Sharp CV-2P10SX User Manual

EN-15
ENGLISH
Removal of the exhaust hose
1
Remove the window adapter.
Pull out and remove the window adapter by
pushing down two “PUSH” markings, and
slide and close the exhaust cover in the win-
dow panel.
2
Remove the exhaust hose from the
unit.
Lift up and remove the exhaust hose from
the unit by pushing on the two projections.
Projection
"PUSH"
Exhaust hose
CV-2P13SX_en.indd 15 11.3.3 5:58:18 PM
