EN-13
ENGLISH
Inner height of the window:
28.3" (718mm) - 45.3" (1150mm)
Use the window panel and the adjustment
panel.
(1) Open the window sash and place the
window panel on the window frame.
(2) Slide the adjustment panel to t the
window frame height.
(3) Secure the window panel to the window
frame with 3 screws.
Inner height of the window:
45.3" (1150mm) - 70.9" (1800mm)
Use the window panel, the adjustment panel
and the extension panel.
(1) Open the window sash and place the
window panel on the window frame.
(2) Slide the adjustment and extension
panels to t the window frame height.
(3) Secure the window panel to the window
frame with 4 screws.
5
Cut the foam seal B to the proper
length and attach them to the window
panel.
6
Close the window sash securely
against the Window panel.
7
Attach the bracket with a screw.
(Recommended)
Adjustment panel
Extension panel
28.3"- 45.3"
45.3"- 70.9"
Foam seal B (adhesive type)
Bracket
Adjustment panel
CV-2P13SX_en.indd 13 11.3.3 5:58:17 PM
