General Information
- Controls and indicators -
!
Main speaker
1. Woofer
2. Tweeter
3. Bass Reflex Duct
4. Speaker Terminals
!
Woofer
1. Woofer
2. Bass Reflex Duct
3. Speaker Terminals
!
Placing the speaker system
There is no distinction between the right and the left speakers.
Caution:
The metallic handles on the both sides of the speaker grill on the woofer are decora-
tions. Do not carry the woofers by them as this may damage the woofers.
Bi-amp system:
This unit employs the bi-amp system in which the low frequency range power ampli-
fier drives woofers, and mid-to-high frequency range power amplifier drives woofers
and tweeters of the main speaker respectively. Clearer sound will be assured by
amplifying two frequency bands individually using two characteristically different
amplifiers.
211
3
4
1
2
3
Main speaker (Left) Main speaker (Right)
Woofer (Left) Woofer (Right)
Woofer grilles are removable:
Make sure nothing comes into contact with the speaker
diaphragms when you remove the speaker grilles.
Note:
The speaker grilles on the main speakers are not re-
movable.
Tweeter
Woofer
Woofer
Woofer
Power amplifier
Mid-to-high range
(200 Hz - 20 kHz)
Ultra-low range
(60 Hz - 200 Hz)
Pre-amplifier
Pre-amplifier
Power amplifier
L-ch
