Sharp CP-C1W User Manual

PRICE
RANK
DESCRIPTIONNO.
PART CODE NO. PARTS CODE
PRICE
RANK
DESCRIPTION
CD-C1W, CP-C1W
RM09 VRD-MN2BD103J J AA 10 kohm,1/8W
RM10 VRD-ST2CD103J J AA 10 kohm,1/6W
RM11,12 VRD-ST2CD222J J AA 2.2 kohms,1/6W
RM23,24 VRD-ST2CD821J J AA 820 ohms,1/6W
RM25 VRD-MN2BD102J J AA 1 kohm,1/8W
RP01,02 VRD-MN2BD104J J AA 100 kohm,1/8W
RP05,06 VRD-MN2BD222J J AA 2.2 kohms,1/8W
RP07 VRD-MN2BD102J J AA 1 kohm,1/8W
RP08 VRD-ST2CD102J J AA 1 kohm,1/6W
RP09,10 VRD-ST2CD103J J AA 10 kohm,1/6W
RP11,12 VRD-MN2BD473J J AA 47 kohms,1/8W
RP13,14 VRD-ST2CD562J J AA 5.6 kohms,1/6W
RP15,16 VRD-ST2EE221J J AA 220 ohms,1/4W
RP37,38 VRD-MN2BD683J J AA 68 kohms,1/8W
RP101 RH-QX0003AWZZ J AK Posistor,2.2 ohms
RT01 VRD-MN2BD104J J AA 100 kohm,1/8W
RT02 VRD-MN2BD333J J AA 33 kohms,1/8W
RT03 VRD-ST2CD220J J AA 22 ohms,1/6W
RT04 VRD-MN2BD470J J AA 47 ohms,1/8W
RT05,06 VRD-MN2BD273J J AA 27 kohms,1/8W
RT05A VRD-MN2BD473J J AA 47 kohms,1/8W
RT06A VRD-MN2BD100J J AA 10 ohm,1/8W
RT07,08 VRD-MN2BD182J J AA 1.8 kohms,1/8W
RT07A VRD-MN2BD681J J AA 680 ohms,1/8W
RT08A VRD-MN2BD103J J AA 10 kohm,1/8W
RT09 VRD-ST2CD102J J AA 1 kohm,1/6W
RT09A VRD-ST2EE821J J AA 820 ohms,1/4W
RT10 VRD-MN2BD102J J AA 1 kohm,1/8W
RT10A VRD-ST2CD472J J AA 4.7 kohms,1/6W
RT11,12 VRD-MN2BD104J J AA 100 kohm,1/8W
RT13,14 VRD-ST2CD472J J AA 4.7 kohms,1/6W
RT15,16 VRD-MN2BD102J J AA 1 kohm,1/8W
RT17 VRD-MN2BD183J J AA 18 kohms,1/8W
RT18 VRD-ST2CD183J J AA 18 kohms,1/6W
RT19,20 VRD-MN2BD562J J AA 5.6 kohms,1/8W
RT21,22 VRD-MN2BD104J J AA 100 kohm,1/8W
RT23,24 VRD-ST2CD102J J AA 1 kohm,1/6W
RT25 VRD-ST2CD221J J AA 220 ohms,1/6W
RT27 VRD-ST2CD473J J AA 47 kohms,1/6W
RT41 VRD-ST2CD221J J AA 220 ohms,1/6W
RY03~12 VRS-TV2AB104J J AA 100 kohm,1/10W
RY13 VRD-ST2CD104J J AA 100 kohm,1/6W
RY14~28 VRS-TV2AB104J J AA 100 kohm,1/10W
RY29 VRS-TV2AB330J J AA 33 ohms,1/10W
RY30,31 VRD-ST2CD330J J AA 33 ohms,1/6W
RY32~38 VRS-TV2AB330J J AA 33 ohms,1/10W
RY39 VRS-TV2AB104J J AA 100 kohm,1/10W
RY40~44 VRS-TV2AB102J J AA 1 kohm,1/10W
RY56 VRS-TV2AB104J J AA 100 kohm,1/10W
OTHER CIRCUITRY PARTS
BI851/CNS851 QCNWN1091AWZZ J AG Connector Ass’y,4/4Pin
BIM1 QCNWN1005AWZZ J AF Connector Ass’y,4Pin
BIM2/CNS2 QCNWN1020AWZZ J AF Connector Ass’y,5/5Pin
BIM3 QCNWN0987AWZZ J AH Connector Ass’y,6Pin
CFW1 QCNCWZG27AWZZ J AE Socket,27Pin
