Sharp CD-C612 User Manual

NO.
PRICE
RANK
DESCRIPTIONPARTS CODE
NO. PARTS CODE
PRICE
RANK
DESCRIPTION
CD-C612
R712 VRD-ST2CD223J J AA 22 kohms,1/6W
R713~715 VRD-ST2CD102J J AA 1 kohm,1/6W
R716 VRD-ST2CD330J J AA 33 ohms,1/6W
R717 VRD-MN2BD103J J AA 10 kohm,1/8W
R718 VRD-ST2CD102J J AA 1 kohm,1/6W
R719,720 VRD-MN2BD103J J AA 10 kohm,1/8W
R721~723 VRD-MN2BD104J J AA 100 kohm,1/8W
R724 VRD-ST2CD103J J AA 10 kohm,1/6W
R730~732 VRD-MN2BD102J J AA 1 kohm,1/8W
R733,734 VRD-ST2CD222J J AA 2.2 kohms,1/6W
R735 VRD-ST2CD182J J AA 1.8 kohms,1/6W
R736,737 VRD-MN2BD102J J AA 1 kohm,1/8W
R738 VRD-ST2CD102J J AA 1 kohm,1/6W
R739 VRD-MN2BD103J J AA 10 kohm,1/8W
R740~744 VRD-MN2BD102J J AA 1 kohm,1/8W
R745 VRD-ST2CD102J J AA 1 kohm,1/6W
R747,748 VRD-ST2CD103J J AA 10 kohm,1/6W
R749,750 VRD-MN2BD103J J AA 10 kohm,1/8W
R751 VRD-MN2BD332J J AA 3.3 kohms,1/8W
R752,753 VRD-ST2CD103J J AA 10 kohm,1/6W
R754~757 VRD-MN2BD103J J AA 10 kohm,1/8W
R758 VRD-MN2BD122J J AA 1.2 kohms,1/8W
R759,760 VRD-MN2BD103J J AA 10 kohm,1/8W
R762~772 VRD-ST2CD102J J AA 1 kohm,1/6W
R775~778 VRD-ST2CD102J J AA 1 kohm,1/6W
R780 VRD-ST2CD103J J AA 10 kohm,1/6W
R792 VRD-ST2CD103J J AA 10 kohm,1/6W
R795 VRD-MN2BD473J J AA 47 kohms,1/8W
R797 VRD-MN2BD104J J AA 100 kohm,1/8W
R798 VRD-MN2BD101J J AA 100 ohm,1/8W
R799 VRD-ST2CD103J J AA 10 kohm,1/6W
R801 VRD-ST2CD123J J AA 12 kohms,1/6W
R806 VRD-ST2CD222J J AA 2.2 kohms,1/6W
R808 VRD-ST2CD221J J AA 220 ohms,1/6W
R825 VRD-ST2CD330J J AA 33 ohms,1/6W
R827 VRD-ST2CD223J J AA 22 kohms,1/6W
R830 VRD-ST2CD471J J AA 470 ohms,1/6W
R831 VRD-RT2HD3R3J J AA 3.3 ohms,1/2W
R832 VRD-ST2EE223J J AA 22 kohms,1/4W
R833 VRD-ST2EE100J J AA 10 ohm,1/4W
R834 VRD-ST2CD473J J AA 47 kohms,1/6W
R837 VRD-ST2CD103J J AA 10 kohm,1/6W
R841 VRD-RT2HD3R3J J AA 3.3 ohms,1/2W
R961,962 VRD-ST2CD333J J AA 33 kohms,1/6W
R965 VRD-ST2CD102J J AA 1 kohm,1/6W
R966 VRD-ST2EE102J J AA 1 kohm,1/4W
R967,968 VRD-ST2CD221J J AA 220 ohms,1/6W
R969 VRD-ST2CD103J J AA 10 kohm,1/6W
R971,972 VRD-ST2EE4R7J J AA 4.7 ohms,1/4W
R973 VRD-RT2HD271J J AA 270 ohms,1/2W
R975 VRD-RT2HD271J J AA 270 ohms,1/2W
R981,982 VRD-RT2HD331J J AA 330 ohms,1/2W
RD01 VRD-MN2BD821J J AA 820 ohms,1/8W
