– 11 –
CD-K7000V,CP-C7000
Figure 11-1
Figure 11-2
Figure 11-3
CP-C7000
1 Woofer 1. Front Panel ............ (A1) x1 11-5
2. Screw ..................... (A2) x8 11-6
2 Tweeter 1. Front Panel ............ (B1) x1 12-1
2. Screw ..................... (B2) x4 12-2
3 Mid Range 1. Screw ..................... (C1) x4 12-2
4 Super Tweeter 1. Screw ..................... (D1) x2 12-2
STEP REMOVAL
PROCEDURE
FIGURE
Figure 11-4
Figure 11-5 Figure 11-6
Caution:
The metallic handles on the both sides of the speaker grill on
the main speaker are decorations.
Do not carry the speakers by them as this may damage the
speakers.
Turntable
Slide
Chassis
(N2)x1
CD Player Unit
(N1)x2
1
3
2
(P1)x3
(P1)x3
(Q3)x2
(Q2)x2
(Q3)x2
CD Video
PWB
Slide
Chassis
(Q1)x1
ø3x8mm
(R2)x3
(R1)x1
(S1)x5
(R1)x1
Loading
Motor
PWB
CD
Mechanism
Driver should
be pried away
from speaker box.
Screwdriver
(A1) x1
(A2) x8
ø4x16mm
Woofer
Front
Panel
