INTEGRATED CIRCUITS
IC1 VHILC78645NE1 J AY CD Servo,LC78645NE
IC2 VHIM63001FP-1 J AX Focus/Tracking/Spin/Sled Driver,
M63001FP
IC101 VHIAN7345K/-1 J AM Playback and Record/Playback
Amp.,AN7345K
IC102 VHIBA3126N/-1 J AF Head Selector,BA3126N
IC181 VHIBU2092F/-1 J AM Input/Output Expander,BU2092F
IC302 VHILC72131/-1 J AP PLL (Tuner),LC72131
IC303 VHILA1832S/-1 J AN FM IF Det./FM Mpx./AM IF,
LA1832S
IC401 VHISTK40224-1 J BC Power Amp.,STK40224
IC501 VHPTORX178B-1 J Optical Fiber Data Link,
TORX178B
IC502 VHI74VHC00F-1 J AE Invertor,74VHC00F
IC504 RH-IX0443AWZZ J BM Dolby Decoder,IX443AW
IC505 RH-IX0454AWZZ J BB 6-ch Codec IC,AK4527BVQ
IC571 VHITA48M033-1 J AK 3.3V Voltage Regulator,
TA48M033F (S)
IC601 VHILC75341/-1 J AM Audio Processor,LC75341
IC602 VHIM62446FP-1 J AY 6-ch Electronic Volume,
M62446FP
IC605~607 VHINJM4565M-1 J AC Buffer Amp.,NJM4565M
IC701 RH-IX0442AWZZ J BA System Microcomputer,
IX0442AW
IC702 VHIBU2092F/-1 J AM Input/Output Expander,BU2092F
IC703,704 VHIKIA4558P-1 J AC Ope Amp.,KIA4558P
IC850 VHIKIA7810AP1 J AF Voltage Regulator,KIA7810AP
IC851 VHIKIA7805AP1 J AF Constant Voltage Regulator,
KIA7805AP
IC880 VHIKIA7805AP1 J AF Constant Voltage Regulator,
KIA7805AP
IC901,902 VHISTK40270N1 J AY Power Amp.,STK40270N
IC904 VHIKIA4558P-1 J AC Ope Amp.,KIA4558P
IC905,906 VHITC4053BP-1 J AE Triple 2-Channel Multiplexer,
TC4503BP
IC907 VHIKIA4558P-1 J AC Ope Amp.,KIA4558P
TRANSISTORS
Q1 VSKTA1266GR-1 J AB Silicon,PNP,KTA1266 GR
Q2 VSKTC3203Y/-1 J AC Silicon,NPN,KTC3203 Y
Q3 VSKRC102M//-1 J AC Digital,NPN,KRC102 M
Q101 VSKRC104M//-1 J AC Digital,NPN,KRC104 M
Q102,103 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q121,122 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q124 VS2SA1015GR-1 J AB Silicon,PNP,2SA1015 GR
Q126 VSKRC104M//-1 J AC Digital,NPN,KRC104 M
Q128 VSKTC3203Y/-1 J AC Silicon,NPN,KTC3203 Y
Q360 VSKTA1266GR-1 J AB Silicon,PNP,KTA1266 GR
Q371 VSKTA1266GR-1 J AB Silicon,PNP,KTA1266 GR
Q401~404 VS2SC2878B/-1 J AC Silicon,NPN,2SC2878 B
Q405,406 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q407,408 VS2SC2878B/-1 J AC Silicon,NPN,2SC2878 B
Q409~413 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q420 VSKRC107M//-1 J AC Digital,NPN,KRC107 M
Q421 VSKTA1271Y/-1 J AC Silicon,PNP,KTA1271 Y
Q422 VSKTC3203Y/-1 J AC Silicon,NPN,KTC3203 Y
Q423 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q424 VS2SB1565F/-1 J AG Silicon,PNP,2SB1565 F
Q503 VSKRC104M//-1 J AC Digital,NPN,KRC104 M
Q505 VSKRC104M//-1 J AC Digital,NPN,KRC104 M
Q520 VSKRC104M//-1 J AC Digital,NPN,KRC104 M
Q572 VS2SD468-C/-1 J AD Silicon,NPN,2SD468 C
Q601 VSKTA1271Y/-1 J AC Silicon,PNP,KTA1271 Y
Q602 VSKTC3203Y/-1 J AC Silicon,NPN,KTC3203 Y
Q701~706 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q707 VSKRC102M//-1 J AC Digital,NPN,KRC102 M
Q708,709 VSKTA1271Y/-1 J AC Silicon,PNP,KTA1271 Y
Q710 VSKTA1273Y/-1 J AE Silicon,PNP,KTA1273 Y
Q712 VSKRC104M//-1 J AC Digital,NPN,KRC104 M
Q806 VSKTA1274Y/-1 J AE Silicon,PNP,KTA1274 Y
Q850,851 VSKTC2026Y/-1 J AE Silicon,NPN,KTC2026 Y
Q859 VSKRA107M//-1 J AE Digital,PNP,KRA107 M