RD02 VRD-MN2BD122J J AA 1.2 kohms,1/8W
RD03 VRD-MN2BD152J J AA 1.5 kohms,1/8W
RD04 VRD-MN2BD182J J AA 1.8 kohms,1/8W
RD05 VRD-MN2BD472J J AA 4.7 kohms,1/8W
RD08 VRD-MN2BD472J J AA 4.7 kohms,1/8W
RD09 VRD-MN2BD682J J AA 6.8 kohms,1/8W
RD10 VRD-ST2CD821J J AA 820 ohms,1/6W
RD11 VRD-MN2BD122J J AA 1.2 kohms,1/8W
RD12 VRD-ST2CD152J J AA 1.5 kohms,1/6W
RD13 VRD-ST2CD182J J AA 1.8 kohms,1/6W
RD14 VRD-ST2CD222J J AA 2.2 kohms,1/6W
RD15 VRD-MN2BD332J J AA 3.3 kohms,1/8W
RD16 VRD-MN2BD392J J AA 3.9 kohms,1/8W
RD21 VRD-ST2CD821J J AA 820 ohms,1/6W
RD22 VRD-ST2CD122J J AA 1.2 kohms,1/6W
RD23 VRD-ST2CD152J J AA 1.5 kohms,1/6W
RD24 VRD-ST2CD182J J AA 1.8 kohms,1/6W
RD25 VRD-MN2BD222J J AA 2.2 kohms,1/8W
RD26 VRD-ST2CD332J J AA 3.3 kohms,1/6W
RD27 VRD-MN2BD392J J AA 3.9 kohms,1/8W
RD28 VRD-MN2BD682J J AA 6.8 kohms,1/8W
OTHER CIRCUITRY PARTS
BI601/CNS11 QCNWN1474AWZZ J AG Connector Ass'y,6/6Pin
BI701/CNSM1 QCNWN1386AWZZ J AG Connector Ass'y,8/12Pin
BI702/CNS12 QCNWN1381AWZZ J AL Connector Ass'y,15/15Pin
BIM5/CNS10/CNS5 QCNWN1184AWZZ J AL Connector Ass'y,6/10/2Pin
CNP1 92LCONE5P53253 J AB Plug,5Pin
CNP2 QCNCM705HAFZZ J AB Plug,8Pin
CNP3 92LCONE6P53253 J AC Plug,6Pin
CNP3A 92LCONE6P53254 J AC Plug,6Pin
CNP10 QCNCM705KAWZZ J AC Plug,10Pin
CNP11 QCNCM704FAWZZ J AC Plug,6Pin
CNP12 QCNCM704QAWZZ J AG Plug,15Pin
CNP101 92LCONE3P53253 J AB Plug,3Pin
CNP102 92LCONE7P53253 J AC Plug,7Pin
CNP301 92LCONE3P5268 J AC Plug,3Pin
! CNP801 QCNCM042BAWZZ J AC Plug,2Pin
CNP802 QCNCM035GAWZZ J AC Plug,7Pin
CNPM1 QCNCM932MAFZZ J AE Plug,12Pin
CNPM2 QCNCM030BAWZZ J AB Pin Holder
CNS1A/B QCNWN1181AWZZ J AK Connector Ass'y,5/5Pin
CNS2A/B QCNWN1182AWZZ J AH Connector Ass'y,8/8Pin
CNS3A/B QCNWN1183AWZZ J AG Connector Ass'y,6/6Pin
CNS101 QCNWN1384AWZZ J AL Connector Ass'y,3Pin
CNS102 QCNWN1385AWZZ J AG Connector Ass'y,7Pin
! F803 QFS-D402CSJNI J AD Fuse,4A/125V
! F805 QFS-D202DSJNI J AD Fuse,2A/250V
FL701 VVKBJ685GNK-1 J AV FL Display
FW701 QCNWN1472AWZZ J AC Flat Wire,3Pin
FW702 QCNWN1471AWZZ J AE Flat Wire,11Pin
FW703 QCNWN1470AWZZ J AD Flat Wire,10Pin
FW801 QCNWN1469AWZZ J AD Flat Wire,5Pin
FWM1 QCNWN1274AWZZ J AC Flat Wire,2Pin
FWM2 QCNWN0338AWZZ J AD Flat Wire,2Pin
JK601 QSOCJ0213AWZZ J AE Jack,Video In
