Sharp CD-C410W

PRICE
RANK
DESCRIPTIONNO.
PART CODE NO. PARTS CODE
PRICE
RANK
DESCRIPTION
CD-C410W/C415W/C420W,CP-C410/C415/SR410
– 5 –
8 NFLYC0002AWZZ J AG Flywheel Ass’y [Tape 1]
9 NFLYC0003AWZZ J AH Flywheel Ass’y [Tape 2]
10 MLEVP0024AW01 J AH Lever,FF/REW Roller Ass’y
11 NGERH0027AWZZ J AE Gear,Cam
12 NGERH0028AWZZ J AB Gear,Flywheel
13 NGERH0030AWZZ J AE Gear,Play Idler
14 NGERH0032AWZZ J AC Gear,FF
15 NPLYB0004AWZZ J AB Sensor,Wing
16 MLEVP0026AWZZ J AC Lever,Trigger
17 MLEVP0027AWZZ J AC Lever,Lock [Tape 1]
18 MLEVP0028AWZZ J AC Lever,Eject Obstruct [Tape 1]
19 MLEVP0069AWZZ J AB Lever,Eject Obstruct [Tape 2]
20 LHLDS1001AW01 J AE Holder,Bearing
21 PGIDM0007AWZZ J AC Guide,Cassette [Tape 2]
22 PGIDM0009AWZZ J AC Guide,Cassette [Tape 1]
23 MLEVF0004AWFW J AB Lever,Over Strok [Tape 1]
24 MLEVF0005AW01 J AE Lever,Over Strok Ass’y [Tape 2]
25 MLEVF0006AW01 J AD Lever,Mode Ass’y
26 MLEVF0007AW01 J AC Lever,Idler Ass’y [Tape 1]
27 MLEVF0008AW01 J AD Lever,Idler Ass’y [Tape 2]
28 LANGT0025AWFW J AD Blacket Motor
29 LANGT0026AWFW J AC Blacket Hold
30 LANGT0033AWFW J AB Blacket,Switch
31 MSPRP0005AWFW J AB Spring,Cassette
32 MSPRC0008AWFJ J AB Spring,Back Tention
33 MSPRD0031AWFJ J AB Spring,Lock Lever [Tape 1]
34 MSPRD0032AWFJ J AB Spring,Mode Lever
35 MSPRD0033AWFJ J AB Spring,Play Idler Lever
36 MSPRD0034AWFJ J AB Spring,Play Roller
37 MSPRD0035AWFJ J AB Spring,Eject Obstruct [Tape 1]
38 MSPRD0036AWFJ J AB Spring,Play Return
39 MSPRD0037AWFJ J AB Spring,Over Strok Lever
40 MSPRD0038AWFJ J AB Spring,Trigger Lever
41 MSPRD0039AWFJ J AB Spring,FR Lever
42 MSPRD0040AWFJ J AB Spring,Eject Obstruct [Tape 2]
43 NBLTK0009AWZZ J AC Belt,Sub
44 NBLTK0011AWZZ J AC Belt,Main [Tape 1]
45 NBLTK0012AWZZ J AB Belt,Main [Tape 2]
52 92LM-LEV1756A J AB Lever,Lock [Tape 2]
53 92LM-TSPR1756C J AB Spring,Lock Lever [Tape 2]
55 92LMRPH1746A J AM Head,Record/Playback
56 92LM-EH1658A J AG Head,Erase
57 92LM-REL1676B J AB Cap,Supply Reel
58 92LM-CSPR1676B J AA Spring,Supply Cap
59 92LN-BAND1318A J AA Nylon Band,80mm
501 92LS2R6S1746A J AA Screw,ø2.6×2.5mm
502 92L2TTS+4BZ J AA Screw,ø2×4mm
503 92L2TTS+5BZ J AA Screw,ø2×5mm
504 92L1R5WC3R8R5P J AA Washer,ø1.5×ø3.8×0.5mm
505 92L2R2TWO J AA Washer,ø2mm
506 LX-BZ0004AWFD J AC Screw,Lock Lever
507 XHPSD20P05000 J AA Screw,ø2×5mm
508 92L2R3W3R4R25P J AA Washer,ø2.3×ø3.4×0.25mm
510 92L1R8WC4-R5P J AA Washer,ø1.8×ø4×0.5mm
MM1 RMOTV0006AWM1 J AR Motor with Pulley [Tape]
SOLM2 RPLU-0002AWZZ J AH Solenoid
SWM3 QSW-F9064AFZZ J AC Switch,Leaf Type [Fool Proof]
SWM4 QSW-F9003AWZZ J AG Switch,Leaf Type [F.A.S.]
