CD-DP2500W/DK2500W
A
B
C
D
E
F
G
H
1
23456
Figure 9 CD MECHANISM EXPLODED VIEW
– 9 –
306-1
701
304
701
302
301
702
303
M1
703x2
305x2
SW4
M2
305
PWB-D
306-2
306-3
306
704
