Sharp CP-C1W

NO.
PRICE
RANK
DESCRIPTIONPARTS CODE
NO. PART CODE
PRICE
RANK
DESCRIPTION
CD-C1W, CP-C1W
SWB108 QSW-P0920AFZZ J AC Switch,Push Type [CD Set]
SWE1 ———— — Switch,Leaf Type [Tape 1 Play]
(Supplies at REF NO. PWB-G)
SWE2 ———— — Switch,Leaf Type [Tape 1 CrO2]
(Supplies at REF NO. PWB-G)
SWE4 ———— — Switch,Leaf Type [Tape 2 Play]
(Supplies at REF NO. PWB-H)
SWE5 ———— — Switch,Leaf Type [Tape 2 CrO2]
(Supplies at REF NO. PWB-H)
SWE7 ———— — Switch,Leaf Type
[Tape 2 Side A FP]
(Supplies at REF NO. PWB-H)
SWE8 ———— — Switch,Leaf Type
[Tape 2 Side B FP]
(Supplies at REF NO. PWB-H)
WT853 92LCONE3P52287 J AC Socket,3Pin
WT902 92LCONE5P52287 J AC Socket,5Pin
WTM1 92LCONE8P52287 J AD Plug,8Pin,Wire Trap
WTM2 QCNCW012NAWZZ J AE Plug,13Pin,Wire Trap
CD MECHANISM PARTS
301 NGERH0011AWZZ J AC Gear,Middle
302 NGERH0012AWZZ J AC Gear,Drive
303 MLEVP0010AWZZ J AC Rail,Guide
304 NSFTM0002AWFW J AE Shaft,Guide
305 PCUSG0427AFSC J AC Cushion
! 306 RCTRH8164AFZZ J BF Pickup Unit Ass’y
306- 1 ———— — Pickup Unit
(Not Replacement Item)
306- 2 NGERR0043AFZZ J AC Gear,Rack
306- 3 MSPRC0961AFZZ J AA Spring,Rack
307 PCUSG0001AWSA J AD Insulator
308 PCUSG0004AWSA J AD Insulator
701 92L2R6S+6CZ J AB Screw,ø2.6×6mm
702 XHBSD20P05000 J AA Screw,ø2×5mm
703 XBBSD20P03000 J AA Screw,ø2×3mm
704 92L1R5WC3R8R25 J AA Washer,ø1.5×ø3.8×0.25mm
M701 92LMTR1854CASY J AS Motor with Chassis [Spindle]
M702 92LMTR1854BASY J AP Motor with Gear [Sled]
SW702A QSW-F9001AWZZ J AE Switch,Push Type [Pickup In]
CHANGER MECHANISM
101 LCHSM0037AWZZ J AP Main Base
102 LANGF0024AWZZ J AE Top Board
103 NROLP0007AWZZ J AB Rollar,Cam Guide
104 NPLYR0004AWZZ J AC Pulley,Drive
105 NGERH0052AWZZ J AC Gear,Idler
106 NGERH0053AWZZ J AB Gear,Cam
107 NGERH0054AWZZ J AB Gear,Midle
108 NGERH0057AWZZ J AB Gear,Tray Idler
109 MCAMP0127AFZZ J AR Main Cam
110 MLEVP0056AWZZ J AC Lever,Front Switch
111 MLEVP0057AWM1 J AC Rear Switch Lever Ass’y
112 MLEVP0058AWZZ J AB Lever,Tray Lock
113 PGIDM0018AWZZ J AF Holder,Mechanism
114 PGIDM0019AWZZ J AE Holder,Stabilizer
115 LHLDM1008AWZZ J AD Stabilizer
116 PGIDM0017AWZZ J AC Guide,Mechanism Holder
119 GCOVA1152AWZZ J AL Tray,Disc Guide
120 GCOVA1153AWZZ J AF Tray,Disc
121 LANGF0025AWZZ J AB Bracket,Switch
122 NSFTL0001AWZZ J AB Shaft,Tray Change
123 MSPRD0078AWFJ J AB Spring,Tray Switch
124 MSPRD0080AWFJ J AB Spring,Tray Lock Lever
125 MSPRD0079AWFJ J AB Spring,Disc Stop
126 NBLTK0028AWZZ J AB Belt,Tray Drive
127 NBLTK0027AWZZ J AB Belt,Cam Drive
128 PMAGF0001AWZZ J AF Magnet
129 92LN-BAND1318A J AA Nylon Band,80mm
130 PGUMS0012AWZZ J AB Tray Rubber
131 LANGF0028AWZZ J AB Bracket,Mechanism Holder
132 LCHSM0038AWZZ J AK Changer Box
133 NGERH0055AWZZ J AC Gear,Center
134 NGERH0056AWZZ J AB Gear,Center Tray
135 NGERH0058AWZZ J AB Gear,Tray Drive
136 MLEVP0052AWZZ J AC Lever,Tray Change
137 MLEVP0053AWZZ J AC Lever,Top Joint
138 MLEVP0054AWZZ J AC Lever,Midle Joint
139 MLEVP0055AWZZ J AC Lever,Bottom Joint
801 XBPSD26P04000 J AA Screw,ø2.6×4mm
802 XEBSD20P07000 J AB Screw,ø2×7mm
803 XEBSD20P06000 J AA Screw,ø2×6mm
804 XEBSD26P12000 J AA Screw,ø2.6×12mm
805 LX-EZ0005AWFD J AA Screw,ø2.6×10mm
