PRICE
RANK
DESCRIPTIONNO.
PARTS CODE NO. PARTS CODE
PRICE
RANK
DESCRIPTION
CD-K7000V,CP-C7000
C637 VCKYPA1HB102K J AA 0.001 µF,50V
C641,642 VCQYKA1HM332K J AA 0.0033 µF,50V,Mylar
C709 VCEAZA1HW476M J AB 47 µF,50V,Electrolytic
C715 VCEAZA1HW476M J AB 47 µF,50V,Electrolytic
C716,717 VCEAZA1HW225M J AB 2.2 µF,50V,Electrolytic
C719 VCEAZA1EW476M J AB 47 µF,25V,Electrolytic
C720,721 VCKYBT1HB102K J AA 0.001 µF,50V
C722 VCEAZA1HW476M J AB 47 µF,50V,Electrolytic
C723 VCCSMN1HL150J J AA 15 pF,50V
C724 VCCSMN1HL180J J AA 18 pF,50V
C725 VCKZPA1HF223Z J AA 0.022 µF,50V
C726 RC-EZD227AF1A J AC 220 µF,10V,Electrolytic
C727 RC-EZD104AF1H J AB 0.1 µF,50V,Electrolytic
C728 VCTYMN1CY103N J AA 0.01 µF,16V
C729 VCEAZA1HW335M J AB 3.3 µF,50V,Electrolytic
C730 VCTYMN1EF223Z J AA 0.022 µF,25V
C731 RC-EZD106AF1H J AB 10 µF,50V,Electrolytic
C732 VCKZPA1HF223Z J AA 0.022 µF,50V
C733 VCEAZA1EW476M J AB 47 µF,25V,Electrolytic
C734 VCEAZA1CW476M J AB 47 µF,16V,Electrolytic
C735 VCTYMN1EF223Z J AA 0.022 µF,25V
C736 VCEAZA1CW476M J AB 47 µF,16V,Electrolytic
C737 VCTYMN1EF223Z J AA 0.022 µF,25V
C738 RC-EZD227AF1A J AC 220 µF,10V,Electrolytic
C801 RC-KZ002LAWZZ J AE 0.0047 µF,250V,Ceramic
C802 VCQYKA1HM473J J AB 0.047 µF,50V,Mylar
C803 VCEAZV1VW477M J AD 470 µF,35V,Electrolytic
C804 VCEAZA1CW106M J AC 10 µF,16V,Electrolytic
C805 VCEAZV0JW228M J AC 2200 µF,6.3V,Electrolytic
C809,810 VCFYDA1HA224J J AB 0.22 µF,50V,Polyester
C811,812 VCQYKU2AM224K J AB 0.22 µF,100V,Mylar
C813,814 VCFYDA1HA224J J AB 0.22 µF,50V,Polyester
C815,816 VCEAZA1HW107M J AC 100 µF,50V,Electrolytic
C817 VCEAZV1JW227M J AC 220 µF,63V,Electrolytic
C818,819 VCEAZA1HW476M J AB 47 µF,50V,Electrolytic
C820 VCEAZA1VW107M J AC 100 µF,35V,Electrolytic
C821 VCEAZV1JW107M J 100 µF,63V,Electrolytic
C850 VCEAZW1EW338M J AG 3300 µF,25V,Electrolytic
C851 VCEAZA1EW226M J AB 22 µF,25V,Electrolytic
C852 VCQYKA1HM473K J AB 0.047 µF,50V,Mylar
C855,856 VCQYKA1HM104K J AB 0.1 µF,50V,Mylar
C857 VCEAZA1EW476M J AB 47 µF,25V,Electrolytic
C858,859 VCQYKA1HM104K J AB 0.1 µF,50V,Mylar
C860 VCEAZA1EW476M J AB 47 µF,25V,Electrolytic
C861,862 VCTYMN1EF223Z J AA 0.022 µF,25V
C863,864 VCEAZA1EW226M J AB 22 µF,25V,Electrolytic
C865 VCEAZA1EW476M J AB 47 µF,25V,Electrolytic
C901,902 VCEAZW2AW338M J 3300 µF,100V,Electrolytic
C903,904 RC-GZW478AF1H J AH 4700 µF,50V,Electrolytic
C911,912 VCCSPA1HL221J J AA 220 pF,50V
