PRICE
RANK
DESCRIPTION
NO.
PART CODE
NO. PARTS CODE
PRICE
RANK
DESCRIPTION
CD-E99
201-10 JKNBZ0924AWSA J AK Button,Operation B
201-11 JKNBZ0925AWSA J AL Button,Function
201-12 JKNBZ0926AWSA J AE Button,X-BASS/Equalizer
201-13 GCOVA1460AWSA J AC Cover,Sensor
201-14 GCOVA1351AWSA J AB Cover,Timer LED
201-15 MSPRD0151AWFJ J AB Cassette Spring,Tape 1
201-16 MSPRD0152AWFJ J AB Cassette Spring,Tape 2
201-17 MLIFP0008AWZZ J AD Damper
201-18 HBDGB1007AWSA J AD Badge,SHARP
202 92LCAB3839BASY J AN Side Panel Ass’y,Left
202- 1 ———— — Side Panel,Left
(Not Replacement Item)
202- 2 PCUSG0022AWZZ J AB Cushion,Leg
203 92LCAB3839CASY J AN Side Panel Ass’y,Right
203- 1 ———— — Side Panel,Right
(Not Replacement Item)
203- 2 PCUSG0022AWZZ J AB Cushion,Leg
204 GCAB-1197AWZZ J AM Loading Tray
205 GCAB-1215AWSB J AR Top Cabinet
206 GCOVA1469AWSB J AK Cover,CD Tray
207 GITAR1205AWSA J AM Rear Panel
208 KMECB0032AWZZ J BD Tape Mechanism Ass’y
208- 1 92LF513-894 J BE Head Plate Block [Tape 2]
208- 2 92LF525-357 J BD Motor with Pulley [Tape]
208- 3(PWB-F) 92LF567-719 J — Tape Mechanism PWB Ass’y
208- 4 92LF522-063 J AZ Clutc Ass’y Block [Tape 2]
208- 5 92LFF20D-12 J AN Belt,Main [Tape 2]
208- 6 92LF514-131 J AT Pinch Roller
208- 7 92LFF19S-31 J AL Belt,FF/REW [Tape 1]
208- 8 92LFF20B-13 J AN Belt,Main [Tape 1]
208- 9 92LF522-061 J AZ Clutc Ass’y Block [Tape 1]
208-10 92LFF19S-52 J AL Belt,FF/REW [Tape 2]
208-11 92LF513-895 J BD Head Plate Block [Tape 1]
209 LANGK0110AWFW J AE Bracket,Cassette Lock,Tape 1
210 LANGK0111AWFW J AE Bracket,Cassette Lock,Tape 2
211 LANGK0317AWFW J AF Bracket,Fan Support
212 LBSHC0005AWZZ J AD Bushing,AC Power Supply Cord
213 LCHSM0174AWFW J AN Chassis,Main
214 LCHSM0155AWZZ J AS Chassis,Loading
215 LHLDM1018AWZZ J AE Stabilizer
216 LHLDZ1455AWZZ J AF Holder,CD Mechanism
217 LHLDZ1358AWZZ J AF Stabilizer Holder
218 LHLDZ1433AWZZ J AD Holder,Gear
219 LHLDZ1410AWZZ J AD Holder,FL Display
220 LHLDZ1412AWZZ J AC Holder,LED
221 MCAMP0010AWZZ J AE Gear,Can Upper
222 MCAMP0011AWZZ J AE Gear,Can Lower
223 MLEVP0109AWZZ J AB Lever,Cam Lock
224 MLEVP0110AWZZ J AB Lever,Switch A
225 MLEVP0111AWZZ J AB Lever,Switch B
226 MLEVP0112AWZZ J AB Turntable Actuator
227 MLOKC0003AWZZ J AD Lock Lever,Cassette,Tape 1
228 MLOKC0004AWZZ J AD Lock Lever,Cassette,Tape 2
229 MSPRC0033AWFJ J AB Spring,Friction
230 MSPRD0109AWFJ J AB Spring,Cassette Lock,Tape 1
231 MSPRD0110AWFJ J AB Spring,Cassette Lock,Tape 2
232 MSPRP0057AWFW J AC Spring,Tray Lock
233 MSPRP0068AWFW J AB Spring,Motor Gear
234 NFANP0001AWZZ J AD Rotary Fan
235 NGERH0152AWZZ J AC Gear,Turntable Drive
236 NGERH0153AWZZ J AC Gear,Drive
237 NGERW0020AWZZ J AC Gear,Center
238 NGERW0021AWZZ J AC Gear,Idler
239 NGERW0022AWZZ J AD Gear,Worm
240 NGERW0023AWZZ J AC Motor Gear
241 NTNT-0022AWZZ J AK Turntable
242 PCUSG0022AWZZ J AB Cushion,Leg
243 PMAGF0007AWZZ J AD Magnet
244 PRDAR0267AWFW J AZ Heat Sink,Main
