Sharp CD-DD4500 - Page 79

NO.
PRICE
RANK
DESCRIPTIONPARTS CODE
NO. PARTS CODE
PRICE
RANK
DESCRIPTION
CD-DD4500
258- 4 92PFF19N-21 J Belt,Main [Tape 2]
258- 5 92PF514-133 J AL Pinch Roller
258- 6 92PF19S-31 J AL Belt,FF/REW [Tape 2]
258- 7 92PFF19N-11 J AL Belt,Main [Tape 1]
258- 8 92PF522-061 J AZ Clutch Ass’y Block [Tape 1]
258- 9 92PFF19S-52 J AL Belt,FF/REW [Tape 1]
258-10 92PF513-861 J AG Head Plate Block [Tape 1]
258-11 92PF522-063 J AZ Clutch Ass’y Block [Tape 2]
258-12 92PFD60F-11 J Cam Gear [Tape 1]
258-13 92PFR26C-11 J Flywheel [Tape 1]
258-14 92PFR26D-11 J Flywheel [Tape 2]
258-15 92PF765-292 J Solenoid Ass’y
258-16 92PFD58M-14 J Cam Gear [Tape 2]
264 LANGK0374AWFW J Bracket,Fam Support B
601 XWHSD32-10130 J AA Washer,ø3.2×ø13×1.0mm
602 LX-BZ0880AFZZ J AC Screw,ø2×2.2mm
603 LX-JZ0010AFFD J AA Screw,ø3×10mm
604 LX-LZ0006AWZZ J AC Push Rivet
605 XBBSD20P04000 J AA Screw,ø2×4mm
606 XEBSD30P10000 J AA Screw,ø3×10mm
607 XEBSF30P12000 J AA Screw,ø3×12mm
608 XESSD30P10000 J AA Screw,ø3×10mm
609 XHBSD30P06000 J AA Screw,ø3×6mm
610 XJBSD30P10000 J AA Screw,ø3×10mm
611 XJBSD30P14000 J AA Screw,ø3×14mm
612 XJBSF30P10000 J AA Screw,ø3×10mm
613 XJSSD30P10000 J AA Screw,ø3×10mm
614 92LSC0308MBZI J AB Screw,ø3×8mm
615 92LSC0308RBZI J AB Screw,ø3×8mm
616 XHBSD40P08000 J AA Screw,ø4×8mm
617 LX-LZ0014AWZZ J AC PWB Spacer
PACKING PARTS (Except for U.S.A.)
SPAKA0325AWZZ J Packing Add.
SPAKC1264AWZZ J Packing Case
[Except for Canada]
SPAKC1265AWZZ J Packing Case [For Canada]
SPAKP0032AWZZ J AF Polyethylene Bag,Unit
SPAKZ0817AWZZ J Ethaform
SPAKZ0818AWZZ J Packing Add.
SSAKA0007AWZZ J AB Polyethylene Bag,Accessories
ACCESSORIES
QANTL0007AWZZ J AK AM/FM Loop Antenna
TCAUS0042AWZZ J AB Energy Star Caution
TINSE0378AWZZ J AF Operation Manual
[Except for Canada]
TINSK0117AWZZ J AG Operation Manual [For Canada]
TINSZ0700AWZZ J AC Quick Guide [For U.S.A.]
TLABR1215AWZZ J AB Label,Bar Code
TLABZ0593AWZZ J AB Label,Energy Star
TLABZ0941AWZZ J AC Label,Feature [Tape 1]
TLABZ0942AWZZ J AC Label,Feature [Tape 2]
RRMCG0296AWSA J AV Remote Control
GFTAB1030AWSA J Battery Lid,Remote Control
P.W.B. ASSEMBLY (Not Replacement Item)
PWB-A 92LPWB3723MANS J –– Main
PWB-B1,2 92LPWB3723DPLS J –– Display/Headphones
(Combined Ass’y)
PWB-C 92LPWB3723CDUS J –– CD Servo
1 PWB-D1~4 92LPWB3723PWRS J –– Power/Amp.A/Transformer/
Support (Combined Ass’y)
PWB-E 92LPC99C017 J AE CD Loading Motor (PWB Only)
PWB-F 92PF567-649 J –– Tape Mechanism
PWB-G QPWBF0027AWZZ J AD CD Motor (PWB Only)
PWB-H 92LPWB3723ACTS J –– Dolby
PWB-J 92LPWB3723AMPS J –– Amp.B
OTHER SERVICE PART
UDSKA0004AFZZ J AZ CD Pickup Lens Cleaner
– 8 –
CP-DD4500
SPEAKER BOX PARTS
901 CPNLS1032AW01 J Front Panel Ass’y,Right
901 CPNLS1033AW01 J Front Panel Ass’y,Left
902 GBOXS2006AWSA J Speaker Box Ass’y
903 PCUSG0022AWZZ J AB Foot Cushion
904 PFLT-0049AWZZ J AC Felt
905 QCNWN2023AWZZ J Woofer Cord
906 QCNWN2024AWZZ J Subwoofer Cord
907 QCNWN2040AWZZ J Tweeter Cord Ass’y,with
Capacitor C1,2
908 XESSD30P10000 J AA Screw,ø3×10mm
909 TSPC-0896AWZZ J Label,Specifications
910 XEBSD40P16000 J Screw,ø4×16mm
SP1,2 RSPA00029AW8T J Tweeter
SP3,4 RSPA00028AW8W J Woofer
SP5,6 RSPA10028AW6W J Subwoofer
PACKING PARTS
SPAKA0314AWZZ J Packing Add.
SSAKH0053AWZZ J Polyethylene Bag,Speaker
CENTER SPEAKER BOX PARTS
901 CWAKP1054AWM1 J Net Frame Ass’y
902 GCAB-1203AWSA J Bottom Cabinet
903 QCNWN2041AWZZ J Speaker Cord
904 PCUSG0088AWZZ J Foot Cushion
905 XEBSD30P14000 J AA Screw,ø3×14mm
906 TLABM0125AWZZ J Label,Parts Code
SP1 RSPA10039AW6S J Speaker
GBOXS0064AWM1
GBOXS2008AWM1/GBOXS4008AWM1
SURROUND SPEAKER BOX PARTS
901 CWAKP1055AWM1 J Net Frame Ass’y
902 GCAB-1024AWSA J Bottom Cabinet
903 QCNWN2042AWZZ J Speaker Cord [Left]
903 QCNWN2043AWZZ J Speaker Cord [Right]
904 XEBSD30P14000 J AA Screw,ø3×14mm
905 TLABM0126AWZZ J Label,Parts Cord [Left]
905 TLABM0127AWZZ J Label,Parts Cord [Right]
SP1,2 RSPA00024AW8P J Speaker
PACKING PARTS
SPAKA0315AWZZ J Packing Add.
SSAKH0066AWZZ J Polyethylene Bag,Center
Speaker
SSAKH0067AWZZ J Polyethylene Bag,Surround
Speaker
