Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
34
CX34K3
PARTS LIST
PARTS REPLACEMENT
Replacement parts which have these special safety characteristics
identified in this manual: electrical components having such features
are identified by "å" in the Replacement Parts Lists.
The use of a substitute replacement part which does not have the
same safety characteristics as the factory recommended replace-
ment parts shown in this service manual may create shock, fire or
other hazards.
"HOW TO ORDER REPLACEMENT PARTS"
To have your order filled promptly and correctly, please furnish the
following informations.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
5. CODE 6. QUANTITY
MARK ★: SPARE PARTS-DELIVERY SECTION
Ref. No. Part No. ★ Description Code
PICTURE TUBE
å V1 VB370BVBK1S-S R Picture Tube BZ
or (DY: H0160PE)
VB37GDA86X/1E Picture Tube CB
(DY: H0149PEZZ)
LHLDW0003PEKZ J ADG Coil Holder, x3 AB
MSPRT0001PEFJ J Spring AC
PMAGF3006CEZZ R Purity Magnet AK
PSPAG0004PEZZ J Wedge (Gum), x3 AB
QEARC1422PEZZ J Grounding Strap AD
RCiLG0068PEZZ J Degaussing Coil AH
RCiLH0160PEZZ J Deflection Yoke BC
or (CRT: B370BVBK1S)
RCiLH0149PEZZ Deflection Yoke BA
(CRT: B37GDA86X)
PRINTED WIRING BOARD ASSEMBLIES
(NOT REPLACEMENT ITEM)
PWB-A DUNTK9988WEY2 – MAIN Unit —
PWB-B DUNTK9990WEV0 – CRT Unit —
PWB-C DUNTK9989WEV0 – HEADPHONE Unit —
PWB-A DUNTK9988WEY2
MAIN UNIT
TUNER
NOTE: THE PARTS HERE SHOWN ARE SUPPLIED AS AN
ASSEMBLY BUT NOT INDEPENDENTLY.
å TU201 VTUVTST5HD84/ R VHF Tuner BB
INTEGRATED CIRCUITS
IC301 VHiTDA7056A-1 R TDA7056A AP
IC304 VHiLA7016//-1 R LA7016 AH
IC402 VHiLA7016//-1 R LA7016 AH
IC501 VHiTDA8357/-1 R I.C. AN
IC605 VHiKA7808Pi-1 J KA7808PI AF
IC701 VHiSTRF6653-1 R I.C. AS
å IC702 RH-FX0008GEZZ R PC123FY8 AE
IC751 VHiTA48M033-1 R TA48M033F AH
IC753 VHiSE115N//-1 R SE115N AF
IC801 RH-iX3368CEN0 R I.C. BE
IC1002 VHiPST573J/-1 R I.C. AE
IC1003 VHiM24C04W/-1 R I.C. AG
IC1005 VHiKA7805Pi-1 J KA7805PI AE
TRANSISTORS
Q201 VS2SC2735//1E R 2SC2735 AC
Q203 VS2SD601A//-1 R 2SD601A AC
Q205 VS2SC1815GW-1 R 2SC1815GW AB
Q301 VS2SD601A//-1 R 2SD601A AC
Q302 VS2SD601A//-1 R 2SD601A AC
Q305 VS2SD601A//-1 R 2SD601A AC
Q601 VS2SC2482//-1 R 2SC2482 AD
Q602 VS2SD1877//1E R 2SD1877 AL
Q603 VS2SD601A//-1 R 2SD601A AC
Q710 VS2SC4517//-1 R 2SC4517 AG
Q711 VS2SD601A//-1 R 2SD601A AC
Q723 VS2SD601A//-1 R 2SD601A AC
Q751 VS2SA1015G/1E R 2SA1015G AC
Q752 VS2SC1815GW-1 R 2SC1815GW AB
Q753 VS2SC1815GW-1 R 2SC1815GW AB
Q801 VS2SB709A//-1 R 2SB709A AA
Q802 VS2SB709A//-1 R 2SB709A AA
Q1003 VS2SD601A//-1 R 2SD601A AC
Q1010 VS2SD601A//-1 R 2SD601A AC
DIODES
D201 RH-EX0676GEZZ R Zener Diode AA
D301 RH-DX0475CEZZ R Diode AB
D305 RH-EX0631GEZZ R Zener Diode AA
D308 RH-EX0631GEZZ R Zener Diode AA
D310 RH-DX0302CEZZ R Diode AC
D401 RH-EX0631GEZZ R Zener Diode AA
D402 RH-EX0631GEZZ R Zener Diode AA
D501 RH-EX0640GEZZ R Zener Diode AA
D502 RH-DX0475CEZZ R Diode AB
D503 RH-DX0475CEZZ R Diode AB
D504 RH-DX0475CEZZ R Diode AB
D505 RH-DX0127CEZZ R Diode AC
D507 RH-DX0475CEZZ R Diode AB
D508 RH-EX0647GEZZ R Zener Diode AA
D509 RH-EX0647GEZZ R Zener Diode AA
D510 RH-EX0867CEZZ R Zener Diode AC
D511 RH-EX0867CEZZ R Zener Diode AC
D512 RH-DX0475CEZZ R Diode AB
D513 RH-DX0475CEZZ R Diode AB
D514 RH-EX0903CEZZ R Zener Diode AC
D515 RH-EX0903CEZZ R Zener Diode AC
D602 RH-DX0475CEZZ R Diode AB
D603 RH-DX0062CEZZ R Diode AD
D604 RH-DX0475CEZZ R Diode AB
D605 RH-EX0840CEZZ R Zener Diode AC
D606 RH-DX0475CEZZ R Diode AB
D607 RH-EX0662GEZZ R Zener Diode AB
D608 RH-EX0604GEZZ R Zener Diode AB
D609 RH-DX0475CEZZ R Diode AB
D610 RH-EX0662GEZZ R Zener Diode AB
D611 RH-DX0302CEZZ R Diode AC
D612 RH-EX0627GEZZ R Zener Diode AA
D613 RH-DX0475CEZZ R Diode AB
D614 RH-DX0475CEZZ R Diode AB
D701 RH-DX0386CEZZ R Diode AG
D702 VHD1SS82///1A R Diode AC
D705 RH-DX0492CEZZ R Diode AE
D706 VHD1SS82///1A R Diode AC
D707 VHD1SS82///1A R Diode AC
D708 RH-DX0400CEZZ R Diode AC
D709 RH-DX0164CEZZ R Diode AC
D710 RH-EX0601GEZZ R Zener Diode AA
D711 VHD1SS82///1A R Diode AC
D712 VHD1SS82///1A R Diode AC
D713 RH-EX0621GEZZ R Zener Diode AB
D714 RH-DX0055TAZZ R Diode AD
D715 RH-DX0055TAZZ R Diode AD
