
2 1 4 3
7
1 2
3
4
75 6
8
9
COMPONENT VIDEO OUT jacks
(p. 15)
VIDEO output jack (p. 16)
2CH AUDIO output jacks (p. 17)
ETHERNET terminal (p. 18)
HDMI OUT terminal (p. 14)
BD STORAGE/SERVICE terminal
BD STORAGE (pp. 25, 42)
SERVICE for software (p. 43)
DIGITAL AUDIO OUT OPTICAL
terminal (p. 17)
Cooling fan
The cooling fan operates while the
power to the Player is on.
AC IN terminal (p. 19)
1
2
3
4
5
6
7
8
9
POWER (p. 20)
Remote control sensor (p. 19)
Disc tray (p. 23)
OPEN/CLOSE (p. 23)
ON indicator (p. 20)
STANDBY indicator (p. 20)
Front panel display (p. 20)
BD/DVD/CD mode indicator (p. 20)
1
2
3
4
5
6
7
8
