Sharp BD-HP90S - Page 33

BD-HP90S
5
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
FB9002 RBLN-A018WJZZY AA V Ferrite Core
FB9003 RBLN-A018WJZZY AA V Ferrite Core
FB9004 RBLN-A018WJZZY AA V Ferrite Core
FB9005 RBLN-A018WJZZY AA V Ferrite Core
FB9006 RBLN-A018WJZZY AA V Ferrite Core
FB9007 RBLN-A018WJZZY AA V Ferrite Core
FB9008 RBLN-A018WJZZY AA V Ferrite Core
FB9011 RBLN-A018WJZZY AA V Ferrite Core
FL2501 RFILZA003WJPZY AD V Filter
FL7201 RFILNA119WJZZY AC V Filter
FL7801 RFILNA119WJZZY AC V Filter
FL7802 RFILNA119WJZZY AC V Filter
FL7803 RFILNA119WJZZY AC V Filter
FL7804 RFILNA119WJZZY AC V Filter
FL7805 RFILNA119WJZZY AC V Filter
FL7806 RFILNA119WJZZY AC V Filter
FL7807 RFILNA119WJZZY AC V Filter
FL7808 RFILNA119WJZZY AC V Filter
FL7810 RFILNA119WJZZY AC V Filter
FL7811 RFILNA119WJZZY AC V Filter
FL7814 RFILNA119WJZZY AC V Filter
FL7815 RFILNA119WJZZY AC V Filter
FL7816 RFILNA119WJZZY AC V Filter
FL7820 RFILNA119WJZZY AC V Filter
IC2501 VHIPST8431N-1Y AC V IC IC-PST8431NR
IC2502 VHIPST8220N-1Y AC V IC IC-PST8220NR
IC2503 VHIPST8246N-1Y AC V IC IC-PST8246NR
IC2504 RH-IXC893WJQZQ - - IC
Note This IC cannot do an individual exchange.
The relevant PWB must be entirely replaced with
new one.
IC2505 VHIT7SET08F1EY AD V IC TC7SET08F(TE85L,JF
IC3002 VHIBA10358V-1Y AD V IC BA10358FV-E2
IC3003 VHIAZ1117HA-1Y AD V IC AZ1117H-ADJTRE
IC3004 VHITC7WH74U-1Y AF V IC TC7WH74FU(TE12L,F)
IC3005 VHITC7SH04U-1Y AE V
IC TC7SH04FU(TE85L)
IC7201 VHIPCA9517+-1Y AK V IC PCA9517DP,118
IC7202 VHIPQ1LAX95-1Y AD V IC PQ1LAX95MSPQ
IC7203 VHIMP62055/-1Y AD V IC MP62055EJ-LF-Z
IC7204 VHILCX125FT-1Y AD V IC TC74LCX125FT(EL,K)
IC7207 VHIMP62055/-1Y AD V IC MP62055EJ-LF-Z
IC7208 RH-IXD206WJQZQ - N - IC
Note This IC cannot do an individual exchange.
The relevant PWB must be entirely replaced with
new one.
IC7802 RH-IXD158WJQZQ AY V IC EDJ1108DBSE-DJ
IC7803 RH-IXD158WJQZQ AY V IC EDJ1108DBSE-DJ
IC7804 RH-IXD158WJQZQ AY V IC EDJ1108DBSE-DJ
IC7805 RH-IXD158WJQZQ AY V IC EDJ1108DBSE-DJ
IC7806 RH-IXD121WJQZQ - - IC K9F2G08U0B-PCB
Note This IC cannot do an individual exchange.
The relevant PWB must be entirely replaced with
new one.
IC9001 VHIMP28254+-1Y AG V IC MP28254EL-LF-Z
IC9002 VHIAOZ1016+-1Y AF V IC AOZ1016AI
IC9003 VHIMP2303A+-1Y AF V IC MP2303ADN-LF-Z
IC9004 VHIAOZ1016+-1Y AF V IC AOZ1016AI
IC9005 VHIPQ200WN3-1Y AE V IC PQ200WN3MZPH
J7201 QJAKZA053WJQZ AM V Jack
J7202 VHPGP1F55TKVY AF V Photo Diode
J9002 QJAKCA027WJPZ N V Jack
L3001 VPCUN4R7MR23NY AB V Coil Peaking 4.7µH
L3002 VPCUN4R7MR23NY AB V Coil Peaking 4.7µH
L7201 RCILFA112WJZZY AC V Coil
L7205 VPCUN100KR42NY AB V Coil Peaking 10µH
L7207 RCILFA112WJZZY AC V Coil
L9001 RCILPB126WJQZY AD V Coil
L9002 RCILPB115WJQZY AC V Coil
L9003 RCILPB126WJQZY AD V Coil
L9004 RCILPB115WJQZY AC V Coil
LUG9001 QLUGHA006WJZZY AC V
Lug
LUG9002 QLUGHA006WJZZY AC V Lug
LUG9003 QLUGHA006WJZZY AC V Lug
LUG9004 QLUGHA006WJZZY AC V Lug
P2502 QPLGN0056CEZZY AD V Plug
P7202 QPLGN0570FJZZY AD V Plug
P7207 QPLGN0060CEZZY AE V Plug
Q2501 VSRT1N241C/-1Y AB V Transistor RT1N241C-T112-1
Q2502 VS2SC3928AR-1Y AB V Transistor 2SC3928A-T112-1R
Q2503 VSRT1N241C/-1Y AB V Transistor RT1N241C-T112-1
Q2504 VSRT1N241C/-1Y AB V Transistor RT1N241C-T112-1
Q2505 VSRT1N241C/-1Y AB V Transistor RT1N241C-T112-1
Q7201 VSRT1N241C/-1Y AB V Transistor RT1N241C-T112-1
Q7202 VS2SA1530AR-1Y AB V Transistor 2SA1530A-T112-1R
Q9003 VSRT1N241C/-1Y AB V Transistor RT1N241C-T112-1
[2] DSETV0218TEVZ (MAIN Unit)
