Sharp CV-P10LC

ENGLISH
ndow
haust
apter
"PUSH"
Projection
E-17
Removal of the exhaust hose
1
Remove the window exhaust adapter.
Pull out and remove the window exhaust
adapter by pushing down two “PUSH”
markings, and slide and close the exhaust
cover in the window panel.
2
Remove the exhaust hose adapter from
the unit.
Lift up and remove the exhaust hose
adapter from the unit by pushing down on
the two projections.