SWM5 QSW-F0346AFZZ J AB Switch,Leaf Type [CAM]
CD MECHANISM PARTS
301 NGERH0011AWZZ J AC Gear,Middle
302 NGERH0012AWZZ J AC Gear,Drive
303 MLEVP0010AWZZ J AC Rail,Guide
304 NSFTM0002AWFW J AE Shaft,Guide
305 92LM-CUSN1524A J AC Cushion
306 92LHPC1MASY J BG Pickup Unit Ass’y
306- 1 ———— — Pickup Unit
(Not Replacement Item)
306- 2 NGERR0043AFZZ J AC Gear,Rack
306- 3 MSPRC0961AFZZ J AA Spring,Rack
701 92L2R6S+6CZ J AB Screw,ø2.6×6mm
702 92L2TTS+5BB J AB Screw,ø2×5mm
703 92L2S+3PZ J AA Screw,ø2×3mm
704 92L1R5WC3R8R25 J AA Washer,ø1.5×ø3.8×0.25mm
M1 92LMTR1858CASY J AS Motor with Chassis [Disc]
M2 92LMTR1854BASY J AP Motor with Gear [Slide]
SW4 QSW-F9001AWZZ J AE Switch,Leaf Type [Pickup In]
CABINET PARTS
201 92LCAB2533AS1 J AX Front Panel Ass’y [410W]
201 92LCAB2534AS1 J AX Front Panel Ass’y [415W]
201 92LCAB2545AS1 J AX Front Panel Ass’y [420W]
201- 1 ———— — Front Panel
(Not Replacement Item)
201- 2 PCUSG0022AWZZ J AB Cushion,Leg
201- 3 HDECQ0215AWSA J AH Front Amp. [410W]
201- 3 HDECQ0216AWSA J AH Panel,Amp. [415W]
201- 3 HDECQ0225AWSA J AH Panel,Amp. [420W]
201- 4 JKNBZ0354AWSB J AF Knob,Disc Number
202 GCAB-1045AWSB J AL Top Cabinet
203 GITAR0217AWSA J AG Back Board [410W]
203 GITAR0218AWSA J AG Back Board [415W]
203 GITAR0223AWSA J AG Back Board [420W]
204 92LMEC2533CTS1 J AN Cassette Holder Ass’y,Tape 1
204- 1 ———— — Cassette Holder Tape 1
(Not Replacement Item)
204- 2 HDECQ0198AWSB J AF Panel,Cassette,Tape 1
206 92LMEC2533CTS2 J AN Cassette Holder Ass’y,Tape 2
206- 1 ———— — Cassette Holder Tape 2
(Not Replacement Item)
206- 2 HDECQ0199AWSB J AF Panel,Cassette,Tape 2
208 MSPRD0093AWFJ J AB Spring,Cassette,Tape 2
209 92LCAB2475BS1 J AK Side Panel Ass’y,Left
209- 1 ———— — Side Panel,Left
(Not Replacement Item)
209- 2 PCUSG0022AWZZ J AB Cushion,Leg
210 92LCAB2475CS1 J AK Side Panel Ass’y,Right
210- 1 ———— — Side Panel,Right
(Not Replacement Item)
210- 2 PCUSG0022AWZZ J AB Cushion,Leg
211 GCOVA1135AWSC J AG Cover,CD Tray
213 MLIFP0003AWZZ J AE Damper
214 MSPRD0092AWFJ J AB Spring,Cassette,Tape 1
215 LCHSM0045AWFW J AR Main Chassis
216 QACCB0003AW00 J BA AC Power Supply Cord
[410W/420W for Hong Kong]
216 QACCE0008AW00 J AG AC Power Supply Cord
[410W/420W Except for Saudi
Arabia/Hong Kong/Taiwan]
216 92LCORDA1387C J AP AC Power Supply Cord [415W]
216 92LCORDT1699A J AL AC Power Supply Cord
[410W/420W for Taiwan]
216 92LCORD577B J AM AC Power Supply Cord
[410W/420W for Saudi Arabia]
217 92LN-BAND1318A J AA Nylon Band,80mm
218 LANGT0043AWFW J AC Bracket,Heat Sink Support
220 LANGT0045AWFW J AD Bracket,Terminal
221 JKNBZ0335AWSA J AC Knob,Tuner/Memory
222 JKNBZ0334AWSA J AD Knob,Function
223 JKNBZ0332AWSA J AD Knob,Operation A
224 JKNBZ0333AWSA J AC Knob,Operation B
225 JKNBZ0337AWSB J AD Knob,X-BASS
226 JKNBZ0336AWSA J AC Knob,Open/Close,Rec./Playback
227 MLEVP0068AWZZ J AB Lever,Change
228 LCHSZ0011AWZZ J AG Chassis,CD Mechanism
229 NGERK0004AWZZ J AB Gear,Bevel
230 MSPRC0021AWFJ J AB Spring,Worm Wheel
231 NGERW0006AWZZ J AC Gear,Worm Wheel
232 NPLYD0001AWZZ J AB Pulley
233 NGERK0005AWZZ J AB Gear,Loading
234 MLEVP0066AWZZ J AE Lever,Shift
235 NGERH0064AWZZ J AD Gear,Cam
236 NGERK0003AWZZ J AC Gear,Drive
237 LHLDZ1141AWZZ J AB Support,Pitch
238 NGERH0065AWZZ J AB Gear,Turntable
239 NBLTK0029AWZZ J AB Belt,Drive
240 MSPRD0044AWFJ J AB Spring,Lock Lever
241 MLEVP0067AWZZ J AC Lever,Lock
242 LCHSZ0010AWZZ J AM Chassis,Loading
243 NROLP0009AWZZ J AB Roller
244 MLEVP0070AWZZ J AB Lever,T/T Lock
245 MSPRC0020AWFJ J AB Spring,T/T Lock Lever
246 GCAB-1044AWSA J AM CD Player Base
247 LHLDZ1139AWSA J AD Support,Stabilizer
248 92LHOLD2037AS1 J AK Stabilizer Ass’y
248- 1 ———— — Stabilizer
(Not Replacement Item)
248- 2 PMAGF0001AWZZ J AF Magnet
!
!
!
!
!
!
