Sharp CD-E250E - Page 31

03/2/17 CD-E250E(E)3.fm
31
CD-E250E
References
! CD player
! Tuner
! Cassette deck
! Front speaker
! Surround speaker
Type 3-disc multi-play compact disc player
Signal readout Non-contact, 3-beam semiconductor laser
pickup
D/A converter 1-bit D/A converter
Frequency
response
20 - 20,000 Hz
Dynamic range 90 dB (1 kHz)
Frequency range FM: 87.5 - 108 MHz
AM: 522 - 1,620 kHz
Frequency
response
125 - 8,000 Hz (normal tape)
Signal/noise ratio 50 dB (TAPE 1, playback)
50 dB (TAPE 2, recording/playback)
Wow and flutter 0.3 % (WRMS)
Type 2-way type speaker system
5 cm (2") tweeter
10 cm (4") woofer
Maximum input
power
46 W
Rated input power 23 W
Impedance 8 ohms
Dimensions Width: 200 mm (7-7/8")
Height: 305 mm (12")
Depth: 175 mm (6-7/8")
Weight 2.8 kg (6.2 lbs.)/each
Type 8 cm (3-1/8") full-range speaker
Maximum input
power
20 W
Rated input power 10 W
Impedance 16 ohms
Dimensions Width: 195 mm (7-11/16")
Height: 100 mm (4")
Depth: 140 mm (5-1/2")
Weight 0.7 kg (1.5 lbs.)/each
