Sharp CV-P10LC - Unit Part Identification; Front View Parts; Rear View Parts

PART NAMES
1 Air Outlet
2 Vertical louvers
3 Horizontal louvers
4 PLASMACLUSTER Lamp (blue)
5 Remote control signal receiver
window
6 POWER Button
7 OPERATION Lamp (red)
8 TIMER Lamp (orange)
9 MEGA COOL Lamp (green)
0 Air inlet
REAR VIEW
NOTE: Actual unit might vary slightly from above illustration.
FRONT VIEW
q Exhaust air outlet
w Window exhaust adapter
e Exhaust hose
r Remote control hook
t Air filters
y Drainage nozzle and stopcock
u Power supply cord hooks
i Drainpipe nozzle and stopcock
o Power supply cord
p Power plug
a Casters(4)