CFW2 QCNCWZG27AWZZ J AE Socket,27Pin
CFW852 QCNCWZG14AWZZ J AD Socket,14Pin
CFW903 QCNWN1089AWZZ J AH Socket,14Pin
CNP1 92LCONPB7BPHK J AC Plug,7Pin
CNP2 92LCONPB8BPHK J AC Plug,8Pin
CNP3 92LCONE6P53253 J AC Plug,6Pin
CNP3A 92LCONE6P53254 J AC Plug,6Pin
CNP11 92LCONE4P53015 J AC Plug,4Pin
CNP12 92LCONE5P53253 J AB Plug,5Pin
CNP13 92LCONE6P53253 J AC Plug,6Pin
CNP101 92LCONE3P53253 J AB Plug,3Pin
CNP102 92LCONE7P53253 J AC Plug,7Pin
CNP201 QCNCWZS10AWZZ J AK Socket,10Pin
CNP202 QCNCW010LAWZZ J AD Plug,11Pin
CNP303 QCNCM010LAWZZ J AC Plug,11Pin
CNP851 92LCONE-4P5267 J Plug,4Pin
CNP901 92LCONE2P53253 J AB Plug,2Pin
CNS1A/B QCNWN0858AWZZ J AG Connector Ass’y,8/8Pin
CNS2A/B QCNWN0859AWZZ J AF Connector Ass’y,7/7Pin
CNS3A/B QCNWN0857AFZZ J AK Connector Ass’y,6/6Pin
CNS101A/B QCNWN1095AWZZ J AG Connector Ass’y,3/3Pin
CNS102A/B QCNWN1096AWZZ J AM Connector Ass’y,7/6Pin
CNS701 QCNCMZS10AWZZ J AK Socket,10Pin
CNS901 QCNWN1090AWZZ J AD Connector Ass’y,2Pin
! F820 92LFUSE-T501E J AD Fuse,T500mA L 250V
! F853 92LFUSE-T202E J AD Fuse,T2A L 250V
! F854 92LFUSE-T502-E J AD Fuse,T5A L 250V
! F855,856 92LFUSE-T252-E J AD Fuse,T2.5A L 250V
! F857,858 92LFUSE-T502-E J AD Fuse,T5A L 250V
FL701 VVKCK1627M/-1 J BM FL Display
FW1 QCNWN1085AWZZ J AF Flat Cable,27Pin
FW201 QCNWN1101AWZZ J AE Flat Wire,8Pin
FW701 QCNWN1092AWZZ J AE Flat Cable,6Pin
FW853 QCNWN1100AWZZ J AC Flat Cable,3Pin
FW901 QCNWN1087AWZZ J AD Flat Cable,5Pin
FW903 QCNCW012PAWZZ J AE Flat Cable,14Pin
FW904 QCNWN1088AWZZ J AF Flat Wire,8Pin
FWM1 QCNWN1093AWZZ J AF Flat Wire,8Pin
FWM2 QCNWN1094AWZZ J AH Flat Wire,13Pin
J901 QJAKM0005AWZZ J AD Jack,Headphones
JT01 QSOCJ0205AWZZ J AG Jack,VIDEO/AUX 1
JT02 QSOCJ0205AWZZ J AG Jack,LINE OUT
M701 92LMTR1854CASY J AS Motor with Chassis [Spindle]
M702 92LMTR1854BASY J AP Motor with Gear [Sled]
M901 92LMTR1810A J AK Motor,Air Cooling Fan
MM1(300-3) 92PF525-319 J AW Motor with Pulley [Tape]
MOB1 RMOTV0373AFM1 J AQ Main Cam Motor Ass’y
MOB2 RMOTV0373AFM1 J AQ Tray Motor Ass’y
PHM1,2 ———— — Phote Interrupter (Supplies at
REF NO. PWB-G/PWB-H)
RL851 RRLYD0007AWZZ J AQ Relay
RL901 RRLYD0004AWZZ J AP Relay
RX701 VHL22043TE2-1 J Remote Control
Sensor,22043TE2
SO301 QTANC0301AWZZ J AH Terminal,Antenna
SO901 QTANA0404AWZZ J AF Terminal,Speaker
SOL1,2 ———— — Solenoid (Supplies at REF NO.
