Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
43
27N-S100, 27N-S180
CN27S10/14/18
å D753 RH-DX0441CEZZ J Diode AC
å D754 RH-DX0441CEZZ J Diode AC
D755 VHD1SS119//-1 J Diode AB
å D756 RH-DX0441CEZZ J Diode AC
D2001 VHD1SS119//-1 J Diode AB
D2011 RH-EX0611GEZZ J Zener Diode, 5.1V AA
PACKAGED CITCUITS
å PR701 RMPTP0092CEZZ J Packaged Circuit AH
X801 RCRSB0205CEZZ J Crystal AF
or
RCRSB0001PEZZ
FILTERS
CF301 RFiLC0029TAZZ J Ceramic Filter AD
CF401 RFiLC0013CEZZ J Ceramic Filter AE
CF631 RFiLA0034CEZZ J Ceramic Filter AD
CF2040 RFiLC0121GEZZ J Ceramic Filter AD
or
RFiLA0099CEZZ
SF201 RFiLC0405CEZZ J SAW Filter AH
COILS
L201 VP-XF1R2K0000 J Peaking 1.2µH AB
L202 RCiLi0588CEZZ J VCO Coil AF
L251 VP-XF390K0000 J Coil (27N-S180, CN27S18) AB
L301 VP-XF8R2K0000 J Peaking 8.2µH AB
L302 RCiLi0613CEZZ J IF Coil AE
or
RCiLi0605CEZZ
L401 VP-XF6R8K0000 J Peaking 6.8µH AB
L402 VP-XF3R3K0000 J Peaking 3.3µH AB
L403 VP-XF8R2K0000 J Peaking 8.2µH AB
L404 VP-XF8R2K0000 J Peaking 8.2µH AB
L421 VP-XF680K0000 J Peaking 68µH (CN27S10) AB
L672 RCiLZ0101MEZZ M Coil AE
or
RCiLZ0102MEZZ
å L701 RCiLF0025PEZZ M Coil AK
å L702 RCiLF0025PEZZ M Coil AK
å L705 RCiLP0179CEZZ J Coil AD
L729 RCiLP0179CEZZ J Coil AD
L2040 RCiLB0131CEZZ J Oscillation Coil AE
TRANSFORMERS
T601 RTRNZ0057PEZZ R Transformer AK
çå T602 RTRNF0033MEZZ M H-Volt Transformer AY
or
RTRNF0037MEZZ
å T701 RTRNP0543CEZZ J Power Transformer AM
å T702 RTRNZ0017MEZZ M Transformer AM
or
RTRNZ0022MEZZ
CAPACITORS
[EL.··· Electrolytic, M-Poly.··· Metalized Polypro Film]
C51 VCEA0A1CW476M J 47 16V EL. AB
C53 VCEA0A1HW105M J 1 50V EL. AB
C54 VCEA0A1HW475M J 4.7 50V EL. AB
C55 VCEA0A1CW108M J 1000 16V EL. AD
C56 VCKYCY1CB104K J 0.1 16V Ceramic AB
C103 VCEA0A1CW228M J 2200 16V EL. AB
C201 VCKYMN1HB102K J 1000p 50V Ceramic AA
C202 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C203 VCKYCY1HB102K J 1000p 50V Ceramic AA
C204 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C205 VCEA0A1HW474M J 0.47 50V EL. AB
C206 VCEA0A1CW337M J 330 16V EL. AC
C207 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C208 VCEA0A1HW474M J 0.47 50V EL. AB
C209 VCKYCY1HB222K J 2200p 50V Ceramic AA
C210 VCKYCY1HB102K J 1000p 50V Ceramic AA
C251 VCQYTA1HM103K J 0.01 50V Mylar AB
(27N-S180, CN27S18)
