CD-DD4500
– 4 –
CD-DD4500
Rear panel
1. DVD Digital Input Jack
2. Center Speaker Jacks
3. Surround Speaker Jacks
4. FM/AM Loop Antenna Jack
5. Video/Auxiliary (Audio Signal) Input Jacks
6. Speaker Terminals
7. Subwoofer Pre Output Jack
8. AC Power Cord
1
8
2
3
4
5
6
7
Remote control
1. Remote Control Transmitter
2. CD Memory Button
3. Set Up Menu Select Buttons
4. Menu Button
5. Item Button
6. Disc Number Select Buttons
7. CD Random Button
8. CD Pause Button
9. CD Fast Reverse/Preset Down Button
10. CD Stop Button
11. Tape 2 Record Pause Button
12. Tuner (Band) Button
13. CD Button
14. Extra Bass Button
15. CD Clear Button
16. Power Button
17. Surround Effect Buttons
18. Equalizer Mode Select Button
19. CD Play or Repeat Button
20. CD Fast Forward/Preset Up Button
21. Tape 1/Tape 2 Play Button
22. Tape 1/Tape 2 Stop Button
23. Tape 2 Fast Forward Button
24. Tape 2 Rewind Button
25. DVD/VCR Button
26. Tape (1 2) Button
27. Volume Up or Down Buttons
11
2
15
16
17
20
3
5
6
7
8
9
13
14
12
11
10
4
21
27
26
25
24
23
22
18
19
✱
✱
✱
✱
✱
✱
Buttons with “✱” mark in the illustration can be operated with the remote control
only.
Other buttons can be operated on the main unit and the remote control.
