Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
36
CX34K3
C707 RC-EZ1044CEZZ R 150 400V Electrolytic AM
C708 RC-KZ0160GEZZ R 0.01 250V Ceramic AC
C709 RC-QZA471TAYJ R 470p 50V Mylar AB
C711 RC-KZ0339CEZZ R 560p 2kV Ceramic AD
C712 VCQYTA1HM102J R 1000p 50V Mylar AA
C713 RC-KZ007JCEZZ R 0.01 250V Ceramic AC
C714 RC-KZ0338CEZZ R 560p 2kV Ceramic AD
C715 VCKYPA2HB102K R 1000p 500V Ceramic AA
C717 VCQYTA1HM182J R 1800p 50V Mylar AA
C718 VCEA0A1EW475M R 4.7 25V Electrolytic AB
C719 VCEA9M1HW226M R 22 50V Electrolytic AB
å C721 RC-KZ0156CEZZ R 680p 250V Ceramic AG
C751 VCEA0A1CW476M R 47 16V Electrolytic AB
C752 VCEA0A0JW107M R 100 6.3V Electrolytic AB
C753 VCKYPA2HB102K R 1000p 500V Ceramic AA
C755 VCEA0A1CW108M R 1000 16V Electrolytic AD
C756 VCEA0A1CW338M R 3300 16V Electrolytic AE
C758 VCKYPA1HB221K R 220p 50V Ceramic AA
å C759 VCKYPA1HB102K R 1000p 50V Ceramic AA
C760 RC-KZ0339CEZZ R 680p 2kV Ceramic AD
C761 VCEA4W2CN227M R 220 160V Electrolytic AG
C762 VCQYTA1HM473J R 0.047 50V Mylar AA
C801 VCEA0A1HW105M R 1.0 50V Electrolytic AB
C802 VCEA0A1CW337M R 330 16V Electrolytic AC
C803 VCEA9M1CW107M R 100 16V Electrolytic AB
C804 VCKYCY1HB222K R 2200p 50V Ceramic AA
C805 VCKYCY1HB102K R 1000p 50V Ceramic AA
C806 VCKYCY1HB102K R 1000p 50V Ceramic AA
C807 VCKYCY1HB102K R 1000p 50V Ceramic AA
C808 VCEA0A1CW107M R 100 16V Electrolytic AC
C809 VCKYCY1HF223Z R 0.022 50V Ceramic AB
C810 VCKYCY1EF104Z R 0.1 25V Ceramic AA
C811 VCEA0A1CW107M R 100 16V Electrolytic AC
C812 VCFYFA1HA224J R 0.22 50V Mylar AB
C813 VCFYFA1HA224J R 0.22 50V Mylar AB
C814 VCKYCY1HB471K R 470p 50V Ceramic AA
C1001 VCEA0A0JW107M R 100 6.3V Electrolytic AB
C1002 VCKYCY1HB561K R 560p 50V Ceramic AA
C1003 VCEA0A1CW106M R 10 16V Electrolytic AB
C1004 VCKYCY1HF103Z R 0.01 50V Ceramic AA
C1005 VCKYCY1HF223Z R 0.022 50V Ceramic AB
C1006 VCEA0A1CW106M R 10 16V Electrolytic AB
C1007 VCEA0A1CW106M R 10 16V Electrolytic AB
C1008 VCCCCY1HH330J R 33p 50V Ceramic AA
C1009 VCCCCY1HH330J R 33p 50V Ceramic AA
C1010 VCEA0A0JW107M R 100 6.3V Electrolytic AB
C1011 VCKYCY1HF223Z R 0.022 50V Ceramic AB
C1012 VCKYCY1HF223Z R 0.022 50V Ceramic AB
C1013 VCEA0A0JW107M R 100 6.3V Electrolytic AB
C1014 VCEA0A1CW106M R 10 16V Electrolytic AB
C1015 VCFYFA1HA474J R 0.47 50V Mylar AC
C1016 VCQYTA1HM104J R 0.1 50V Mylar AA
C1017 VCKYCY1HB222K R 2200p 50V Ceramic AA
C1018 VCKYCY1HB221K R 220p 50V Ceramic AA
C1019 VCEA9M1HW225M R 2.2 50V Electrolytic AB
RESISTORS
RJ2 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ5 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ7 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ8 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ9 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ10 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ11 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ12 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ13 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ14 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ15 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ16 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ21 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ25 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ26 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ27 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ28 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ29 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ30 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ31 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ32 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ33 