Sharp DV-600S - Page 74

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
74
DV-600S
DV-600H
R2308 VRD-RA2BE102J 1k 1/8W Carbon AA
R2309 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R2310 VRS-CY1JF682J 6.8k 1/16W Metal Oxide AA
R2311 VRS-CY1JF682J 6.8k 1/16W Metal Oxide AA
R2312 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R2313 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R2314 VRD-RA2BE102J 1k 1/8W Carbon AA
R2315 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R2316 VRD-RA2BE102J 1k 1/8W Carbon AA
R2317 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R2318 VRS-CY1JF750J 75 1/16W Metal Oxide AA
R2319 VRS-CY1JF471J 470 1/16W Metal Oxide AA
R2320 VRS-CY1JF471J 470 1/16W Metal Oxide AA
R2321 VRS-CY1JF471J 470 1/16W Metal Oxide AA
R2322 VRS-CY1JF750J 75 1/16W Metal Oxide AA
R2323 VRS-CY1JF222J 2.2k 1/16W Metal Oxide AA
R2324 VRS-CY1JF750J 75 1/16W Metal Oxide AA
R2325 VRS-CY1JF750J 75 1/16W Metal Oxide AA
R2326 VRS-CY1JF750J 75 1/16W Metal Oxide AA
R2327 VRS-CY1JF750J 75 1/16W Metal Oxide AA
R2331 VRS-CY1JF821J 820 1/16W Metal Oxide AA
R2332 VRS-CY1JF331J 330 1/16W Metal Oxide AA
R2333 VRS-CY1JF562J 5.6k 1/16W Metal Oxide AA
R2334 VRS-CY1JF474J 470k 1/16W Metal Oxide AA
MISCELLANEOUS PARTS
CN2303 QPLGN1280GEZZ Plug, 12Pin AC
CN2304 QPLGN1080GEZZ Plug, 10Pin AC
FB2201 RBLN-0043CEZZ Balun, BLN-0043CE AB
SC2201 QSOCZ2101REZZ Socket, 21Pin AK
17-8
CAPACITOR
C6661 VCKYCY1HF103Z 0.01 50V Ceramic AA
RESISTOR
R6664 VRS-CY1JF101J 100 1/16W Metal Oxide AA
MISCELLANEOUS PARTS
CN6661 QSOCN0895REZZ Socket, 8Pin AC
W6661 RRMCU0080GEZZ Remote Receiver AG
DUNTK5672TEV3(DV-600S)
DUNTK5672TEV4(DV-600H)
21-PIN EURO SCART PWB UNIT
INTEGRATED CIRCUITS
IC2302 VHiNJM2286M-1 NJM2286M, Signal SW AE
IC2303 VHiNJM2267M-1 NJM2267M, B/G Drive AF
IC2304 VHiNJM2267M-1 NJM2267M, SC RT R/V Drive AF
TRANSISTORS
Q2301 VS2SB709A//-1 2SB709A AA
Q2302 VSUN2212///-1 UN2212 AA
Q2303 VS2SD601A//-1 2SD601A AC
Q2304 VS2SD601A//-1 2SD601A AC
Q2305 VS2SB709A//-1 2SB709A AA
Q2306 VS2SD601A//-1 2SD601A AC
Q2307 VSUN2212///-1 UN2212 AA
Q2308 VS2SD601A//-1 2SD601A AC
Q2309 VS2SD601A//-1 2SD601A AC
DIODES
D2201 RH-EX0646GEZZ Zener, EX0646GE AA
D2202 RH-EX0646GEZZ Zener, EX0646GE AA
D2301 VHDDAN202K/-1 DAN202K AB
D2302 VHDDAP202K/-1 DAP202K AB
COILS
L2203 VP-XF3R3K0000 Peaking, 3.3µHAB
L2204 VP-XF3R3K0000 Peaking, 3.3µHAB
L2301 VP-MK100K0000 Peaking, 10µHAB
CAPACITORS
C2203 VCKYCY1HB102K 1000p 50V Ceramic AA
C2302 VCKYCY1CB104K 0.1 16V Ceramic AB
C2303 VCEAEM1AW476M 47 10V Electrolytic AB
C2304 VCEAEM1AW476M 47 10V Electrolytic AB
C2305 VCKYCY1HB103K 0.01 50V Ceramic AA
C2306 VCEAEM1AW476M 47 10V Electrolytic AB
C2307 VCEAEM1HW225M 2.2 50V Electrolytic AB
C2308 VCEAEM1HW225M 2.2 50V Electrolytic AB
C2309 VCEAEM1HW225M 2.2 50V Electrolytic AB
C2310 VCEAEM1HW225M 2.2 50V Electrolytic AB
C2311 VCEAEM1CW226M 22 16V Electrolytic AB
C2312 VCEAEM1HW475M 4.7 50V Electrolytic AB
C2313 VCEAEM1HW475M 4.7 50V Electrolytic AB
C2314 VCEA2A0JW477M 470 6.3V Electrolytic AB
C2315 VCQYTA1HM104J 0.1 50V Mylar AA
C2316 VCEAEM1HW475M 4.7 50V Electrolytic AB
C2317 VCEAEM0JW107M 100 6.3V Electrolytic AB
RESISTORS
R2205 VRS-CY1JF101J 100 1/16W Metal Oxide AA
R2206 VRS-CY1JF101J 100 1/16W Metal Oxide AA
R2207 VRD-RM2HD331J 330 1/2W Carbon AA
R2208 VRD-RM2HD750J 75 1/2W Carbon AA
R2301 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R2303 VRS-CY1JF750J 75 1/16W Metal Oxide AA
R2304 VRS-CY1JF471J 470 1/16W Metal Oxide AA
R2305 VRS-CY1JF750J 75 1/16W Metal Oxide AA
R2306 VRS-CY1JF121J 120 1/16W Metal Oxide AA
R2307 VRS-CY1JF682J 6.8k 1/16W Metal Oxide AA
QCNW-7884AJZZ Connecting Cord, 14 Pin AF
CN5001-CN802
QCNW-8035AJZZ Connecting Cord, 29 pin AF
CN801-CN6001
QCNW-8036AJZZ Connecting Cord, 15 Pin AE
CN803-CN2001
QCNW-8037AJZZ Connecting Cord, 8 Pin AD
CN5002-CN8102,
CN6601-CN6661
QCNW-8083AJZZ Connecting Cord, 12 Pin AH
CN201-CN9001
QCNW-8040AJZZ Connecting Cord, 12 Pin AG
CN2301-CN2303
QCNW-8041AJZZ Connecting Cord, 10 Pin AG
CN2302-CN2304
QCNW-8047AJZZ Connecting Cord, 6 Pin AF
CN6602-CN6002
OTHER PARTS