JK970 QJAKM0010AWZZ J AF Jack,Headphones
M1 92LMTR1858CASY J AS Motor with Chassis [Disc]
M2 92LMTR1854BASY J AP Motor with Gear [Slide]
M3 RMOTV0373AFZZ J AL Motor with Worm Pulley
[T/T Up/Down Loading]
MM1(204-7) RMOTV0006AWM1 J AR Motor with Pulley [Tape]
PHM1 VHPI31535CD-1 J AG Photo Interrupter
! RL801 RRLYD0001SJZZ J AQ Relay
RX701 VHLN63H380A-1 J AK Remote Sensor,N63H380A
! SO801 QSOCA0209AWZZ J AH Socket,AC Input
SO961 QTANA0802AWZZ J AH Terminal,Speaker
SOLM1(204-8) RPLU-0002AWZZ J AH Solenoid Ass'y [Tape]
SOLM2 RPLU-0002AWZZ J AH Solenoid Ass'y [CD]
SW1 QSW-P0004AWZZ J AE Switch,Push Type [Open/Close]
SW2 QSW-F0001AWZZ J AD Switch,Leaf/Skeleton Type
[Mecha Up]
SW3 QSW-P0005AWZZ J AD Switch,Push Type [Disc Number]
SW4 QSW-F9001AW01 J AD Switch,Leaf Type [Pickup In]
SW701 92LSWICH1401AT J AC Switch,Key Type [POWER]
SW703 92LSWICH1401AT J AC Switch,Key Type [CLOCK]
SW704 92LSWICH1401AT J AC Switch,Key Type
[TIMER/SLEEP]
SW708 92LSWICH1401AT J AC Switch,Key Type [DISC SKIP]
SW709 92LSWICH1401AT J AC Switch,Key Type
[OPEN/CLOSE]
SW710 92LSWICH1401AT J AC Switch,Key Type [REV]
SW711 92LSWICH1401AT J AC Switch,Key Type [REC PAUSE]
SW712 92LSWICH1401AT J AC Switch,Key Type
[MEMORY/SET]
SW713 92LSWICH1401AT J AC Switch,Key Type [STOP]
SW714 92LSWICH1401AT J AC Switch,Key Type
[TUNER/BAND]
SW715 92LSWICH1401AT J AC Switch,Key Type [VIDEO]
SW716 92LSWICH1401AT J AC Switch,Key Type [TAPE]
SW717 92LSWICH1401AT J AC Switch,Key Type [CD]
SW722 92LSWICH1401AT J AC Switch,Key Type [FF]
SW723 92LSWICH1401AT J AC Switch,Key Type [TUNING UP]
SW724 92LSWICH1401AT J AC Switch,Key Type
[TUNING DOWN]
SW725 92LSWICH1401AT J AC Switch,Key Type [PLAY]
SW726 92LSWICH1401AT J AC Switch,Key Type
[VOLUME DOWN]
SW727 92LSWICH1401AT J AC Switch,Key Type [VOLUME UP]
SW728 92LSWICH1401AT J AC Switch,Key Type
[X-BASS/DEMO]
SW729 92LSWICH1401AT J AC Switch,Key Type [EQUALIZER]
SW730 92LSWICH1401AT J AC Switch,Key Type [DIMMER]
SWM3(204-9) 92LM-SW1676A J AC Switch,Leaf Type [Fool Proof]
SWM4(204-10) QSW-F9003AWZZ J AG Switch,Leaf Type [F.A.S]
SWM5(204-11) 92LM-SW1658A J AB Switch,Leaf Type [CAM]
CD MECHANISM PARTS
301 NGERH0011AWZZ J AC Gear,Middle
– 4 –