PWB-A: DUNTKA126WEK4/K8 (27N-S100/CN27S10)
PWB-A: DUNTKA126WEK5 (27N-S180, CN27S18)
PWB-A: DUNTKA126WEL6 (CN27S14)
MAIN UNIT (Continued)
Q252 VS2SD601AR/-1 J 2SD601AR AC
(27N-S180, CN27S18)
Q253 VS2SD601AR/-1 J 2SD601AR AC
(27N-S180, CN27S18)
Q301 VS2SD601AR/-1 J 2SD601AR AC
Q401 VS2SD601AR/-1 J 2SD601AR AC
Q402 VS2SB709AR/-1 J 2SB709AR AC
or
VS2SA1037KR-1
Q403 VS2SD601AR/-1 J 2SD601AR AC
Q421 VS2SB709AR/-1 J 2SB709AR (CN27S10) AC
or
VS2SA1037KR-1
Q451 VS2SB709AR/-1 J 2SB709AR AC
or
VS2SA1037KQ-1
Q601 VS2SC2482//-1 J 2SC2482 AD
å Q602 VS2SD2539//1E J 2SD2539 AP
Q751 VS2SC3198-Y-1 J 2SC3198(Y) AA
Q901 VS2SD601AR/-1 J 2SD601AR AC
(27N-S180, CN27S10/14/18)
Q902 VS2SD601AR/-1 J 2SD601AR AC
(27N-S180, CN27S10/14/18)
Q903 VS2SD601AR/-1 J 2SD601AR AC
(27N-S180, CN27S10/14/18)
Q904 VS2SD601AR/-1 J 2SD601AR AC
(27N-S180, CN27S10/14/18)
Q2060 VS2SD601AR/-1 J 2SD601AR AC
Q2201 VS2SD601AR/-1 J 2SD601AR AC
Q2211 VS2SD601AR/-1 J 2SD601AR AC
DIODES
You can substitute "RH-DX0475CEZZ" for "VHD1SS119//-1".
D51 RH-EX0611GEZZ J Zener Diode, 5.1V AA
D52 RH-EX0673GEZZ J Zener Diode, 32V AB
D53 RH-EX0611GEZZ J Zener Diode, 5.1V AA
D103 VHD1SS119//-1 J Diode AB
D401 VHD1SS119//-1 J Diode AB
D402 RH-EX0604GEZZ J Zener Diode, 3.9V AB
D454 RH-EX0611GEZZ J Zener Diode, 5.1V AA
D455 VHD1SS119//-1 J Diode AB
D456 VHD1SS119//-1 J Diode AB
D457 RH-EX0217CEZZ J Zener Diode AB
D458 RH-EX0217CEZZ J Zener Diode AB
D459 VHD1SS119//-1 J Diode AB
å D501 RH-DX0131CEZZ J Diode AC
å D510 RH-DX0441CEZZ J Diode AC
D621 RH-EX0631GEZZ J Zener Diode, 9.1V AA
å D622 RH-DX0131CEZZ J Diode AC
çå D651 RH-DX0131CEZZ J Diode AC
çå D652 RH-EX1313CEZZ M Zener Diode, 9.1V AB
çå D653 VHD1SS119//-1 J Diode AB
çå D654 VHD1SS119//-1 J Diode AB
å D701 RH-DX0154CEZZ J Diode AC
å D702 RH-DX0154CEZZ J Diode AC
å D703 RH-DX0154CEZZ J Diode AC
å D704 RH-DX0154CEZZ J Diode AC
D705 VHD1SS82///1A J Diode AC
D706 RH-DX0066GEZZ J Diode AB
D707 VHD1SS82///1A J Diode AC
D708 RH-DX0066GEZZ J Diode AB
å D709 RH-DX0229CEZZ J Diode AF
å D712 RH-DX0407CEZZ J Diode AD
å D713 RH-EX0673GEZZ J Zener Diode, 32V AB
å D715 RH-EX0610GEZZ J Zener Diode AA
D716 VHD1SS119//-1 J Diode AB
D717 RH-EX0650GEZZ J Zener Diode, 16V AB
å D725 RH-DX0407CEZZ J Diode AD
å D751 RH-DX0441CEZZ J Diode AC
å D752 RH-DX0441CEZZ J Diode AC