1 245 QACCD0022AWZZ J AM AC Power Supply Cord
246 QCNWN1860AWZZ J AC Lug Wire
1 247 QFSHD0001AWZZ J AB Holder,Fuse
248 92LCSPR1431C J AA Spring,Ring
250 92LNBAND1318A J AA Nylon Band,80mm
251 92LPT0303002 J AB Roller
252 LANGK0359AWFW J AD Bracket,Heat Sink
253 HDECQ0964AWSA J AF Panel,Edge Light
254 LHLDZ1451AWZZ J AC Holder,Edge Light
255 JKNBK0095AWSA J AK Knob,Volume
257 PSHEP0119AWZZ J AD Sheet,Edge Light
258 MLEVF0117AWFW J AC Plate,Support
259 92LSUPT1749D J AA Support,Magnet
260 LANGT0042AWFW J AC Bracket,PWB Support
261 PCOVQ7004AWFW J AK Cover,Fan
262 PRDAR0293AWFW J AN Heat Sink,Sub
601 XJBSD30P12000 J AA Screw,ø3×12mm
602 XEBSD30P12000 J AA Screw,ø3×12mm
603 LX-EZ0010AWFD J AA Screw,Special
604 LX-JZ0044AWFF J AB Screw,ø3×10mm
605 LX-HZ0009AWFD J AC Screw,ø2×13mm
606 XHBSD26P04000 J AA Screw,ø2.6×4mm
607 92LSC0314WBZI J AB Screw,ø3×14mm
608 XJBSD20P05000 J AA Screw,ø2×5mm
609 XHBSD40P08000 J AA Screw,ø4×8mm
610 XBBSD20P04000 J AA Screw,ø2×4mm
611 LX-JZ0010AFFD J AA Screw,ø3×10mm
612 XJSSD30P10000 J AA Screw,ø3×10mm
614 XHBSD30P06000 J AA Screw,ø3×6mm
615 LX-JZ0036AWFD J AB Screw,Special
616 LX-JZ0037AWFD J AB Screw,ø3×18mm
617 XEBSD30P10000 J AA Screw,ø3×10mm
618 XESSD30P10000 J AA Screw,ø3×10mm
621 XJBSD30P10000 J AA Screw,ø3×10mm
622 92LSC2608RBZI J AA Screw,ø2.6×8mm
623 92LSC0310RBZI J AB Screw,ø3×10mm
ACCESSORIES
QANTL0007AWZZ J AK AM/FM Loop Antenna
TINSE0527AWZZ J AE Operation Manual
TINSZ0924AWZZ J AB Quick Guide
TLABZ0593AWZZ J AB Energy Star Label (Set)
TLABZ1322AWZZ J AC Label,Feature [Tape 2]
TLABZ1389AWZZ J AC Label,Feature [Tape 1]
RRMCG0361AWSA J AS Remote Control
GFTAT1017AWSA J AK Battery Lid,Remote Control
P.W.B. ASSEMBLY (Not Replacement Item)
PWB-A1~5 92LPWB5183MANS J —
Main/Display/Headphones/LED A/
LED B (Combined Ass’y)
1 PWB-B1,2 92LPWB5183PWRS J — Power/Transformer
(Combined Ass’y)
PWB-C 92LPWB4896CDUS J — CD Servo
PWB-D QPWBF0027AWZZ J AD CD Motor (PWB Only)
PWB-E QPWBF0749AWZZ J AD CD Loading Motor (PWB Only)
PWB-F(208-3) 92LF567-719 J — Tape Mechanism
PWB-G 92LPWB5183PTCS J — Protect Circuit
OTHER SERVICE PART
UDSKA0004AFZZ J AZ CD Pickup Lens Cleaner
– 5 –
SPEAKER BOX PARTS
901 GBOXS2024AWSC J BE Speaker Box Ass’y,Right
901 GBOXS4024AWSC J BE Speaker Box Ass’y,Left
902 CPNLS1076AW02 J AX Front Panel Ass’y,Right
902 CPNLS1077AW02 J AX Front Panel Ass’y,Left
903 HPNLS1078AWSD J AY Side Panel,Right
903 HPNLS1079AWSD J AY Side Panel,Left
904 RSPXZ0003AWZX J AY Passive Radiator
905 XJBSD40P16000 J AB Screw,ø4×16mm
906 XJBSD30P12000 J AA Screw,ø3×12mm
907 XMPSF40P40000 J AC Screw,ø4×40mm
908 XMBSF40P16000 J AC Screw,ø4×16mm
909 TSPC-1238AWZZ J AD Label,Specifications
910 PFLT-0046AWZZ J AC Felt
911 QCNWN2487AWZZ J AM Speaker Cord Ass’y
(with Capacitor C1,2)
912 PCUSG0141AWZZ J Cushion,Leg
913 PFLT-0079AWZZ J Felt
SP1,2 RSPA10094AW6W J BE Woofer
SP3,4 RSPA00081AW6T J AW Tweeter
SP5~8 LHLDZ1457AWM1 J AT Super Tweeter Ass’y
CP-E99