C913,914 VCCSPA1HL470J J AA 47 pF,50V
C915,916 VCEAZA1HW476M J AB 47 µF,50V,Electrolytic
C917,918 VCEAZA1HW225M J AB 2.2 µF,50V,Electrolytic
C919,920 VCEAZV2AW107M J 100 µF,100V,Electrolytic
C921,922 VCEAZA1HW107M J AC 100 µF,50V,Electrolytic
C923,924 VCQYKA1HM223J J AB 0.022 µF,50V,Mylar
C925 VCEAZA1HW476M J AB 47 µF,50V,Electrolytic
C927~930 VCFYHA1HA224J J AC 0.22 µF,50V,Thin Film
C931~938 VCQYKA1HM223J J AB 0.022 µF,50V,Mylar
C943 VCEAZA1HW106M J AB 10 µF,50V,Electrolytic
C945 VCEAZA1EW476M J AB 47 µF,25V,Electrolytic
C946 VCEAZA0JW107M J AC 100 µF,6.3V,Electrolytic
C951 VCQYKA1HM223J J AB 0.022 µF,50V,Mylar
C952 VCEAZA1EW227M J AC 220 µF,25V,Electrolytic
C957 VCEAZV2AW107M J 100 µF,100V,Electrolytic
C960,961 VCEAZA1HW106M J AB 10 µF,50V,Electrolytic
CK1 VCTYPA1CX103K J AA 0.01 µF,16V
CK2 VCFYHA1HA474J J AD 0.47 µF,50V,Thin Film
CK3 RC-EZY475AF1H J AB 4.7 µF,50V,Electrolytic
CK4 RC-EZY225AF1H J AB 2.2 µF,50V,Electrolytic
CK5,6 VCFYDA1HA104J J AB 0.1 µF,50V,Thin Film
CK7 VCFYHA1HA474J J AD 0.47 µF,50V,Thin Film
CK8 RC-EZY475AF1H J AB 4.7 µF,50V,Electrolytic
CK9 RC-EZY225AF1H J AB 2.2 µF,50V,Electrolytic
CK10,11 VCFYDA1HA104J J AB 0.1 µF,50V,Thin Film
CK12 RC-EZY225AF1H J AB 2.2 µF,50V,Electrolytic
CK13 VCTYPA1CX472K J AA 0.0047 µF,16V
CK14 VCTYPA1CX102K J AA 0.001 µF,16V
CK15 VCQYKA1HM683K J AB 0.068 µF,50V,Mylar
CK16 VCFYHA1HA224J J AC 0.22 µF,50V,Thin Film
CK17 VCEAZA1AW227M J AC 220 µF,10V,Electrolytic
CK18 VCEAZA1CW107M J AC 100 µF,16V,Electrolytic
CK19 VCKZPA1HF223Z J AA 0.022 µF,50V
CK20 VCFYHA1HA224J J AC 0.22 µF,50V,Thin Film
CK21 VCQYKA1HM683K J AB 0.068 µF,50V,Mylar
CK22 VCTYPA1CX472K J AA 0.0047 µF,16V
CK23 VCTYPA1CX102K J AA 0.001 µF,16V
CK24~30 VCEAZA1HW225M J AB 2.2 µF,50V,Electrolytic
CK31 VCFYDA1HA154J J AB 0.15 µF,50V,Polyester
CK33~35 VCCSPA1HL470J J AA 47 pF,50V
CK41 VCEAZA1EW476M J AB 47 µF,25V,Electrolytic
CK42 VCKZPA1HF223Z J AA 0.022 µF,50V
CK43,44 VCEAZA1EW476M J AB 47 µF,25V,Electrolytic
CK50~52 VCQYKA1HM683K J AB 0.068 µF,50V,Mylar
CK53~55 VCCSPA1HL470J J AA 47 pF,50V
CK56 VCEAZA1EW476M J AB 47 µF,25V,Electrolytic
CK57 VCEAZA1CW107M J AC 100 µF,16V,Electrolytic
CK58 VCKZPA1HF223Z J AA 0.022 µF,50V
CK60 VCQYKA1HM152K J AB 0.0015 µF,50V,Mylar
CK61 VCEAZA1HW225M J AB 2.2 µF,50V,Electrolytic
CK62,63 VCCSPA1HL471J J AA 470 pF,50V
CK64~67 VCTYPA1CX103K J AA 0.01 µF,16V
CK68 VCTYPA1CX472K J AA 0.0047 µF,16V
