CD-C1W,CP-C1W
– 51 –
59 PD3 SRS PASS Output SRS Specification
60 PD4 SRS 3D/MONO Output SRS Specification
61 PD5 SRS A Output SRS Specification
62 PD6 SRS B Output SRS Specification
63 PD7 SRS INH Output SRS Specification
64 PE0 Q-SDA Output Q-sound
65 PE1 Q-SCL Output Q-sound Not specified
66 PE2 Q-STRB Output LC75396E, LV1035M, LA1832, LC72131,LC72720
67 PE3 ENA Output LC75396E, LV1035M, LA1832, LC72131,LC72720
68 PE4 CE Output LC75396E, LV1035M, LA1832, LC72131,LC72720
69 PE5 CL Output LC75396E, LV1035M, LA1832, LC72131,LC72720
70 PE6 SD Input LC75396E, LV1035M, LA1832, LC72131,LC72720
71 PE7 DI Input LC75396E, LV1035M, LA1832, LC72131,LC72720
72 PF0 DO Output LC75396E, LV1035M, LA1832, LC72131,LC72720
73 PF1 VOICE CANCEL Output Karaoke function "H": ON
74 PF2 LINE MUT Output Line out MUT signal
75 PF3 SYS MUT Output Front Amp MUT signal
76 PF4 REAR MUT Output Rear Amp MUT signal
77 PF5 CENTER MUT Output Center Amp MUT signal
78 PF6 S.W.MUT Output Superwoofer Amp MUT signal
79 PF7 POWER Output Set power control, ON "H", "OFF"L"
80 PL6 9K/10K Input Span selection 9K "H" 10K "L"
81 PL5 MIC provided/not provided Input MIC existence/nonexistence detection Existence "L", Nonexistenece "H"
82 PL4 — Input
83 PL0 H/P SW Input H. P existence/nonexistence detection
84 PL1 AUT provided/not provided Input Tuner AUT scan function provided/not provided
85 PL2 SRS/Q-SOUND Input Surround SRS/Q-sound selection
86 PL3 Dolby Pro provided/not provided Input Dolby Pro function provided/not provided
87 P30 CD MUT Output CD output MUT signal
88 P31 PCCL Output CD general-use port control signal
91 P32 CD RES Output CD DSP RES signal
92 P33 SL- Output CD SLED -signal
93 P34 SL+ Output CD SLED +signal
94 P35 RWC Output CD RWC
95 P00 CAM SW1 Input CD EH mechanism
96 P01 CAM SW2 Input CD CAM SW
97 P02 CAM SW3 Input CD
98 P03 CAM SW4 Input CD
99 P04 TRY SW1 Input CD EH mechanism
100 P05 TRY SW2 Input CD TRY position detection switch
Port Name Terminal NamePin No. Input/Output
IC201 RH-iX0207AWZZ: System Microcomputer (IX0207AW) (2/2)
Function
