CD-C1W,CP-C1W
– 50 –
1 P06 TRY SW3 Input CD
2 P07 TRY SW4 Input CD
3 SO0 COIN Output CD command
4 SI0 SQ_OUT Input CD Q code data
5 SCK0 CQ CK Output CD seria clock
6 SO1 COM Output DISP microcomputer control line
7 SI1 DAT Input DISP microcomputer control line
8 SCK1 SCK Output DISP microcomputer control line
9 P16 STB Output DISP microcomputer control line
10 P17 DISP-RES Output DISP microcomputer control line
11 INT0 WRQ Input CD WRQ input
13 P74 DRF Input CD DRF input
14 P75 PU-IN SW Input CD PU-IN SW input
19 AN0 63 Hz Input Input for spectrum analyzer 63 Hz
20 AN1 250 Hz Input Input for spectrum analyzer 250 Hz
21 AN2 1 kHz Input Input for spectrum analyzer 1 kHz
22 AN3 4 kHz Input Input for spectrum analyzer 4 kHz
23 AN4 16 KHZ Input Input for spectrum analyzer 16 KHz
24 AN5 POSISTOR Input Input for temperature detection
25 AN6 TUNER SM Input For tuner input detection
26 AN7 SP DET Input For speaker output detection
27 INT1 SYS-STOP Input Power failure detection input HOLD mode
28 INT2 SP PROTECT Input Speaker ovecurrent detection input PROTECT mode
29 INT3 Input
30 PA0 B-FP SW Input Tape B-FPSW
31 PA1 A-FP SW Input Tape A-FP SW
32 PA2 T2 CrO SW Input Tape T2 CrO SW
33 PA3 T1 CrO SW Input Tape T1 CrO SW
34 PA4 T2 RUN Input Tape T2 RUN pulse
35 PA5 T2 PLAY SW Inputt Tape T2 PLAY SW
36 PA6 Voltage selection Output Voltage selection
37 PA7 MOTOR Output Tape motor output
38 PB0 T2 SOL Output For tape T2 sol drive
39 PB1 T1 SOL Output For tape T1 sol drive
40 PB2 T1 RUN Input Tape T1 RUN pulse
41 PB3 T1PLAY SW Input Tape T1 PLAY SW
42 PB4 HI SPEED Output Tape HIGHSPEED state "L" "H"
43 PB5 BIAS Output Tape REC bias OSC
44 PB6 BEET CANCEL Output Tape bias frequency selection; Usually "L"
45 PB7 PB/REC Output Tepe PB/REC signal selection
46 PC0 PB EQ Output Tape PLAYBACK side tape EQ selection NOR/CrO
47 PC1 REC EQ Output Tape record Amp EQ selection signal NOR/CrO
48 PC2 REC MUT Output Tape
49 PC3 T1/T2 Output Tape T1 : "H" T2 : "L"
50 PC4 DUBBING Output Tape
51 PC5 DOLBY ON/OFF Output Tape Specification
52 PC6 DOLBY PLAY/REC Output Tape
53 PC7 PB MUT Output Tape
54 PD0 SP RELAY Outout For speaker relay drive
55 PD1 FUN MOTOR Output For fan motor drive
58 PD2 TUNER MUT Output Tuner
IC201 RH-iX0210AWZZ: System Microcomputer (IX0210AW)(1/2)
Port Name Terminal NamePin No. Input/Output
Function