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ34 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ40 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ41 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ51 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ53 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ55 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ64 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ66 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ68 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ69 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ71 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ74 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ75 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ76 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ78 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ79 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ80 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ84 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ85 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ87 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ88 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ89 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ92 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ94 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ95 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ96 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ97 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ103 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ105 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ201 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ202 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ204 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ205 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ206 VRN-MD2AL000J R 0 1/10W Metal Film AA
R201 VRN-MD2AL101J R 100 1/10W Metal Film AA
R202 VRN-MD2AL101J R 100 1/10W Metal Film AA
R203 VRD-RM2HD102J R 1.0k 1/2W Carbon AA
R204 VRD-RM2HD102J R 1.0k 1/2W Carbon AA
R205 VRD-RA2BE680J R 68 1/8W Carbon AA
R206 VRN-MD2AL122J R 1.2k 1/10W Metal Film AA
R207 VRN-MD2AL221J R 220 1/10W Metal Film AA
R208 VRN-MD2AL122J R 1.2k 1/10W Metal Film AA
R209 VRN-MD2AL392J R 3.9k 1/10W Metal Film AA
R216 VRN-MD2AL681J R 680 1/10W Metal Film AA
R217 VRD-RA2BE392J R 3.9k 1/8W Carbon AA
R218 VRN-MD2AL102J R 1.0k 1/10W Metal Film AA
R219 VRN-MD2AL391J R 390 1/10W Metal Film AA
R220 VRN-MD2AL101J R 100 1/10W Metal Film AA
R221 VRN-MD2AL102J R 1.0k 1/10W Metal Film AA
R222 VRN-MD2AL681J R 680 1/10W Metal Film AA
R226 VRN-MD2AL750J R 75 1/10W Metal Film AA
R227 VRD-RM2HD330J R 33 1/2W Carbon AA
R228 VRD-RM2HD330J R 33 1/2W Carbon AA
R230 VRN-MD2AL101J R 100 1/10W Metal Film AA
R231 VRN-MD2AL153J R 15k 1/10W Metal Film AA
R233 VRN-MD2AL181J R 180 1/10W Metal Film AA
R237 VRN-MD2AL272J R 2.7k 1/10W Metal Film AA
R238 VRN-MD2AL821J R 820 1/10W Metal Film AA
R239 VRN-MD2AL221J R 220 1/10W Metal Film AA
R301 VRN-MD2AL680J R 68 1/10W Metal Film AA
R302 VRN-MD2AL473J R 47k 1/10W Metal Film AA
R303 VRN-MD2AL473J R 47k 1/10W Metal Film AA
R304 VRN-MD2AL392J R 3.9k 1/10W Metal Film AA
R305 VRN-MD2AL100J R 10 1/10W Metal Film AA
R307 VRD-RA2BE182J R 1.8k 1/8W Carbon AA
R308 VRD-RA2BE472J R 4.7k 1/8W Carbon AA
R320 VRN-MD2AL101J R 100 1/10W Metal Film AA
R321 VRN-MD2AL561J R 560 1/10W Metal Film AA
R328 VRN-MD2AL564J R 560k 1/10W Metal Film AA
R329 VRN-MD2AL332J R 3.3k 1/10W Metal Film AA
R330 VRN-MD2AL101J R 100 1/10W Metal Film AA
