Sharp CD-C470HCD-C470E User Manual

PRICE
RANK
DESCRIPTIONNO.
PART CODE NO. PARTS CODE
PRICE
RANK
DESCRIPTION
CD-C470H,C470E,C480H/CP-C470H,C470E,C480H
– 1 –
INTEGRATED CIRCUITS
IC1 VHILA9240M/-1 J AV Servo Amp.,LA9240M
IC2 VHILC78623D-1 J AY Servo/Signal Control,LC78623D
[CD-C480H]
IC2 VHILC78623E-1 J AX Servo/Signal Control,LC78623E
[CD-C470H/470E]
IC5 VHIM56748FP-1 J AR Focus/Tracking/Spin/Slide
Driver,M56748FP
IC91 VHITA7291S/-1 J AH Loading Motor Driver, TA7291S
IC99 VHPGP1F32T/-1 J AP Optical Fiber Data Link,
GP1F32T
IC101 VHIAN7345K/-1 J AM Playback and Record/ Playback
Amp.,AN7345K
IC201 VHILA2786//-1 J AV Dolby Pro Logic Active Decorder,
LA2786
IC202 VHILV1016//-1 J AX Dolby Pro Logic Passive
Decorder,LV1016
IC302 VHILC72131/-1 J AP PLL (Tuner),LC72131
IC303 VHILA1832//-1 J AR FM IF Det./FM Mpx./ AM IF,
LA1832
IC451 VHISRS5250S-1 J BL SRS,SRS5250S
[CD-C480H Only]
IC453 VHIBU4052BC-1 J AH Function Serector,BU4052BC
[CD-C480H Only]
IC501 VHILC75396E-1 J AT Audio Processor,LC75396E
IC502~504 VHIBA4558//-1 J AD Ope Amp.,BA4558
IC601 RH-IX0171AWZZ J AV System Microcomputer,
IX0171AW
IC651 VHIBA4558//-1 J AD Ope Amp.,BA4558
IC701 RH-IX0170AWZZ J AW System Microcomputer,
IX0170AW
IC702 VHIBU2092F/-1 J AM Input/Output Expander,
BU2092F
IC901 VHISTK48801-1 J BD Power Amp.,STK48801
IC951 VHILA4451//-1 J AN Power Amp.,LA4451
ICT21 VHILC72720/-1 J AW RDS,LC72720
[CD-C470H/480H Only]
TRANSISTORS
Q1 VSKTA1266GR-1 J AB Silicon,PNP,KTA1266 GR
Q81 VSKTC3203Y/-1 J AC Silicon,NPN,KTC3203 Y
Q83,84 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q91 VSKTA1271Y/-1 J AC Silicon,PNP,KTA1271 Y
Q93 VSKRC102M//-1 J AC Digital,NPN,KRC102 M
Q94 VSKRC107M//-1 J AC Digital,NPN,KRC107 M
Q103~106 VS2SC1845F/-1 J AC Silicon,NPN,2SC1845 F
Q107,108 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q109 VSKTA1266GR-1 J AB Silicon,PNP,KTA1266 GR
Q110,111 VSKRC104M//-1 J AC Digital,NPN,KRC104 M
Q113,114 VSKRC104M//-1 J AC Digital,NPN,KRC104 M
[CD-C480H Only]
Q115,116 VSKRC104M//-1 J AC Digital,NPN,KRC104 M
Q117,118 VS2SC2878A/-1 J AE Silicon,NPN,2SC2878 A
Q119 VSKRC104M//-1 J AC Digital,NPN,KRC104 M
Q121,122 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q124 VSKTA1266GR-1 J AB Silicon,PNP,KTA1266 GR
Q125 VSKTA1266GR-1 J AB Silicon,PNP,KTA1266 GR
[CD-C480H Only]
Q126 VSKRC104M//-1 J AC Digital,NPN,KRC104 M
Q127 VSKRC104M//-1 J AC Digital,NPN,KRC104 M
[CD-C480H Only]
Q128 VS2SC2236-Y-1 J AB Silicon,NPN,2SC2236 Y
Q129,130 VSKTC3199GR-1 J AB Digital,NPN,KTC3199 GR
Q131,132 VSKRC107M//-1 J AC Digital,NPN,KRC107 M
[CD-C480H Only]
Q133 VSKRC104M//-1 J AC Digital,NPN,KRC104 M
[CD-C480H Only]
Q301 VS2SC380-O/-1 J AC Silicon,NPN,2SC380 O
Q302~304 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q353,354 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q360 VSKTA1266GR-1 J AB Silicon,PNP,KTA1266 GR
Q361 VSKRC107M//-1 J AC Digital,NPN,KRC107 M
Q362 VSKRA107M//-1 J AE Digital,PNP,KRA107 M
Q371 VSKTA1266GR-1 J AB Silicon,PNP,KTA1266 GR
Q458~460 VSKRC107M//-1 J AC Digital,NPN,KRC107 M
[CD-C480H Only]
Q461 VSKTC3203Y/-1 J AC Silicon,NPN,KTC3203 Y
[CD-C480H Only]
Q463 VSKRC107M//-1 J AC Digital,NPN,KRC107 M
[CD-C480H Only]
