Sharp CV-2P10SX - Front;Rear View; Part Names

EN-8
1 Air Outlet
2 Vertical louvers
3 Horizontal louvers
4 POWER Button
5 Receiver window (for remote
control)
6 AIR CON Lamp (green)
7 TIMER Lamp (orange)
8 MAXIMUM Lamp (red)
9 ION GENERATOR Lamp
(blue)
10 Air inlet
REAR VIEW
NOTE: Actual unit might vary slightly from above illustration.
FRONT VIEW
11 Exhaust air outlet
12
Window adapter
13 Exhaust hose
14 Remote control hook
15 Airlter
16 Grill
17 Air inlet
18 Drainpipe and stopcock
19 Power plug
20 Casters(4)
1
2
3
4
5
6
7
8
9
10
10
10
PART NAMES
11
12
13
14
15
16
17
18
19
20
