Sharp CP-C7000

PRICE
RANK
DESCRIPTIONNO.
PARTS CODE NO. PARTS CODE
PRICE
RANK
DESCRIPTION
CD-K7000V,CP-C7000
– 1 –
INTEGRATED CIRCUITS
IC1 VHILA9235M/-1 J AQ Servo Amp.,LA9235M
IC2 VHILC78636E-1 J Servo DSP,LC78636E
IC3 VHIM63001FP-1 J AX Focus/Tracking/Spin/Sled Driver,
M63001FP
IC101 VHIAN7345K/-1 J AM Playback and Record/Playback
Amp.,AN7345K
IC301 VHITA7358AP-1 J AG FM Front End,TA7358AP
IC302 VHILC72131/-1 J AP PLL (Tuner),LC72131
IC303 VHILA1832S/-1 J AN FM IF Det./FM Mpx./AM IF,
LA1832S
IC401 VHIKIA4558P-1 J AC Ope Amp.,KIA4558P
IC561~563 VHIKIA4558P-1 J AC Ope Amp.,KIA4558P
IC601 VHILC75341/-1 J AM Audio Processor,LC75341
IC701 RH-IX0360AWZZ J System Microcomputer,
IX0360AW
IC702,703 VHIBU2092F/-1 J AM Input/Output Expander,BU2092F
IC704 VHIKIA7042AP1 J AC Reset,KIA7042AP
IC860 VHIKIA4558P-1 J AC Ope Amp.,KIA4558P
IC901 VHISTK4115G-1 J BP Power Amp.,STK4115G
ICK1 VHIM65856SP-1 J AX Mic Amp.,M65856SP
ICK2 VHIM65847AFP1 J Key Control,M65847AFP
ICV1 RH-IX0352AWZZ J MPEG Controller,IX0352AW
ICV2 VHID61012GC-1 J BP MPEG Decoder,D61012GC
ICV3 VHISDM4260C-1 J AY DRAM,SDM4260C
ICV4 VHINJM2267M-1 J AH Video Operation Amp.,
NJM2267M
TRANSISTORS
Q1 VSKTC3265Y/-1 J AC Silicon,NPN,KTC3265 Y
Q2 VSKRC102S//-1 J AB Digital,NPN,KRC102 S
Q3,4 VSKTA1504GR-1 J AB Silicon,PNP,KTA1504 GR
Q103~106 VS2SC1845F/-1 J AC Silicon,NPN,2SC1845 F
Q107,108 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q109 VSKTA1266GR-1 J AB Silicon,PNP,KTA1266 GR
Q110,111 VSKRC104M//-1 J AC Digital,NPN,KRC104 M
Q121,122 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q124 VS2SA1015GR-1 J AB Silicon,PNP,2SA1015 GR
Q126 VSKRC104M//-1 J AC Digital,NPN,KRC104 M
Q128 VSKTC3203Y/-1 J AC Silicon,NPN,KTC3203 Y
Q129 VSKRC104M//-1 J AC Digital,NPN,KRC104 M
Q302 VSKTC3194Y/-1 J AD Silicon,NPN,KTC3194 Y
Q360 VSKTA1266GR-1 J AB Silicon,PNP,KTA1266 GR
Q401 VSKRA107M//-1 J AE Digital,PNP,KRA107 M
Q402 VS2SK246GR/-1 J AB FET,2SK246 GR
Q603~606 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q701~703 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q704,705 VSKTA1271Y/-1 J AC Silicon,PNP,KTA1271 Y
Q706,707 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q708 VSKTA1273Y/-1 J AE Silicon,PNP,KTA1273 Y
Q709 VSKRC102M//-1 J AC Digital,NPN,KRC102 M
Q710~712 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q713~716 VSKTA1271Y/-1 J AC Silicon,PNP,KTA1271 Y
Q801 VHIAN78L05/-1 J AE Constant Voltage Regulator,
AN78L05
Q802 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q803 VSKTA1274Y/-1 J AE Silicon,PNP,KTA1274 Y
Q850 VSKTC2026//-1 J AF Silicon,NPN,KTC2026
Q851 VHIKIA7810AP1 J AF Voltage Regulator,KIA7810 AP
Q852 VHIKIA7805P-1 J AF Voltage Regulator,KIA7805 P
Q862,863 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q864 VSKRC102M//-1 J AC Digital,NPN,KRC102 M
Q865 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q901~904 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q905 VSKRC107M//-1 J AC Digital,NPN,KRC107 M
Q907 VSKTC3203Y/-1 J AC Silicon,NPN,KTC3203 Y
