Sharp CD-C1W - Display and Control IC Function Details; IC701 FL Driver Pin Functions (1;2)

CD-C1W,CP-C1W
– 53 –
1 P16/BUZZ DIP_STB Input Serial strobe input for system microcomputer
2 P17/PWM0 NC Output NC
3 P30 LED17 Output LED output H: Lights R-play
4 P31 LED18 Output LED output H: Lights PAUSE
5 P32 LED19 Output LED output H: Lights DISC1
6 P33 LED20 Output LED output H: Lights DISC2
7 P34 LED21 Output LED output H: Lights DISC3
8 P35 LED22 Output LED output H: Lights #
9 P36 LED23 Output LED output H: Lights NATURAL
10 P37 LED24 Output LED output H: Lights b
11 P70/INT0 FL_SET Input FL initial setting input
12 RES DIP_RES Input Reset input
13 XT1/P74 VOL_UP Input Volume jog input UP
14 XT2/P75 VOL_DOW Input Volume jog input DOWN
15 Vss1 Vss — GND
16 CF1 CF_IN Input Main clock ceramic 4.19 MHz
17 CF2 CF_OUT Output Main clock ceramic 4.19 MHz
18 Vdd1 Vdd — Normal power supply
19 P80/AN0 DEST Input Initial setting input
20 P81/AN1 AU_SET Input Audio operation setting input
21 P82/AN2 KEY1 Input Button input 0 to 9
22 P83/AN3 KEY2 Input Button input 10 to 18
23 P84/AN4 KEY3 Input Button input 19 to 27
24 P85/AN5 KEY4 Input Button input 28 to 36
25 P86/AN6 KEY5 Input Button input 37 to 45
26 P87/AN7 KEY6 Input Button input 46 to 54
27 P71/INT1 MAL_UP Input Multi-Button jog input UP
28 P72/INT2/T0IN MAL_DOW Input Multi-jog input DOWN
29 P73/INT3/T0IN REM_IN Input Remote controller input
30 S0/T0 G15 Output Display tube grid drive
31 S1/T1 G14 Output Display tube grid drive
32 S2/T2 G13 Output Display tube grid drive
33 S3/T3 G12 Output Display tube grid drive
34 S4/T4 G12 Output Display tube grid drive
35 S5/T5 G11 Output Display tube grid drive
36 S6/T6 G10 Output Display tube grid drive
37 S7/T7 G9 Output Display tube grid drive
38 S8/T8 G8 Output Display tube grid drive
39 S9/T9 G7 Output Display tube grid drive
40 S10/T10 G6 Output Display tube grid drive
41 S11/T11 G5 Output Display tube grid drive
42 S12/T12 G4 Output Display tube grid drive
43 S13/T13 G3 Output Display tube grid drive
44 S14/T14 G2 Output Display tube grid drive
45 S15/T15 G1 Output Display tube grid drive
46 Vdd3 Vdd-F — Normal power supply for display tube drive
47 S16/PC0 S27 Output Display tube grid drive
48 S17/PC1 S26 Output Display tube grid drive
49 S18/PC2 S25 Outout Display tube grid drive
50 S19/PC3 S24 Output Display tube grid drive
51 VP VP — Negative power supply -30 W for display tube drive
IC701 RH-iX0206AWZZ: FL Driver & Controller (IX0206AW) (1/2)
Port Name
Terminal Name
Pin No.
Input/Output
Function