Q880 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q891~893 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q905~908 VS2SC2878B/-1 J AC Silicon,NPN,2SC2878 B
Q909~912 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q913,914 VSKRA107M//-1 J AE Digital,PNP,KRA107 M
Q915 VSKRC107M//-1 J AC Digital,NPN,KRC107 M
Q916 VSKRA107M//-1 J AE Digital,PNP,KRA107 M
Q917 VS2SC2878B/-1 J AC Silicon,NPN,2SC2878 B
Q918~921 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q937 VSKTA1046Y+-1 J AF Sillicon,PNP,KTA1046 Y
DIODES
D1,2 VHDD1SS133//- J Silicon,D1SS133
D181~186 VHDDS1SS133-1 J AB Silicon,DS1SS133
D301~306 VHDDS1SS133-1 J AB Silicon,DS1SS133
D352 VHDDS1SS133-1 J AB Silicon,DS1SS133
D401~406 VHDDS1SS133-1 J AB Silicon,DS1SS133
D409,410 VHDDS1SS133-1 J AB Silicon,DS1SS133
D500,501 VHD1SS133//-V J AC Silicon,1SS133
D502,503 VHD1SS133//-1 J AA Silicon,1SS133
D506~513 VHDDS1SS133-1 J AB Silicon,DS1SS133
D601,602 VHDDS1SS133-1 J AB Silicon,DS1SS133
D604 VHDDS1SS133-1 J AB Silicon,DS1SS133
D701~712 VHDDS1SS133-1 J AB Silicon,DS1SS133
D801,802 VHDTS6B04GM-1 J AP Silicon,TS6B04GM-1
D803~811 VHD1N4004S/-1 J AB Silicon,1N4004S
D851~853 VHDDS1SS133-1 J AB Silicon,DS1SS133
D855 VHDDS1SS133-1 J AB Silicon,DS1SS133
D859,860 VHDDS1SS133-1 J AB Silicon,DS1SS133
D880 VHDDS1SS133-1 J AB Silicon,DS1SS133
D881~884 VHD1N4004S/-1 J AB Silicon,1N4004S
D885 VHDDS1SS133-1 J AB Silicon,DS1SS133
D901~906 VHDDS1SS133-1 J AB Silicon,DS1SS133
D908 VHDDS1SS133-1 J AB Silicon,DS1SS133
DZ403 VHEDZ3R9BSB-1 J AC Zener,3.9V,DZ3.9BSB
DZ404 VHEDZ5R6BSB-1 J AC Zener,5.6V,DZ5.6BSB
DZ571 VHEMTZJ5R6A-V J AB Zener,5.6V,MTZJ5.6A
DZ802 VHEDZ2R4BSB-1 J AB Zener,2.4V,DZ2.4BSB
DZ803 VHEDZ360BSC-1 J AB Zener,36V,DZ36BSC
DZ804 VHEDZ6R2BSA-1 J AB Zener,6.2V,DZ6.2BSA
DZ901,902 VHEDZ5R1BSB-1 J AC Zener,5.1V,DZ5.1BSB
DZ903 VHEDZ130BSC-1 J AB Zener,13V,DZ13BSC
LED701,702 VHP4204UYT7-1 J AD LED,Yellow,4204UYT7
LED709 VHP4204SRT7-1 J AD LED,Red,4204SRT7
ZD1 VHEDZ3R3BSB-1 J AB Zener,3.3V,DZ3.3BSB
ZD2 VHEDZ3R9BSB-1 J AC Zener,3.9V,DZ3.9BSB
ZD351 VHEDZ5R1BSB-1 J AC Zener,5.1V,DZ5.1BSB
ZD601,602 VHEDZ7R5BSC-1 J AB Zener,7.5V,DZ7.5BSC
ZD701 VHEDZ6R2BSC-1 J AB Zener,6.2V,DZ6.2BSC
ZD850 VHEDZ2R4BSB-1 J AB Zener,2.4V,DZ2.4BSB
FILTERS
CF302 RFILF0124AFZZ J AD FM IF,10.7 MHz
CF351 RFILF0003AWZZ J AK FM IF
CF352 RFILA0009AWZZ J AE AM IF
TRANSFORMERS
T302 RCILA0062AWZZ J AC AM Tracking
T306 RCILB0066AWZZ J AD AM OSC
T351 RCILI0019AWZZ J AD AM IF
1 T801 RTRNP0384AWZZ J BG Power
1 T802 RTRNP0312AWZZ J AM Power
COILS
L1 VP-XHR82K0000 J AC 0.82 µH
L103 VP-DH101K0000 J AB 100 µH,Choke
L104 VP-MK331K0000 J AB 330 µH,Choke
L342 VP-DH2R2K0000 J AB 2.2 µH,Peaking
L351,352 VP-DH101K0000 J AB 100 µH,Choke
L353 VP-DH102K0000 J AB 1 mH,Choke
L401~403 RCILZ0137AFZZ J AA 0.29 µH
L500 VP-XF100K0000 J AB 10 µH,Choke
L501 VP-XFR82K0000 J AD 0.82 µH
L505~507 RCILC0353AFZZ J AB Tip Solid Induction,100mA
L510~513 RCILC0353AFZZ J AB Tip Solid Induction,100mA
L570 VP-XFR82K0000 J AD 0.82 µH
L701 VP-DH101K0000 J AB 100 µH,Choke
L702 VP-DH2R2K0000 J AB 2.2 µH,Peaking
1 L802 RCILZ0021AWZZ J AF AC Line Filter