MOB1 RMOTV0373AFM1 J AQ Main Cam Motor Ass’y
MOB2 RMOTV0373AFM1 J AQ Tray Motor Ass’y
SWB101,102 QSW-F0353AFZZ J AD Switch,Leaf Type [Cam1,2]
SWB103,104 QSW-F0353AFZZ J AD Switch,Leaf Type [Cam3,4]
SWB105 QSW-P0920AFZZ J AC Switch,Push Type [CD Eject]
SWB106 QSW-P0920AFZZ J AC Switch,Push Type
[CD Tray Close]
SWB107 QSW-P0920AFZZ J AC Switch,Push Type [CD In]
SWB108 QSW-P0920AFZZ J AC Switch,Push Type [CD Set]
CABINET PARTS
201 92LCAB2695AS1 J Front Panel Ass’y
201- 1 ———— — Front Panel
(Not Replacement Item)
201- 2 PCUSG0022AWZZ J AB Cushion,Leg
201- 3 HDECP0043AWSA J AE Panel,Function
202 92LPNL2695AS1 J FL Panel Ass’y
202- 1 HBDGB1006AWSA J AD Badge,SHARP
202- 2 HDECQ0283AWSA J AU Panel,FL Display
203 KNOB2695AASY1 J AR Disc No.Button Ass’y
204 KNOB2695BASY1 J AT Operation Button Ass’y
205 GCAB-1049AWSA J AR Top Cabinet
206 GCOVA1173AWSA J AK Cover,Disc Tray 1
207 GCOVA1174AWSA J AK Cover,Disc Tray 2
208 GCOVA1175AWSA J AK Cover,Disc Tray 3
211 GDORF0049AWSA J AM Cassette Holder,Tape 1
212 GDORF0050AWSA J AM Cassette Holder,Tape 2
213 GITAR0285AWSA J AT Rear Panel
214 GITAS0044AWSA J AP Side Panel,Left
215 GITAS0045AWSA J AP Side Panel,Right
217 HDECQ0281AWSA J AH Decoration Plate,Cassette
Holder,Tape 1
218 HDECQ0282AWSA J AH Decoration Plate,Cassette
Holder,Tape 2
219 HDECQ0285AWSA J AL Panel,Operation Botton
220 JKNBK0052AWSA J AF Knob,Volume Up/Down
221 JKNBK0053AWSA J AF Knob,Jog Dial
222 JKNBZ0455AWSA J AF Button,Power On/Stand-by
223 JKNBZ0457AWSA J AF Button,Function
224 JKNBZ0458AWSA J AF Button,X-BASS
225 JKNBZ0459AWSA J AF Button,SRS
226 LANGK0057AWFW J AE Bracket,Heat Sink,Front
227 LANGK0058AWFW J AE Bracket,Heat Sink,Rear
228 LANGK0059AWFW J AD Bracket,Fan Motor
229 LANGK0104AWFW J AK Bracket,Main PWB
230 LANGK0110AWFW J AE Bracket,Cassette Lock,Tape 1
231 LANGK0111AWFW J AE Bracket,Cassette Lock,Tape 2
232 LANGK0113AWFW J AL Bracket,Main PWB Supt,Right
! 233 LBSHC0002AWZZ J AD Bushing,AC Power Supply Cord
234 LCHSM0065AWFW J AV Main Chassis
235 LCHSZ0012AWZZ J AQ Holder,CD Mechanism
237 LHLDZ1171AWZZ J AF Holder,FL Display
238 LHLDZ1172AWZZ J AD Holder,LED Operation,Left
239 LHLDZ1173AWZZ J AD Holder,LED Operation,Right
240 LHLDZ1174AWZZ J AD Holder,LED Disc No.
241 MLIFP0003AWZZ J AE Damper,Cassette Holder
242 MLOKC0001AWZZ J AD Cassette Lock,Tape 1
243 MLOKC0002AWZZ J AD Cassette Lock,Tape 2
244 MSPRD0092AWFJ J AB Spring,Cassette,Tape 1
245 MSPRD0093AWFJ J AB Spring,Cassette,Tape 2
246 MSPRD0109AWFJ J AB Spring,Cassette Lock,Tape 1
247 MSPRD0110AWFJ J AB Spring,Cassette Lock,Tape 2
248 NFANP0001AWZZ J AD Rotary Fan
249 PCUSG0022AWZZ J AB Cushion,Leg
250 PRDAR0065AWFW J AD Heat Sink,Diode
251 PRDAR0095AWFW J BB Heat Sink,Main
252 PRDAR0096AWFW J AM Heat Sink,Sub
! 253 QACCA0001AW00 J AM AC Power Supply Cord
[For Saudi Arabia]
! 253 QACCB0005AW00 J AQ AC Power Supply Cord
[For Hong Kong]
! 253 QACCE0008AW00 J AG AC Power Supply Cord
[Except for Australia/New
Zealand/Taiwan/Saudi Arabia]
! 253 92LCORDA1387C J AP AC Power Supply Cord
[For Australia/New Zealand]
! 253 92LCORDT1699A J AL AC Power Supply Cord
[For Taiwan]
– 8 –