CK69 VCEAZA1HW225M J AB 2.2 µF,50V,Electrolytic
CK70,71 VCQYKA1HM473K J AB 0.047 µF,50V,Mylar
CK72 VCEAZA1CW107M J AC 100 µF,16V,Electrolytic
CK73,74 VCEAZA1HW225M J AB 2.2 µF,50V,Electrolytic
CV1 VCEAPS476AF0J J AC 47 µF,6.3V,Electrolytic
CV2 VCKYTV1CF224Z J AB 0.22 µF,16V
CV3 VCEAZA1HW475M J AB 4.7 µF,50V,Electrolytic
CV4 VCEAPS476AF0J J AC 47 µF,6.3V,Electrolytic
CV5 VCKYTV1CF224Z J AB 0.22 µF,16V
CV6,7 VCCCTV1HH270J J AA 27 pF (CH),50V
CV8 VCEAZA1HW105M J AB 1 µF,50V,Electrolytic
CV9 VCKYTV1CF224Z J AB 0.22 µF,16V
CV10 VCEAPS476AF0J J AC 47 µF,6.3V,Electrolytic
CV11,12 VCKYTV1CF224Z J AB 0.22 µF,16V
CV13,14 VCKYTV1EB104K J AA 0.1 µF,25V
CV15 VCEAPS475AF1E J AB 4.7 µF,25V,Electrolytic
CV16 VCKYTV1EB104K J AA 0.1 µF,25V
CV17 VCKYTV1HB103K J AA 0.01 µF,50V
CV18 VCEAZA0JW108M J AC 1000 µF,6.3V,Electrolytic
CV19~21 VCKYTV1CF224Z J AB 0.22 µF,16V
CV22,23 VCEAPS476AF0J J AC 47 µF,6.3V,Electrolytic
CV24,25 VCKYTV1CF224Z J AB 0.22 µF,16V
CV26 VCTYPA1CX102K J AA 0.001 µF,16V
CV39 VCEAZA0JW108M J AC 1000 µF,6.3V,Electrolytic
CV40 VCEAPS226AF0J J AB 22 µF,6.3V,Electrolytic
CV41 VCEAPS475AF1E J AB 4.7 µF,25V,Electrolytic
RESISTORS
VRD-MN2BD000C J AA 0 ohm,Jumper,ø1.4×3.5mm,Ivory
VRS-TV2AB000J J AA 0 ohm,Jumper,1.25×2mm,Green
J128~130 VRD-ST2CD102J J AA 1 kohm,1/6W
J732 VRD-ST2CD102J J AA 1 kohm,1/6W
R1 VRS-TV2AB102J J AA 1 kohm,1/10W
R3 VRS-TV2AB823J J AA 82 kohms,1/10W
R4 VRS-TV2AB183J J AA 18 kohms,1/10W
R5 VRS-TV2AB393J J AA 39 kohms,1/10W
R6 VRS-TV2AB273J J AA 27 kohms,1/10W
R7 VRS-TV2AB682J J AA 6.8 kohms,1/10W
R8 VRS-TV2AB331J J AA 330 ohms,1/10W
R10 VRS-TV2AB273J J AA 27 kohms,1/10W
R11 VRS-TV2AB123J J AA 12 kohms,1/10W
R12,13 VRS-TV2AB681J J AA 680 ohms,1/10W
R14 VRS-TV2AB122J J AA 1.2 kohms,1/10W
R15,16 VRS-TV2AB103J J AA 10 kohm,1/10W
R17 VRS-TV2AB102J J AA 1 kohm,1/10W
R19 VRS-TV2AB470J J AA 47 ohms,1/10W
R20 VRS-TV2AB221J J AA 220 ohms,1/10W
R21,22 VRS-TV2AB471J J AA 470 ohms,1/10W
R25 VRS-TV2AB103J J AA 10 kohm,1/10W
R35 VRS-TV2AB102J J AA 1 kohm,1/10W
R37 VRD-ST2CD152J J AA 1.5 kohm,1/6W
R38 VRS-TV2AB271J J AA 270 ohms,1/10W
R39 VRS-TV2AB471J J AA 470 ohms,1/10W
R40 VRS-TV2AB122J J AA 1.2 kohms,1/10W
R42 VRS-TV2AB124J J AA 120 kohms,1/10W
R44 VRS-TV2AB102J J AA 1 kohm,1/10W
R45 VRS-TV2AB122J J AA 1.2 kohms,1/10W
R46 VRS-TV2AB102J J AA 1 kohm,1/10W
R47 VRS-TV2AB3R3J J AA 3.3 ohms,1/10W
R48 VRS-TV2AB682J J AA 6.8 kohms,1/10W
– 3 –