Q910,911 VSKRC107M//-1 J AC Digital,NPN,KRC107 M
QK1 VSKTC3203Y/-1 J AC Silicon,NPN,KTC3203 Y
QK2,3 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
QV2 VSKTA1298Y/-1 J AC Silicon,PNP,KTA1298 Y
QV3 VSKRC104S//-1 J AC Digital,NPN,KRC104 S
QV4 VSKTA1298Y/-1 J AC Silicon,PNP,KTA1298 Y
DIODES
D21,22 VHDKDS193//-1 J AC Silicon,KDS193
D101,102 VHD1SS133//-1 J AA Silicon,1SS133
D301~305 VHD1SS133//-1 J AA Silicon,1SS133
D401 VHD1SS133//-1 J AA Silicon,1SS133
D561~566 VHD1SS133//-1 J AA Silicon,1SS133
D601,602 VHD1SS133//-1 J AA Silicon,1SS133
D705 VHD1SS133//-1 J AA Silicon,1SS133
D707 VHD1SS133//-1 J AA Silicon,1SS133
D710 VHD1SS133//-1 J AA Silicon,1SS133
D712~718 VHD1SS133//-1 J AA Silicon,1SS133
D720~725 VHD1SS133//-1 J AA Silicon,1SS133
D801 VHD1SS133//-1 J AA Silicon,1SS133
D802~805 VHD1N4004S/-1 J AB Silicon,1N4004S
D806~808 VHD1SS133//-1 J AA Silicon,1SS133
! D809 VHDTS6B04GM-1 J AP Silicon,TS6B04GM
! D810 VHDD10XB60F-1 J AL Silicon,D10XB60F
! D811~814 VHD1N4004S/-1 J AB Silicon,1N4004S
D815~818 VHD1N4004S/-1 J AB Silicon,1N4004S
D860~862 VHD1SS133//-1 J AA Silicon,1SS133
D901,902 VHD1N4004S/-1 J AB Silicon,1N4004S
D903,904 VHD1SS133//-1 J AA Silicon,1SS133
D905,906 VHD1N5402M/-1 J AE Silicon,1N5402M
D907~913 VHD1SS133//-1 J AA Silicon,1SS133
DK1,2 VHD1SS133//-1 J AA Silicon,1SS133
DV4,5 VHDKDS193//-1 J AC Silicon,KDS193
LED701~712 VHP4204UYT7-1 J AD LED,Yellow,4204UYT7
LED713~715 VHP4204UGT7-1 J AD LED,Green,4204UGT7
LED716 VHP4204UYT7-1 J AD LED,Yellow,4204UYT7
LED722 VHP4204SRT7-1 J AD LED,Red,4204SRT7
ZD61 VHEZ02W3R9Z-1 J Zener,3.9V,Z02W3.9Z
ZD351 VHEMTZJ5R1B-1 J AC Zener,5.1V,MTZJ5.1B
ZD561 VHEMTZJ6R2C-1 J AC Zener,6.2V,MTZJ6.2C
ZD801 VHEMTZJ360C-1 J AB Zener,36V,MTZJ36C
ZD802 VHEMTZJ6R2A-1 J AA Zener,6.2V,MTZJ6.2A
ZD901,902 VHEMTZJ130B-1 J AC Zener,13V,MTZJ13B
ZD951 VHEMTZJ130B-1 J AC Zener,13V,MTZJ13B
ZDK1 VHEMTZJ5R6B-1 J AD Zener,5.6V,MTZJ5.6B
FILTERS
BF301 RFILR0008AWZZ J AE Band Pass Filter
CF303 RFILF0124AFZZ J AD FM IF,10.7 MHz
CF351 RFILF0003AWZZ J AK FM IF
CF352 RFILA0009AWZZ J AE AM IF
TRANSFORMERS
T301 RCILB0065AWZZ J AC OSC,FM
T302 RCILI0017AWZZ J AB FM IF
T303 RCILA0052AWZZ J AE AM Antenna
T306 RCILB0058AWZZ J AC OSC,AM
T351 RCILI0019AWZZ J AD AM IF
! T801 RTRNP0311AWZZ J BN Power
! T802 RTRNP0239AWZZ J AP Power
COILS
L61 RCILC0006AWZZ J AH 0.82 µH,Choke
L62 RCILC0007AWZZ J 2.2 µH,Choke
L63,64 RCILC0006AWZZ J AH 0.82 µH,Choke
L104 VP-MK331K0000 J AB 330 µH,Choke
L312 RCILR0056AWZZ J AB FM RF
L351,352 VP-DH101K0000 J AB 100 µH,Choke
L701 VP-DH101K0000 J AB 100 µH,Choke
L901~904 RCILZ0137AFZZ J AA 0.29 µH
VARIABLE RESISTORS
VRK1 92LVRR1674A J AF 20 kohms (B),Semi-VR
[Mic 1 Volume]
VRK2 92LVRR1674A J AF 20 kohms (B),Semi-VR
[Mic 2 Volume]
VARIABLE CAPACITORS
VD301 VHCSVC348S/-1 J AK Variable Capacitance,SVC348S
VD302,303 VHCSVC211C/-1 J AG Variable Capacitance,SVC211C
VIBRATORS
X351 92LCRSTL1425A J AF Crystal,456 kHz
X352 RCRSP0015AWZZ J Crystal,4.5 MHz
XL1 92LCRSTL1746A J AC Ceramic,16.934 MHz
XL701 RCRSP0003AWZZ J AH Crystal,4.1943 MHz
CD-K7000V