Q466 VSKRC107M//-1 J AC Digital,NPN,KRC107 M
[CD-C480H Only]
Q467 VSKRA107M//-1 J AE Digital,PNP,KRA107 M
[CD-C480H Only]
Q468,469 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
[CD-C480H Only]
Q501~504 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q701 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q704 VSKRC102M//-1 J AC Silicon,NPN,KRC102 M
Q705,706 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q801 VSKTA1266GR-1 J AB Silicon,PNP,KTA1266 GR
Q821 VS2SD2012//-1 J AD Silicon,NPN,2SD2012
Q822 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q823 VS2SD2012//-1 J AD Silicon,NPN,2SD2012
Q824 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q825 VSKRA107M//-1 J AE Digital,PNP,KRA107 M
Q826 VS2SD2012//-1 J AD Silicon,NPN,2SD2012
Q827 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q828 VS2SD468-C/-1 J AD Silicon,NPN,2SD468 C
Q829 VSKRC107M//-1 J AC Digital,NPN,KRC107 M
Q901 VSKRC107M//-1 J AC Digital,NPN,KRC107 M
Q951 VSKRC107M//-1 J AC Digital,NPN,KRC107 M
QM01 VSKTA1266GR-1 J AB Silicon,PNP,KTA1266 GR
QM02 VSKTA1273Y/-1 J AE Silicon,PNP,KTA1273 Y
QM03 VSKTA1271Y/-1 J AC Silicon,PNP,KTA1271 Y
QM04 VSKRC104M//-1 J AC Digital,NPN,KRC104 M
QM05 VSKTA1266GR-1 J AB Silicon,PNP,KTA1266 GR
QT21 VSKTC3199GR-1 J AB Digital,NPN,KTC3199 GR
[CD-C470H/480H Only]
DIODES
D2 VHD1SS133//-1 J AA Silicon,1SS133
D5,6 VHDRL104A//-1 J AB Silicon,RL104A
D7 VHDRL104A//-1 J AB Silicon,RL104A
D8,9 VHD1SS133//-1 J AA Silicon,1SS133
D91 VHD1SS133//-1 J AA Silicon,1SS133
D301~304 VHD1SS133//-1 J AA Silicon,1SS133
D351~353 VHD1SS133//-1 J AA Silicon,1SS133
D451 VHD1SS133//-1 J AA Silicon,1SS133
[CD-C480H Only]
D501,502 VHD1SS133//-1 J AA Silicon,1SS133
D551~557 VHD1SS133//-1 J AA Silicon,1SS133
D558,559 VHDRL104A//-1 J AB Silicon,RL104A
D560,561 VHD1SS133//-1 J AA Silicon,1SS133
D562 VHDRL104A//-1 J AB Silicon,RL104A
D601,602 VHD1SS133//-1 J AA Silicon,1SS133
D705~709 VHD1SS133//-1 J AA Silicon,1SS133
D801 VHDS4VB20//-1 J AG Rectifier,S4VB20
D802~809 VHDRL104A//-1 J AB Silicon,RL104A
D817~825 VHD1SS133//-1 J AA Silicon,1SS133
D826,827 VHDRL104A//-1 J AB Silicon,RL104A
D828~831 VHD1SS133//-1 J AA Silicon,1SS133
D901 VHD1SS133//-1 J AA Silicon,1SS133
D951 VHD1SS133//-1 J AA Silicon,1SS133
DM02,03 VHD1SS133//-1 J AA Silicon,1SS133
LED701~705 VHP333GTH2/-1 J AD LED,Green,333GTH2
LED706~711 VHP333YTH2/-1 J AD LED,Orange,333YTH2
LED712 VHP333YTH4/-1 J AD LED,Orange,333YTH4
[CD-C480H Only]
LED714~719 VHPLMKD515B-1 J AE LED,Green,LMKD515B
PHM1 VHPI31535CD-1 J AG Phote Interrupter
VD301 VHCKV1236Z23F J AS Variable Capacitance,
KV1236Z23F
ZD81 VHEMTZJ5R6B-1 J AD Zener,5.6V,MTZJ5.6B
ZD351 VHEMTZJ5R1B-1 J AC Zener,5.1V,MTZJ5.1B
ZD352 VHEMTZJ3R9B-1 J AC Zener,3.9V,MTZJ3.9B
ZD551 VHEMTZJ6R2C-1 J AC Zener,6.2V,MTZJ6.2C
ZD701 VHEMTZJ3R9B-1 J AC Zener,3.9V,MTZJ3.9B
ZD801 VHEMTZJ300C-1 J Zener,30V,MTZJ30C
[CD-C470H/470E]
ZD801 VHEMTZJ330C-1 J AB Zener,33V,MTZJ33V
[CD-C480H]
ZD802 VHEMTZJ5R6B-1 J AD Zener,5.6V,MTZJ5.6B
ZD821 VHEMTZJ8R2C-1 J AB Zener,8.2V,MTZJ8.2C
ZD822 VHEMTZJ130C-1 J AB Zener,13V,MTZJ13C
ZD823 VHEMTZJ6R2C-1 J AC Zener,6.2V,MTZJ6.2C
ZD901 VHEMTZJ130C-1 J AB Zener,13V,MTZJ13C
CD-C470H/CD-C470E/CD-C480H
