CD-C1W,CP-C1W
– 54 –
52 S20/PC4 S23 Output Display tube segment drive
53 S21/PC5 S22 Output Display tube segment drive
54 S22/PC6 S21 Output Display tube segment drive
55 S23/PC7 S20 Output Display tube segment drive
56 S24/PD0 S19 Output Display tube segment drive
57 S25/PD1 S18 Output Display tube segment drive
58 S26/PD2 S17 Output Display tube segment drive
59 S27/PD3 S16 Output Display tube segment drive
60 S28/PD4 S15 Output Display tube segment drive
61 S29/PD5 S14 Output Display tube segment drive
62 S30/PD6 S13 Output Display tube segment drive
63 S31/PD7 S12 Output Display tube segment drive
64 P32/PE0 S11 Output Display tube segment drive
65 P33/PE1 S10 Output Display tube segment drive
66 P34/PE2 S9 Output Display tube segment drive
67 P35/PE3 S8 Output Display tube segment drive
68 P36/PE4 S7 Output Display tube segment drive
69 P37/PE5 S6 Output Display tube segment drive
70 P38/PE6 S5 Output Display tube segment drive
71 P39/PE7 S4 Output Display tube segment drive
72 Vdd4 Vdd-F — Normal proper supply for display tube drive
73 S40/PF0 S3 Output Display tube segment drive
74 S41/PF1 S2 Output Display tube segment drive
75 S42/PF2 S1 Output Display tube segment drive
76 S43/PF3 — Output NC
77 S44/PF4 LED1 Output LED output H: Lights Not defined
78 S45/PF5 LED2 Output LED output H: Lights Not defined
79 S46/PF6 LED3 Output LED output H: Lights F-PLAY
80 S46/PF7 LED4 Output LED output H: Lights STOP
81 S48/PG0 LED5 Output LED output H: Lights FF
82 S49/PG1 LED6 Output LED output H: Lights REW
83 S50/PG2 LED7 Output LED output H: Lights SRS-G
84 S51/PG3 LED8 Output LED output H: Lights SRS-R
85 P00 LED9 Output LED output H: Lights VIRTUAL-G
86 P01 LED10 Output LED output H: Lights VIRTUAL-R
87 P02 LED11 Output LED output H: Lights PHANTOM -G
88 P03 LED12 Output LED output H: Lights PHANTOM -R
89 Vss2 Vss — GND
90 Vdd2 Vdd — Normal power supply
91 P04 LED13 Output LED output H: Lights NORMAL -G
92 P05 LED14 Output LED output H: Lights NORMAL -R
93 P06 LED15 Output LED output H: Lights STEREO -G
94 P07 LED16 Output LED output H: Lights STEREO -R
95 P10/S00 DIP_KEY Output Serial data output for system microcomputer
96 P11/S10/SB0 DIP_DAT Input Serial data input for system microcomputer
97 P12/SCK0 DIP_SCK Input Serial clock output for system microcomputer
98 P13/S01 NC Output NC
99 P14/SI1/SB1 NC Output NC
100 P15/SCK1 NC Outout NC
IC701 RH-iX0206AWZZ: FL Driver & Controller (IX0206AW) (2/2)
Port Name
Terminal Name
Pin No.
Input/Output
Function