PWB-G/PWB-H)
SW202 QSW-S0024AWZZ J AE Switch,Slide Type
[Span Selector]
SW701 QSW-Z0003AWZZ J AH Switch,Rotary Type
[Volume Up/Down]
SW702 QSW-Z0003AWZZ J AH Switch,Rotary Type [Jog Dial]
SW702A QSW-F9001AWZZ J AE Switch,Push Type [Pickup In]
SW703 QSW-K0006AWZZ J AC Switch,Key Type [X-BASS]
SW704 QSW-K0006AWZZ J AC Switch,Key Type
[Equalizer/Demo]
SW705 QSW-K0006AWZZ J AC Switch,Key Type [SRS Mode]
SW706 QSW-K0006AWZZ J AC Switch,Key Type [SRS Pass]
SW707 QSW-K0006AWZZ J AC Switch,Key Type [FF]
SW708 QSW-K0006AWZZ J AC Switch,Key Type [Stop]
SW709 QSW-K0006AWZZ J AC Switch,Key Type [Edit Normal]
SW710 QSW-K0006AWZZ J AC Switch,Key Type [Edit High]
SW711 QSW-K0006AWZZ J AC Switch,Key Type [Record/Pause]
SW712 QSW-K0006AWZZ J AC Switch,Key Type [Forward Play]
SW713 QSW-K0006AWZZ J AC Switch,Key Type [Dolby-NR]
SW717 QSW-K0006AWZZ J AC Switch,Key Type [Rewind]
SW718 QSW-K0006AWZZ J AC Switch,Key Type [CD Pause]
SW719 QSW-K0006AWZZ J AC Switch,Key Type [Reverse Play]
SW720 QSW-K0006AWZZ J AC Switch,Key Type
[Reverse Mode]
SW721 QSW-K0006AWZZ J AC Switch,Key Type [Clock]
SW722 QSW-K0006AWZZ J AC Switch,Key Type [Timer]
SW723 QSW-K0006AWZZ J AC Switch,Key Type [Sleep]
SW724 QSW-K0006AWZZ J AC Switch,Key Type [Video/AUX]
SW725 QSW-K0006AWZZ J AC Switch,Key Type [Tape 1/2]
SW726 QSW-K0006AWZZ J AC Switch,Key Type [Tuner (BAND)]
SW727 QSW-K0006AWZZ J AC Switch,Key Type [CD]
SW732 QSW-K0006AWZZ J AC Switch,Key Type [Clear]
SW733 QSW-K0006AWZZ J AC Switch,Key Type [Memory/Set]
SW734 QSW-K0006AWZZ J AC Switch,Key Type
[Power On/Stand-by]
SW739 QSW-K0006AWZZ J AC Switch,Key Type
[Disc 3 Open/Close]
SW740 QSW-K0006AWZZ J AC Switch,Key Type [Disc 3]
SW741 QSW-K0006AWZZ J AC Switch,Key Type
[Disc 2 Open/Close]
SW742 QSW-K0006AWZZ J AC Switch,Key Type [Disc 2]
SW743 QSW-K0006AWZZ J AC Switch,Key Type
[Disc 1 Open/Close]
SW744 QSW-K0006AWZZ J AC Switch,Key Type [Disc 1]
! SW851 QSOCE0008AWZZ J AH Switch,Slide Type
[Voltage Selector]
SWB101,102 QSW-F0353AFZZ J AD Switch,Leaf Type [Cam1,2]
SWB103,104 QSW-F0353AFZZ J AD Switch,Leaf Type [Cam3,4]
SWB105 QSW-P0920AFZZ J AC Switch,Push Type [CD Eject]
SWB107 QSW-P0920AFZZ J AC Switch,Push Type [CD In]
– 7 –
